#include <patch_point_values.hh>

Collaboration diagram for PatchPointValues< spacedim >:

[legend]

Classes
struct	PatchFeData

Public Member Functions
	PatchPointValues (uint dim, PatchFeData &patch_fe_data)

virtual	~PatchPointValues ()

void	initialize ()

void	reset ()
	Reset number of columns (points and elements) More...

uint	dim () const
	Getter for dim_. More...

uint	n_elems () const
	Getter for n_elems_. More...

uint	n_points () const
	Getter for n_points_. More...

Quadrature *	get_quadrature () const
	Getter for quadrature. More...

void	resize_tables (uint n_elems, uint n_points)
	Resize data tables. Method is called before reinit of patch. More...

uint	register_element (arma::mat coords, uint element_patch_idx)

uint	register_side (arma::mat elm_coords, arma::mat side_coords, uint side_idx)

uint	register_bulk_point (uint elem_table_row, uint value_patch_idx, uint elem_idx, uint i_point_on_elem)

uint	register_side_point (uint elem_table_row, uint value_patch_idx, uint elem_idx, uint side_idx, uint i_point_on_side)

PatchOp< spacedim > *	make_new_op (uint op_idx, std::initializer_list< uint > shape, ReinitFunction reinit_f, OpSizeType size_type=pointOp)

PatchOp< spacedim > *	make_fixed_op (uint op_idx, std::initializer_list< uint > shape, ReinitFunction reinit_f)

PatchOp< spacedim > *	make_fe_op (uint op_idx, std::initializer_list< uint > shape, ReinitFunction reinit_f, uint n_dofs, OpSizeType size_type=pointOp)

PatchOp< spacedim > *	make_fixed_fe_op (uint op_idx, std::initializer_list< uint > shape, ReinitFunction reinit_f, uint n_dofs)

void	reinit_patch ()

Scalar	scalar_elem_value (uint op_idx, uint point_idx) const

Vector	vector_elem_value (uint op_idx, uint point_idx) const

Tensor	tensor_elem_value (uint op_idx, uint point_idx) const

Scalar	scalar_value (uint op_idx, uint point_idx, uint i_dof=0) const

Vector	vector_value (uint op_idx, uint point_idx, uint i_dof=0) const

Tensor	tensor_value (uint op_idx, uint point_idx, uint i_dof=0) const

AssemblyArena &	asm_arena () const
	return reference to assembly arena More...

PatchArena &	patch_arena () const
	return reference to patch arena More...

void	zero_values_needed ()
	Set flag needs_zero_values_ to true. More...

PatchPointValues *	zero_values ()

virtual void	create_zero_values ()=0
	Create zero_values_ object. More...

void	print_data_tables (ostream &stream, bool points, bool ints) const

void	print_operations (ostream &stream, uint bulk_side) const

Protected Member Functions
void	create_zero_operations (std::vector< PatchOp< spacedim > * > &ref_ops)

Protected Attributes
IntTableArena	int_table_

std::vector< OpSizeType >	int_sizes_
	Set size and type of rows of int_table_, value is set implicitly in constructor of descendants. More...

std::vector< PatchOp< spacedim > * >	operations_
	Vector of all defined operations. More...

std::vector< std::vector< unsigned int > >	op_dependency_
	Holds dependency between operations. More...

uint	dim_
	Dimension. More...

uint	n_points_
	Number of points in patch. More...

uint	n_elems_
	Number of elements in patch. More...

uint	i_elem_
	Index of registered element in table, helper value used during patch creating. More...

Quadrature *	quad_
	Quadrature of given dimension and order passed in constructor. More...

std::vector< uint >	elements_map_
	Map of element patch indices to PatchOp::result_ and int_table_ tables. More...

std::vector< uint >	points_map_
	Map of point patch indices to PatchOp::result_ and int_table_ tables. More...

PatchFeData &	patch_fe_data_
	Reference to PatchFeData structure shared with PatchFeValues. More...

bool	needs_zero_values_
	Flags hold whether zero_values_ object is needed. More...

PatchPointValues *	zero_values_
	PatchPointValues object returns zero values for all operations. More...

