Class represents element or FE operations. More...

#include <patch_point_values.hh>

Collaboration diagram for PatchOp< spacedim >:

Public Member Functions
	PatchOp (uint dim, std::initializer_list< uint > shape, ReinitFunction reinit_f, OpSizeType size_type, std::vector< PatchOp< spacedim > * > input_ops={}, uint n_dofs=1)

std::vector< uint >	set_shape_vec (std::initializer_list< uint > shape) const
	Aligns shape_vec to 2 items (equal to matrix number of dimensions) More...

uint	n_comp () const

uint	dim () const
	Getter for dimension. More...

OpSizeType	size_type () const
	Getter for size_type_. More...

uint	n_dofs () const
	Getter for n_dofs_. More...

PatchOp< spacedim > *	input_ops (uint i_op) const
	Return pointer to operation of i_op index in input operation vector. More...

const std::vector< uint > &	shape () const
	Getter for shape_. More...

std::string	format_shape () const

void	reinit_function (FMT_UNUSED std::vector< PatchOp< spacedim > * > &operations, IntTableArena &int_table)
	Call reinit function on element table if function is defined. More...

void	allocate_result (size_t data_size, PatchArena &arena)

void	allocate_const_result (ArenaVec< double > &value_vec)

Eigen::Map< Eigen::Matrix< ArenaVec< double >, Eigen::Dynamic, Eigen::Dynamic > >	result_matrix ()
	Return map referenced result as Eigen::Vector. More...

Eigen::Map< Eigen::Matrix< ArenaVec< double >, Eigen::Dynamic, Eigen::Dynamic > >	result_sub_matrix (uint i_dof)
	Return map referenced result of DOF values as Eigen::Matrix. More...

Eigen::Vector< ArenaVec< double >, Eigen::Dynamic > &	raw_result ()
	Return map referenced result as Eigen::Vector. More...

const Eigen::Vector< ArenaVec< double >, Eigen::Dynamic > &	raw_result () const
	Same as previous but return const reference. More...

Protected Attributes
uint	dim_
	Dimension. More...

std::vector< uint >	shape_
	Shape of stored data (size of vector or number of rows and cols of matrix) More...

Eigen::Vector< ArenaVec< double >, Eigen::Dynamic >	result_
	Result matrix of operation. More...

OpSizeType	size_type_
	Type of operation by size of vector (element, point or fixed size) More...

std::vector< PatchOp< spacedim > * >	input_ops_
	Indices of operations in PatchPointValues::operations_ vector on which PatchOp is depended. More...

uint	n_dofs_
	Number of DOFs of FE operations (or 1 in case of element operations) More...

ReinitFunction	reinit_func
	Pointer to patch reinit function of element data table specialized by operation. More...

Detailed Description

template<unsigned int spacedim = 3>
class PatchOp< spacedim >

Class represents element or FE operations.

Definition at line 639 of file patch_point_values.hh.

Constructor & Destructor Documentation

◆ PatchOp()

template<unsigned int spacedim = 3>

PatchOp< spacedim >::PatchOp	(	uint	dim,
		std::initializer_list< uint >	shape,
		ReinitFunction	reinit_f,
		OpSizeType	size_type,
		std::vector< PatchOp< spacedim > * >	input_ops = `{}`,
		uint	n_dofs = `1`
	)

inline

Constructor

Set all data members.

Definition at line 646 of file patch_point_values.hh.

Member Function Documentation

◆ allocate_const_result()

template<unsigned int spacedim = 3>

void PatchOp< spacedim >::allocate_const_result ( ArenaVec< double > & value_vec )

inline

Definition at line 716 of file patch_point_values.hh.

◆ allocate_result()

template<unsigned int spacedim = 3>

void PatchOp< spacedim >::allocate_result	(	size_t	data_size,
		PatchArena &	arena
	)

inline

Definition at line 710 of file patch_point_values.hh.

◆ dim()

template<unsigned int spacedim = 3>

uint PatchOp< spacedim >::dim ( ) const

inline

Getter for dimension.

Definition at line 670 of file patch_point_values.hh.

◆ format_shape()

template<unsigned int spacedim = 3>

std::string PatchOp< spacedim >::format_shape ( ) const

inline

Format shape to string

Method is used in output development method.

Definition at line 699 of file patch_point_values.hh.

◆ input_ops()

template<unsigned int spacedim = 3>

PatchOp<spacedim>* PatchOp< spacedim >::input_ops ( uint i_op ) const

inline

Return pointer to operation of i_op index in input operation vector.

