#include <patch_fe_values.hh>

Inheritance diagram for BulkValues< dim >:

Collaboration diagram for BulkValues< dim >:

[legend]

Public Member Functions
	BulkValues (PatchPointValues< 3 > *patch_point_vals, MixedPtr< FiniteElement > fe)
	Constructor. More...

FeQ< Scalar >	JxW ()
	Register the product of Jacobian determinant and the quadrature weight at bulk quadrature points. More...

ElQ< Vector >	coords ()
	Create bulk accessor of coords entity. More...

ElQ< Scalar >	determinant ()
	Create bulk accessor of jac determinant entity. More...

FeQArray< Scalar >	ref_scalar (uint component_idx=0)

FeQArray< Vector >	ref_vector (uint component_idx=0)

FeQArray< Vector >	ref_scalar_grad (uint component_idx=0)

FeQArray< Tensor >	ref_vector_grad (uint component_idx=0)

FeQArray< Scalar >	scalar_shape (uint component_idx=0)
	Return the value of the `function_no-th` shape function at the `p` bulk quadrature point. More...

FeQArray< Vector >	vector_shape (uint component_idx=0)

FeQArray< Vector >	grad_scalar_shape (uint component_idx=0)
	Return the value of the `function_no-th` gradient shape function at the `p` bulk quadrature point. More...

FeQArray< Tensor >	grad_vector_shape (uint component_idx=0)
	Return the value of the `function_no-th` gradient vector shape function at the `p` bulk quadrature point. More...

FeQArray< Tensor >	vector_sym_grad (uint component_idx=0)
	Return the value of the `function_no-th` vector symmetric gradient at the `p` bulk quadrature point. More...

FeQArray< Scalar >	vector_divergence (uint component_idx=0)
	Return the value of the `function_no-th` vector divergence at the `p` bulk quadrature point. More...

Private Attributes
PatchPointValues< 3 > *	patch_point_vals_

std::shared_ptr< FiniteElement< dim > >	fe_

Additional Inherited Members
Protected Member Functions inherited from BaseValues< dim >
	BaseValues ()

template<unsigned int FE_dim>
std::shared_ptr< FiniteElement< FE_dim > >	fe_comp (std::shared_ptr< FiniteElement< FE_dim > > fe, uint component_idx)
	Return FiniteElement of `component_idx` for FESystem or `fe` for other types. More...

template<unsigned int FE_dim>
std::vector< std::vector< arma::vec > >	ref_shape_values_bulk (Quadrature *q, std::shared_ptr< FiniteElement< FE_dim >> fe)
	Precomputed values of basis functions at the bulk quadrature points. More...

template<unsigned int FE_dim>
std::vector< std::vector< std::vector< arma::vec > > >	ref_shape_values_side (Quadrature *q, std::shared_ptr< FiniteElement< FE_dim >> fe)
	Precomputed values of basis functions at the side quadrature points. More...

template<unsigned int FE_dim>
std::vector< std::vector< arma::mat > >	ref_shape_gradients_bulk (Quadrature *q, std::shared_ptr< FiniteElement< FE_dim >> fe)
	Precomputed gradients of basis functions at the bulk quadrature points. More...

template<unsigned int FE_dim>
std::vector< std::vector< std::vector< arma::mat > > >	ref_shape_gradients_side (Quadrature *q, std::shared_ptr< FiniteElement< FE_dim >> fe)
	Precomputed gradients of basis functions at the side quadrature points. More...

Detailed Description

template<unsigned int dim>
class BulkValues< dim >

Definition at line 349 of file patch_fe_values.hh.

Constructor & Destructor Documentation

◆ BulkValues()

template<unsigned int dim>

BulkValues< dim >::BulkValues	(	PatchPointValues< 3 > *	patch_point_vals,
		MixedPtr< FiniteElement >	fe
	)

inline

Constructor.

Definition at line 353 of file patch_fe_values.hh.

Member Function Documentation

◆ coords()

template<unsigned int dim>

ElQ<Vector> BulkValues< dim >::coords ( )

inline

Create bulk accessor of coords entity.

Definition at line 371 of file patch_fe_values.hh.

◆ determinant()

template<unsigned int dim>

ElQ<Scalar> BulkValues< dim >::determinant ( )

inline

Create bulk accessor of jac determinant entity.

Definition at line 380 of file patch_fe_values.hh.

◆ grad_scalar_shape()

template<unsigned int dim>

FeQArray<Vector> BulkValues< dim >::grad_scalar_shape ( uint component_idx = 0 )

inline

Return the value of the function_no-th gradient shape function at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 533 of file patch_fe_values.hh.

◆ grad_vector_shape()

template<unsigned int dim>

FeQArray<Tensor> BulkValues< dim >::grad_vector_shape ( uint component_idx = 0 )

inline

Return the value of the function_no-th gradient vector shape function at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 550 of file patch_fe_values.hh.

◆ JxW()

template<unsigned int dim>

FeQ<Scalar> BulkValues< dim >::JxW ( )

inline

Register the product of Jacobian determinant and the quadrature weight at bulk quadrature points.

Parameters

quad	Quadrature.

Definition at line 365 of file patch_fe_values.hh.

◆ ref_scalar()

template<unsigned int dim>

FeQArray<Scalar> BulkValues< dim >::ref_scalar ( uint component_idx = 0 )

inline

Definition at line 385 of file patch_fe_values.hh.

◆ ref_scalar_grad()

template<unsigned int dim>

FeQArray<Vector> BulkValues< dim >::ref_scalar_grad ( uint component_idx = 0 )

inline

Definition at line 429 of file patch_fe_values.hh.

◆ ref_vector()

template<unsigned int dim>

FeQArray<Vector> BulkValues< dim >::ref_vector ( uint component_idx = 0 )

inline

Definition at line 406 of file patch_fe_values.hh.

◆ ref_vector_grad()

template<unsigned int dim>

FeQArray<Tensor> BulkValues< dim >::ref_vector_grad ( uint component_idx = 0 )

inline

Definition at line 451 of file patch_fe_values.hh.

◆ scalar_shape()

template<unsigned int dim>

FeQArray<Scalar> BulkValues< dim >::scalar_shape ( uint component_idx = 0 )

inline

Return the value of the function_no-th shape function at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 481 of file patch_fe_values.hh.

◆ vector_divergence()

template<unsigned int dim>

FeQArray<Scalar> BulkValues< dim >::vector_divergence ( uint component_idx = 0 )

inline

Return the value of the function_no-th vector divergence at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 614 of file patch_fe_values.hh.

◆ vector_shape()

template<unsigned int dim>

FeQArray<Vector> BulkValues< dim >::vector_shape ( uint component_idx = 0 )

inline

Definition at line 492 of file patch_fe_values.hh.

◆ vector_sym_grad()

template<unsigned int dim>

FeQArray<Tensor> BulkValues< dim >::vector_sym_grad ( uint component_idx = 0 )

inline

Return the value of the function_no-th vector symmetric gradient at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 597 of file patch_fe_values.hh.

Member Data Documentation

◆ fe_

template<unsigned int dim>

std::shared_ptr< FiniteElement<dim> > BulkValues< dim >::fe_

private

Definition at line 627 of file patch_fe_values.hh.

◆ patch_point_vals_

template<unsigned int dim>

PatchPointValues<3>* BulkValues< dim >::patch_point_vals_

private

Definition at line 626 of file patch_fe_values.hh.

The documentation for this class was generated from the following file:

/home/runner/work/flow123d/flow123d/src/fem/patch_fe_values.hh