Friends
class	PatchFEValues< spacedim >

class	PatchOp< spacedim >

template<class ValueType >
class	ElQ

template<class ValueType >
class	FeQ

template<unsigned int dim>
class	BulkValues

template<unsigned int dim>
class	SideValues

template<unsigned int dim>
class	JoinValues

Detailed Description

template<unsigned int spacedim = 3>
class PatchPointValues< spacedim >

v Class for storing FE data of quadrature points on one patch.

Store data of bulk or side quadrature points of one dimension.

Definition at line 143 of file patch_point_values.hh.

Constructor & Destructor Documentation

◆ PatchPointValues()

template<unsigned int spacedim = 3>

PatchPointValues< spacedim >::PatchPointValues	(	uint	dim,
		PatchFeData &	patch_fe_data
	)

inline

Constructor

Parameters

dim	Set dimension

Definition at line 171 of file patch_point_values.hh.

◆ ~PatchPointValues()

template<unsigned int spacedim = 3>

virtual PatchPointValues< spacedim >::~PatchPointValues ( )

inlinevirtual

Destructor.

Reimplemented in FeSide::PatchPointValues< spacedim >, and FeBulk::PatchPointValues< spacedim >.

Definition at line 179 of file patch_point_values.hh.

Member Function Documentation

◆ asm_arena()

template<unsigned int spacedim = 3>

AssemblyArena& PatchPointValues< spacedim >::asm_arena ( ) const

inline

return reference to assembly arena

Definition at line 490 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ create_zero_operations()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::create_zero_operations ( std::vector< PatchOp< spacedim > * > & ref_ops )

protected

◆ create_zero_values()

template<unsigned int spacedim = 3>

virtual void PatchPointValues< spacedim >::create_zero_values ( )

pure virtual

Create zero_values_ object.

Implemented in FeSide::PatchPointValues< spacedim >, and FeBulk::PatchPointValues< spacedim >.

Here is the caller graph for this function:

◆ dim()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::dim ( ) const

inline

Getter for dim_.

Definition at line 204 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ get_quadrature()

template<unsigned int spacedim = 3>

Quadrature* PatchPointValues< spacedim >::get_quadrature ( ) const

inline

Getter for quadrature.

Definition at line 219 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ initialize()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::initialize ( )

inline

Initialize object, set number of columns (quantities) in tables.

Definition at line 189 of file patch_point_values.hh.

◆ make_fe_op()

template<unsigned int spacedim = 3>

PatchOp<spacedim>* PatchPointValues< spacedim >::make_fe_op	(	uint	op_idx,
		std::initializer_list< uint >	shape,
		ReinitFunction	reinit_f,
		uint	n_dofs,
		OpSizeType	size_type = `pointOp`
	)

inline

Adds accessor of FE operation and adds operation dynamically to operations_ vector

Parameters

op_idx	Index of operation in operations_ vector
shape	Shape of function output
reinit_f	Reinitialize function
n_dofs	Number of DOFs
size_type	Type of operation by size of rows

Definition at line 367 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ make_fixed_fe_op()

template<unsigned int spacedim = 3>

PatchOp<spacedim>* PatchPointValues< spacedim >::make_fixed_fe_op	(	uint	op_idx,
		std::initializer_list< uint >	shape,
		ReinitFunction	reinit_f,
		uint	n_dofs
	)

inline

Adds accessor of new operation with fixed data size (ref data) to operations_ vector

Parameters

op_idx	Index of operation in operations_ vector
shape	Shape of function output
reinit_f	Reinitialize function
n_dofs	Number of DOFs

Definition at line 388 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ make_fixed_op()

template<unsigned int spacedim = 3>

PatchOp<spacedim>* PatchPointValues< spacedim >::make_fixed_op	(	uint	op_idx,
		std::initializer_list< uint >	shape,
		ReinitFunction	reinit_f
	)

inline

Adds accessor of new operation with fixed data size (ref data) to operations_ vector

Parameters

op_idx	Index of operation in operations_ vector
shape	Shape of function output
reinit_f	Reinitialize function

Definition at line 354 of file patch_point_values.hh.

◆ make_new_op()

template<unsigned int spacedim = 3>

PatchOp<spacedim>* PatchPointValues< spacedim >::make_new_op	(	uint	op_idx,
		std::initializer_list< uint >	shape,
		ReinitFunction	reinit_f,
		OpSizeType	size_type = `pointOp`
	)

inline

Adds accessor of new operation to operations_ vector

Parameters

op_idx	Index of operation in operations_ vector
shape	Shape of function output
reinit_f	Reinitialize function
size_type	Type of operation by size of rows

Definition at line 343 of file patch_point_values.hh.

