#include <patch_fe_values.hh>

Collaboration diagram for PatchFEValues< spacedim >:

[legend]

Classes
struct	TableSizes
	Struct for pre-computing number of elements, sides, bulk points and side points on each dimension. More...

Public Types
typedef PatchPointValues< spacedim >::PatchFeData	PatchFeData

Public Member Functions
	PatchFEValues ()

	PatchFEValues (unsigned int quad_order, MixedPtr< FiniteElement > fe)

	~PatchFEValues ()
	Destructor. More...

Quadrature *	get_quadrature (uint dim, bool is_bulk) const
	Return bulk or side quadrature of given dimension. More...

template<unsigned int DIM>
void	initialize (Quadrature &_quadrature)
	Initialize structures and calculates cell-independent data. More...

void	init_finalize ()
	Finalize initialization, creates child (patch) arena and passes it to PatchPointValue objects. More...

void	reset ()
	Reset PatchpointValues structures. More...

void	reinit_patch ()
	Reinit data. More...

template<unsigned int dim>
unsigned int	n_dofs () const
	Returns the number of shape functions. More...

template<unsigned int dim>
BulkValues< dim >	bulk_values ()
	Return BulkValue object of dimension given by template parameter. More...

template<unsigned int dim>
SideValues< dim >	side_values ()
	Return SideValue object of dimension given by template parameter. More...

template<unsigned int dim>
JoinValues< dim >	join_values ()
	Return JoinValue object of dimension given by template parameter. More...

void	resize_tables (TableSizes table_sizes)
	Resize tables of patch_point_vals_. More...

uint	register_element (DHCellAccessor cell, uint element_patch_idx)
	Register element to patch_point_vals_ table by dimension of element. More...

uint	register_side (DHCellSide cell_side)
	Register side to patch_point_vals_ table by dimension of side. More...

uint	register_bulk_point (DHCellAccessor cell, uint elem_table_row, uint value_patch_idx, uint i_point_on_elem)
	Register bulk point to patch_point_vals_ table by dimension of element. More...

uint	register_side_point (DHCellSide cell_side, uint elem_table_row, uint value_patch_idx, uint i_point_on_side)
	Register side point to patch_point_vals_ table by dimension of side. More...

void	print_data_tables (ostream &stream, bool points, bool ints, bool only_bulk=true) const
	Temporary development method. More...

void	print_operations (ostream &stream) const
	Temporary development method. More...

Private Attributes
PatchFeData	patch_fe_data_

std::array< FeBulk::PatchPointValues< spacedim >, 3 >	patch_point_vals_bulk_
	Sub objects of bulk data of dimensions 1,2,3. More...

std::array< FeSide::PatchPointValues< spacedim >, 3 >	patch_point_vals_side_
	Sub objects of side data of dimensions 1,2,3. More...

MixedPtr< FiniteElement >	fe_
	Mixed of shared pointers of FiniteElement object. More...

bool	used_quads_ [2]
	Pair of flags signs holds info if bulk and side quadratures are used. More...

Friends
template<class ValueType >
class	ElQ

template<class ValueType >
class	FeQ

Detailed Description

template<unsigned int spacedim = 3>
class PatchFEValues< spacedim >

Definition at line 1079 of file patch_fe_values.hh.

Member Typedef Documentation

◆ PatchFeData

template<unsigned int spacedim = 3>

typedef PatchPointValues<spacedim>::PatchFeData PatchFEValues< spacedim >::PatchFeData

Definition at line 1081 of file patch_fe_values.hh.

Constructor & Destructor Documentation

◆ PatchFEValues() [1/2]

template<unsigned int spacedim = 3>

PatchFEValues< spacedim >::PatchFEValues ( )

inline

Definition at line 1125 of file patch_fe_values.hh.

◆ PatchFEValues() [2/2]

template<unsigned int spacedim = 3>

PatchFEValues< spacedim >::PatchFEValues	(	unsigned int	quad_order,
		MixedPtr< FiniteElement >	fe
	)

inline

Definition at line 1137 of file patch_fe_values.hh.

◆ ~PatchFEValues()

template<unsigned int spacedim = 3>

PatchFEValues< spacedim >::~PatchFEValues ( )

inline

Destructor.

Definition at line 1157 of file patch_fe_values.hh.

Member Function Documentation

◆ bulk_values()

template<unsigned int spacedim = 3>

template<unsigned int dim>

BulkValues<dim> PatchFEValues< spacedim >::bulk_values ( )

inline

Return BulkValue object of dimension given by template parameter.

Definition at line 1220 of file patch_fe_values.hh.

◆ get_quadrature()

template<unsigned int spacedim = 3>

Quadrature* PatchFEValues< spacedim >::get_quadrature	(	uint	dim,
		bool	is_bulk
	)		const

inline

Return bulk or side quadrature of given dimension.

Definition at line 1161 of file patch_fe_values.hh.

