Bulk Side specialization, order of item in operations_ vector corresponds to the SideOps enum. More...
#include <patch_point_values.hh>
Inheritance diagram for FeSide::PatchPointValues< spacedim >:
Collaboration diagram for FeSide::PatchPointValues< spacedim >:
Public Types | |
| typedef ::PatchPointValues< spacedim >::PatchFeData | PatchFeData |
Public Member Functions | |
| PatchPointValues (uint dim, uint quad_order, PatchFeData &patch_fe_data) | |
| Constructor. More... | |
| ~PatchPointValues () | |
| Destructor. More... | |
| void | create_zero_values () override |
| Create zero_values_ object. More... | |
 Public Member Functions inherited from PatchPointValues< 3 > | |
| PatchPointValues (uint dim, PatchFeData &patch_fe_data) | |
| void | initialize () |
| void | reset () |
| Reset number of columns (points and elements) More... | |
| uint | dim () const |
| Getter for dim_. More... | |
| uint | n_elems () const |
| Getter for n_elems_. More... | |
| uint | n_points () const |
| Getter for n_points_. More... | |
| Quadrature * | get_quadrature () const |
| Getter for quadrature. More... | |
| void | resize_tables (uint n_elems, uint n_points) |
| Resize data tables. Method is called before reinit of patch. More... | |
| uint | register_element (arma::mat coords, uint element_patch_idx) |
| uint | register_side (arma::mat elm_coords, arma::mat side_coords, uint side_idx) |
| uint | register_bulk_point (uint elem_table_row, uint value_patch_idx, uint elem_idx, uint i_point_on_elem) |
| uint | register_side_point (uint elem_table_row, uint value_patch_idx, uint elem_idx, uint side_idx, uint i_point_on_side) |
| PatchOp< spacedim > * | make_new_op (uint op_idx, std::initializer_list< uint > shape, ReinitFunction reinit_f, OpSizeType size_type=pointOp) |
| PatchOp< spacedim > * | make_fixed_op (uint op_idx, std::initializer_list< uint > shape, ReinitFunction reinit_f) |
| PatchOp< spacedim > * | make_fe_op (uint op_idx, std::initializer_list< uint > shape, ReinitFunction reinit_f, uint n_dofs, OpSizeType size_type=pointOp) |
| PatchOp< spacedim > * | make_fixed_fe_op (uint op_idx, std::initializer_list< uint > shape, ReinitFunction reinit_f, uint n_dofs) |
| void | reinit_patch () |
| Scalar | scalar_elem_value (uint op_idx, uint point_idx) const |
| Vector | vector_elem_value (uint op_idx, uint point_idx) const |
| Tensor | tensor_elem_value (uint op_idx, uint point_idx) const |
| Scalar | scalar_value (uint op_idx, uint point_idx, uint i_dof=0) const |
| Vector | vector_value (uint op_idx, uint point_idx, uint i_dof=0) const |
| Tensor | tensor_value (uint op_idx, uint point_idx, uint i_dof=0) const |
| AssemblyArena & | asm_arena () const |
| return reference to assembly arena More... | |
| PatchArena & | patch_arena () const |
| return reference to patch arena More... | |
| void | zero_values_needed () |
| Set flag needs_zero_values_ to true. More... | |
| PatchPointValues * | zero_values () |
| void | print_data_tables (ostream &stream, bool points, bool ints) const |
| void | print_operations (ostream &stream, uint bulk_side) const |
Private Member Functions | |
| PatchPointValues (uint dim, std::vector< PatchOp< spacedim > * > &operations, PatchFeData &patch_fe_data) | |
| Specialized constructor of zero values object. Do not use in other cases! More... | |
| template<unsigned int dim> | |
| void | init () |
| Initialize operations vector. More... | |
Additional Inherited Members | |
| Protected Member Functions inherited from PatchPointValues< 3 > | |
| void | create_zero_operations (std::vector< PatchOp< spacedim > * > &ref_ops) |
| Protected Attributes inherited from PatchPointValues< 3 > | |
| IntTableArena | int_table_ |
| std::vector< OpSizeType > | int_sizes_ |
| Set size and type of rows of int_table_, value is set implicitly in constructor of descendants. More... | |
| std::vector< PatchOp< spacedim > * > | operations_ |
| Vector of all defined operations. More... | |
| std::vector< std::vector< unsigned int > > | op_dependency_ |
| Holds dependency between operations. More... | |
| uint | dim_ |
| Dimension. More... | |
| uint | n_points_ |
| Number of points in patch. More... | |
| uint | n_elems_ |
| Number of elements in patch. More... | |
| uint | i_elem_ |
| Index of registered element in table, helper value used during patch creating. More... | |
| Quadrature * | quad_ |
| Quadrature of given dimension and order passed in constructor. More... | |
| std::vector< uint > | elements_map_ |
| Map of element patch indices to PatchOp::result_ and int_table_ tables. More... | |
| std::vector< uint > | points_map_ |
| Map of point patch indices to PatchOp::result_ and int_table_ tables. More... | |
| PatchFeData & | patch_fe_data_ |
| Reference to PatchFeData structure shared with PatchFeValues. More... | |
| bool | needs_zero_values_ |
| Flags hold whether zero_values_ object is needed. More... | |
| PatchPointValues * | zero_values_ |
| PatchPointValues object returns zero values for all operations. More... | |
Detailed Description
template<unsigned int spacedim = 3>
class FeSide::PatchPointValues< spacedim >
Bulk Side specialization, order of item in operations_ vector corresponds to the SideOps enum.
Definition at line 1241 of file patch_point_values.hh.
Member Typedef Documentation
◆ PatchFeData
template<unsigned int spacedim = 3>
| typedef ::PatchPointValues<spacedim>::PatchFeData FeSide::PatchPointValues< spacedim >::PatchFeData |
Definition at line 1243 of file patch_point_values.hh.
Constructor & Destructor Documentation
◆ PatchPointValues() [1/2]
template<unsigned int spacedim = 3>
|
inline |
Constructor.
Definition at line 1246 of file patch_point_values.hh.
Here is the caller graph for this function:
◆ ~PatchPointValues()
template<unsigned int spacedim = 3>
|
inlinevirtual |
Destructor.
Reimplemented from PatchPointValues< 3 >.
Definition at line 1285 of file patch_point_values.hh.
◆ PatchPointValues() [2/2]
template<unsigned int spacedim = 3>
|
inlineprivate |
Specialized constructor of zero values object. Do not use in other cases!
Definition at line 1294 of file patch_point_values.hh.
Member Function Documentation
◆ create_zero_values()
template<unsigned int spacedim = 3>
|
inlineoverridevirtual |
Create zero_values_ object.
Implements PatchPointValues< 3 >.
Definition at line 1288 of file patch_point_values.hh.
◆ init()
template<unsigned int spacedim = 3>
template<unsigned int dim>
|
inlineprivate |
Initialize operations vector.
Definition at line 1302 of file patch_point_values.hh.
The documentation for this class was generated from the following file:
- /home/runner/work/flow123d/flow123d/src/fem/patch_point_values.hh