◆ n_elems()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::n_elems ( ) const

inline

Getter for n_elems_.

Definition at line 209 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ n_points()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::n_points ( ) const

inline

Getter for n_points_.

Definition at line 214 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ patch_arena()

template<unsigned int spacedim = 3>

PatchArena& PatchPointValues< spacedim >::patch_arena ( ) const

inline

return reference to patch arena

Definition at line 495 of file patch_point_values.hh.

◆ print_data_tables()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::print_data_tables	(	ostream &	stream,
		bool	points,
		bool	ints
	)		const

inline

Performs output of data tables to stream.

Development method.

Parameters

points	Allows switched off output of point table,
ints	Allows switched off output of int (connectivity to elements) table,

Definition at line 520 of file patch_point_values.hh.

◆ print_operations()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::print_operations	(	ostream &	stream,
		uint	bulk_side
	)		const

inline

Performs table of fixed operations to stream.

Development method.

Parameters

bulk_side Needs set 0 (bulk) or 1 (side) for correct output of operation names.

Definition at line 559 of file patch_point_values.hh.

◆ register_bulk_point()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::register_bulk_point	(	uint	elem_table_row,
		uint	value_patch_idx,
		uint	elem_idx,
		uint	i_point_on_elem
	)

inline

Register bulk point, add to int_table_

Parameters

elem_table_row	Index of element in temporary element table.
value_patch_idx	Index of point in ElementCacheMap.
elem_idx	Index of element in Mesh.
i_point_on_elem	Index of point on element

Definition at line 305 of file patch_point_values.hh.

◆ register_element()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::register_element	(	arma::mat	coords,
		uint	element_patch_idx
	)

inline

Register element, add to coords operation

Parameters

coords	Coordinates of element nodes.
element_patch_idx	Index of element on patch.

Definition at line 246 of file patch_point_values.hh.

◆ register_side()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::register_side	(	arma::mat	elm_coords,
		arma::mat	side_coords,
		uint	side_idx
	)

inline

Register side, add to coords operations

Parameters

coords	Coordinates of element nodes.
side_coords	Coordinates of side nodes.
side_idx	Index of side on element.

Definition at line 271 of file patch_point_values.hh.

◆ register_side_point()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::register_side_point	(	uint	elem_table_row,
		uint	value_patch_idx,
		uint	elem_idx,
		uint	side_idx,
		uint	i_point_on_side
	)

inline

Register side point, add to int_table_

Parameters

elem_table_row	Index of side in temporary element table.
value_patch_idx	Index of point in ElementCacheMap.
elem_idx	Index of element in Mesh.
side_idx	Index of side on element.
i_point_on_side	Index of point on side

Definition at line 324 of file patch_point_values.hh.

◆ reinit_patch()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::reinit_patch ( )

inline

Reinitializes patch data.

Calls reinit functions defined on each operations.

Definition at line 398 of file patch_point_values.hh.

◆ reset()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::reset ( )

inline

Reset number of columns (points and elements)

Definition at line 197 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ resize_tables()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::resize_tables	(	uint	n_elems,
		uint	n_points
	)

inline

Resize data tables. Method is called before reinit of patch.

Definition at line 224 of file patch_point_values.hh.

◆ scalar_elem_value()

template<unsigned int spacedim = 3>

Scalar PatchPointValues< spacedim >::scalar_elem_value	(	uint	op_idx,
		uint	point_idx
	)		const

inline

Returns scalar output value of data stored by elements.

Parameters

op_idx	Index of operation in operations vector
point_idx	Index of quadrature point in ElementCacheMap

Definition at line 411 of file patch_point_values.hh.

◆ scalar_value()

template<unsigned int spacedim = 3>

Scalar PatchPointValues< spacedim >::scalar_value	(	uint	op_idx,
		uint	point_idx,
		uint	i_dof = `0`
	)		const

inline

Returns scalar output value on point.