Definition at line 685 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ n_comp()

template<unsigned int spacedim = 3>

uint PatchOp< spacedim >::n_comp ( ) const

inline

Return number of operation components

Value is computed from shape_ vector

Definition at line 665 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ n_dofs()

template<unsigned int spacedim = 3>

uint PatchOp< spacedim >::n_dofs ( ) const

inline

Getter for n_dofs_.

Definition at line 680 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ raw_result() [1/2]

template<unsigned int spacedim = 3>

Eigen::Vector<ArenaVec<double>, Eigen::Dynamic>& PatchOp< spacedim >::raw_result ( )

inline

Return map referenced result as Eigen::Vector.

Definition at line 735 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ raw_result() [2/2]

template<unsigned int spacedim = 3>

const Eigen::Vector<ArenaVec<double>, Eigen::Dynamic>& PatchOp< spacedim >::raw_result ( ) const

inline

Same as previous but return const reference.

Definition at line 740 of file patch_point_values.hh.

◆ reinit_function()

template<unsigned int spacedim = 3>

void PatchOp< spacedim >::reinit_function	(	FMT_UNUSED std::vector< PatchOp< spacedim > * > &	operations,
		IntTableArena &	int_table
	)

inline

Call reinit function on element table if function is defined.

Definition at line 706 of file patch_point_values.hh.

◆ result_matrix()

template<unsigned int spacedim = 3>

Eigen::Map<Eigen::Matrix<ArenaVec<double>, Eigen::Dynamic, Eigen::Dynamic> > PatchOp< spacedim >::result_matrix ( )

inline

Return map referenced result as Eigen::Vector.

Definition at line 723 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ result_sub_matrix()

template<unsigned int spacedim = 3>

Eigen::Map<Eigen::Matrix<ArenaVec<double>, Eigen::Dynamic, Eigen::Dynamic> > PatchOp< spacedim >::result_sub_matrix ( uint i_dof )

inline

Return map referenced result of DOF values as Eigen::Matrix.

Definition at line 728 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ set_shape_vec()

template<unsigned int spacedim = 3>

std::vector<uint> PatchOp< spacedim >::set_shape_vec ( std::initializer_list< uint > shape ) const

inline

Aligns shape_vec to 2 items (equal to matrix number of dimensions)

Definition at line 653 of file patch_point_values.hh.

◆ shape()

template<unsigned int spacedim = 3>

const std::vector<uint>& PatchOp< spacedim >::shape ( ) const

inline

Getter for shape_.

Definition at line 690 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ size_type()

template<unsigned int spacedim = 3>

OpSizeType PatchOp< spacedim >::size_type ( ) const

inline

Getter for size_type_.

Definition at line 675 of file patch_point_values.hh.

Member Data Documentation

◆ dim_

template<unsigned int spacedim = 3>

uint PatchOp< spacedim >::dim_

protected

Dimension.

Definition at line 746 of file patch_point_values.hh.

◆ input_ops_

template<unsigned int spacedim = 3>

std::vector<PatchOp<spacedim> *> PatchOp< spacedim >::input_ops_

protected

Indices of operations in PatchPointValues::operations_ vector on which PatchOp is depended.

Definition at line 750 of file patch_point_values.hh.

◆ n_dofs_

template<unsigned int spacedim = 3>

uint PatchOp< spacedim >::n_dofs_

protected

Number of DOFs of FE operations (or 1 in case of element operations)

Definition at line 751 of file patch_point_values.hh.

◆ reinit_func

template<unsigned int spacedim = 3>

ReinitFunction PatchOp< spacedim >::reinit_func

protected

Pointer to patch reinit function of element data table specialized by operation.

Definition at line 753 of file patch_point_values.hh.

◆ result_

template<unsigned int spacedim = 3>

Eigen::Vector<ArenaVec<double>, Eigen::Dynamic> PatchOp< spacedim >::result_

protected

Result matrix of operation.

Definition at line 748 of file patch_point_values.hh.

◆ shape_

template<unsigned int spacedim = 3>

std::vector<uint> PatchOp< spacedim >::shape_

protected

Shape of stored data (size of vector or number of rows and cols of matrix)

Definition at line 747 of file patch_point_values.hh.

◆ size_type_

template<unsigned int spacedim = 3>

OpSizeType PatchOp< spacedim >::size_type_

protected

Type of operation by size of vector (element, point or fixed size)

Definition at line 749 of file patch_point_values.hh.

The documentation for this class was generated from the following file:

/home/runner/work/flow123d/flow123d/src/fem/patch_point_values.hh