Parameters

op_idx	Index of operation in operations vector
point_idx	Index of quadrature point in ElementCacheMap
i_dof	Index of DOF

Definition at line 453 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ tensor_elem_value()

template<unsigned int spacedim = 3>

Tensor PatchPointValues< spacedim >::tensor_elem_value	(	uint	op_idx,
		uint	point_idx
	)		const

inline

Returns tensor output value of data stored by elements.

Parameters

op_idx	Index of operation in operations vector
point_idx	Index of quadrature point in ElementCacheMap

Definition at line 436 of file patch_point_values.hh.

◆ tensor_value()

template<unsigned int spacedim = 3>

Tensor PatchPointValues< spacedim >::tensor_value	(	uint	op_idx,
		uint	point_idx,
		uint	i_dof = `0`
	)		const

inline

Returns tensor output value on point.

Parameters

op_idx	Index of operation in operations vector
point_idx	Index of quadrature point in ElementCacheMap
i_dof	Index of DOF

Definition at line 480 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ vector_elem_value()

template<unsigned int spacedim = 3>

Vector PatchPointValues< spacedim >::vector_elem_value	(	uint	op_idx,
		uint	point_idx
	)		const

inline

Returns vector output value of data stored by elements.

Parameters

op_idx	Index of operation in operations vector
point_idx	Index of quadrature point in ElementCacheMap

Definition at line 421 of file patch_point_values.hh.

◆ vector_value()

template<unsigned int spacedim = 3>

Vector PatchPointValues< spacedim >::vector_value	(	uint	op_idx,
		uint	point_idx,
		uint	i_dof = `0`
	)		const

inline

Returns vector output value on point.

Parameters

op_idx	Index of operation in operations vector
point_idx	Index of quadrature point in ElementCacheMap
i_dof	Index of DOF

Definition at line 464 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ zero_values()

template<unsigned int spacedim = 3>

PatchPointValues* PatchPointValues< spacedim >::zero_values ( )

inline

Definition at line 505 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ zero_values_needed()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::zero_values_needed ( )

inline

Set flag needs_zero_values_ to true.

Definition at line 500 of file patch_point_values.hh.

Here is the caller graph for this function:

Friends And Related Function Documentation

◆ BulkValues

template<unsigned int spacedim = 3>

template<unsigned int dim>

friend class BulkValues

friend

Definition at line 628 of file patch_point_values.hh.

◆ ElQ

template<unsigned int spacedim = 3>

template<class ValueType >

friend class ElQ

friend

Definition at line 624 of file patch_point_values.hh.

◆ FeQ

template<unsigned int spacedim = 3>

template<class ValueType >

friend class FeQ

friend

Definition at line 626 of file patch_point_values.hh.

◆ JoinValues

template<unsigned int spacedim = 3>

template<unsigned int dim>

friend class JoinValues

friend

Definition at line 632 of file patch_point_values.hh.

◆ PatchFEValues< spacedim >

template<unsigned int spacedim = 3>

friend class PatchFEValues< spacedim >

friend

Definition at line 619 of file patch_point_values.hh.

◆ PatchOp< spacedim >

template<unsigned int spacedim = 3>

friend class PatchOp< spacedim >

friend

Definition at line 619 of file patch_point_values.hh.

◆ SideValues

template<unsigned int spacedim = 3>

template<unsigned int dim>

friend class SideValues

friend

Definition at line 630 of file patch_point_values.hh.

Member Data Documentation

◆ dim_

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::dim_

protected

Dimension.

Definition at line 607 of file patch_point_values.hh.

◆ elements_map_

template<unsigned int spacedim = 3>

std::vector<uint> PatchPointValues< spacedim >::elements_map_

protected

Map of element patch indices to PatchOp::result_ and int_table_ tables.

Definition at line 613 of file patch_point_values.hh.

◆ i_elem_

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::i_elem_

protected

Index of registered element in table, helper value used during patch creating.

Definition at line 610 of file patch_point_values.hh.

◆ int_sizes_

template<unsigned int spacedim = 3>

std::vector<OpSizeType> PatchPointValues< spacedim >::int_sizes_

protected

Set size and type of rows of int_table_, value is set implicitly in constructor of descendants.

Definition at line 598 of file patch_point_values.hh.

◆ int_table_

template<unsigned int spacedim = 3>

IntTableArena PatchPointValues< spacedim >::int_table_

protected

Hold integer values of quadrature points of defined operations.

Table contains following rows: 0: Index of quadrature point on patch 1: Row of element/side in PatchOp::result_ table in registration step (before expansion) 2: Element idx in Mesh

last two rows are allocated only for side point table 3: Index of side in element - short vector, size of column = number of sides 4: Index of side in element - long vector, size of column = number of points Number of used rows is given by n_points_.

Definition at line 595 of file patch_point_values.hh.

◆ n_elems_

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::n_elems_

protected

Number of elements in patch.

Definition at line 609 of file patch_point_values.hh.

◆ n_points_

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::n_points_

protected

Number of points in patch.

Definition at line 608 of file patch_point_values.hh.

◆ needs_zero_values_

template<unsigned int spacedim = 3>

bool PatchPointValues< spacedim >::needs_zero_values_

protected

Flags hold whether zero_values_ object is needed.

Definition at line 618 of file patch_point_values.hh.

◆ op_dependency_

template<unsigned int spacedim = 3>

std::vector< std::vector<unsigned int> > PatchPointValues< spacedim >::op_dependency_

protected

Holds dependency between operations.

Definition at line 605 of file patch_point_values.hh.

◆ operations_

template<unsigned int spacedim = 3>

std::vector<PatchOp<spacedim> *> PatchPointValues< spacedim >::operations_

protected

Vector of all defined operations.

Definition at line 602 of file patch_point_values.hh.

◆ patch_fe_data_

template<unsigned int spacedim = 3>

PatchFeData& PatchPointValues< spacedim >::patch_fe_data_

protected

Reference to PatchFeData structure shared with PatchFeValues.

Definition at line 616 of file patch_point_values.hh.

◆ points_map_

template<unsigned int spacedim = 3>

std::vector<uint> PatchPointValues< spacedim >::points_map_

protected

Map of point patch indices to PatchOp::result_ and int_table_ tables.

Definition at line 614 of file patch_point_values.hh.

◆ quad_

template<unsigned int spacedim = 3>

Quadrature* PatchPointValues< spacedim >::quad_

protected

Quadrature of given dimension and order passed in constructor.

Definition at line 611 of file patch_point_values.hh.

◆ zero_values_

template<unsigned int spacedim = 3>

PatchPointValues* PatchPointValues< spacedim >::zero_values_

protected

PatchPointValues object returns zero values for all operations.

Definition at line 619 of file patch_point_values.hh.

The documentation for this class was generated from the following file:

/home/runner/work/flow123d/flow123d/src/fem/patch_point_values.hh

Classes

Public Member Functions

Protected Member Functions

Protected Attributes

Friends

Detailed Description

template<unsigned int spacedim = 3> class PatchPointValues< spacedim >

Constructor & Destructor Documentation

◆ PatchPointValues()

◆ ~PatchPointValues()

Member Function Documentation

◆ asm_arena()

◆ create_zero_operations()

◆ create_zero_values()

◆ dim()

◆ get_quadrature()

◆ initialize()

◆ make_fe_op()

◆ make_fixed_fe_op()

◆ make_fixed_op()

◆ make_new_op()

◆ n_elems()

◆ n_points()

◆ patch_arena()

◆ print_data_tables()

◆ print_operations()

◆ register_bulk_point()

◆ register_element()

◆ register_side()

◆ register_side_point()

◆ reinit_patch()

◆ reset()

◆ resize_tables()

◆ scalar_elem_value()

◆ scalar_value()

◆ tensor_elem_value()

◆ tensor_value()

◆ vector_elem_value()

◆ vector_value()

◆ zero_values()

◆ zero_values_needed()

Friends And Related Function Documentation

◆ BulkValues

◆ ElQ

◆ FeQ

◆ JoinValues

◆ PatchFEValues< spacedim >

◆ PatchOp< spacedim >

◆ SideValues

Member Data Documentation

◆ dim_

◆ elements_map_

◆ i_elem_

◆ int_sizes_

◆ int_table_

◆ n_elems_

◆ n_points_

◆ needs_zero_values_

◆ op_dependency_

◆ operations_

◆ patch_fe_data_

◆ points_map_

◆ quad_

◆ zero_values_

template<unsigned int spacedim = 3>
class PatchPointValues< spacedim >