Here is the caller graph for this function:

◆ init_finalize()

template<unsigned int spacedim = 3>

void PatchFEValues< spacedim >::init_finalize ( )

inline

Finalize initialization, creates child (patch) arena and passes it to PatchPointValue objects.

Definition at line 1186 of file patch_fe_values.hh.

Here is the caller graph for this function:

◆ initialize()

template<unsigned int spacedim = 3>

template<unsigned int DIM>

void PatchFEValues< spacedim >::initialize ( Quadrature & _quadrature )

inline

Initialize structures and calculates cell-independent data.

Parameters

_quadrature	The quadrature rule for the cell associated to given finite element or for the cell side.
_flags	The update flags.

Definition at line 1174 of file patch_fe_values.hh.

◆ join_values()

template<unsigned int spacedim = 3>

template<unsigned int dim>

JoinValues<dim> PatchFEValues< spacedim >::join_values ( )

inline

Return JoinValue object of dimension given by template parameter.

Definition at line 1234 of file patch_fe_values.hh.

◆ n_dofs()

template<unsigned int spacedim = 3>

template<unsigned int dim>

unsigned int PatchFEValues< spacedim >::n_dofs ( ) const

inline

Returns the number of shape functions.

Definition at line 1213 of file patch_fe_values.hh.

◆ print_data_tables()

template<unsigned int spacedim = 3>

void PatchFEValues< spacedim >::print_data_tables	(	ostream &	stream,
		bool	points,
		bool	ints,
		bool	only_bulk = `true`
	)		const

inline

Temporary development method.

Definition at line 1313 of file patch_fe_values.hh.

◆ print_operations()

template<unsigned int spacedim = 3>

void PatchFEValues< spacedim >::print_operations ( ostream & stream ) const

inline

Temporary development method.

Definition at line 1330 of file patch_fe_values.hh.

◆ register_bulk_point()

template<unsigned int spacedim = 3>

uint PatchFEValues< spacedim >::register_bulk_point	(	DHCellAccessor	cell,
		uint	elem_table_row,
		uint	value_patch_idx,
		uint	i_point_on_elem
	)

inline

Register bulk point to patch_point_vals_ table by dimension of element.

Definition at line 1302 of file patch_fe_values.hh.

Here is the caller graph for this function:

◆ register_element()

template<unsigned int spacedim = 3>

uint PatchFEValues< spacedim >::register_element	(	DHCellAccessor	cell,
		uint	element_patch_idx
	)

inline

Register element to patch_point_vals_ table by dimension of element.

Definition at line 1250 of file patch_fe_values.hh.

Here is the caller graph for this function:

◆ register_side()

template<unsigned int spacedim = 3>

uint PatchFEValues< spacedim >::register_side ( DHCellSide cell_side )

inline

Register side to patch_point_vals_ table by dimension of side.

Definition at line 1273 of file patch_fe_values.hh.

Here is the caller graph for this function:

◆ register_side_point()

template<unsigned int spacedim = 3>

uint PatchFEValues< spacedim >::register_side_point	(	DHCellSide	cell_side,
		uint	elem_table_row,
		uint	value_patch_idx,
		uint	i_point_on_side
	)

inline

Register side point to patch_point_vals_ table by dimension of side.

Definition at line 1307 of file patch_fe_values.hh.

Here is the caller graph for this function:

◆ reinit_patch()

template<unsigned int spacedim = 3>

void PatchFEValues< spacedim >::reinit_patch ( )

inline

Reinit data.

Definition at line 1201 of file patch_fe_values.hh.

Here is the caller graph for this function:

◆ reset()

template<unsigned int spacedim = 3>

void PatchFEValues< spacedim >::reset ( )

inline

Reset PatchpointValues structures.

Definition at line 1191 of file patch_fe_values.hh.

Here is the caller graph for this function:

◆ resize_tables()

template<unsigned int spacedim = 3>

void PatchFEValues< spacedim >::resize_tables ( TableSizes table_sizes )

inline

Resize tables of patch_point_vals_.

Following methods are used during update of patch.

Definition at line 1242 of file patch_fe_values.hh.

Here is the caller graph for this function:

◆ side_values()

template<unsigned int spacedim = 3>

template<unsigned int dim>

SideValues<dim> PatchFEValues< spacedim >::side_values ( )

inline

Return SideValue object of dimension given by template parameter.

Definition at line 1227 of file patch_fe_values.hh.

Friends And Related Function Documentation

◆ ElQ

template<unsigned int spacedim = 3>

template<class ValueType >

friend class ElQ

friend

Definition at line 1354 of file patch_fe_values.hh.

◆ FeQ

template<unsigned int spacedim = 3>

template<class ValueType >

friend class FeQ

friend

Definition at line 1356 of file patch_fe_values.hh.

Member Data Documentation

◆ fe_

template<unsigned int spacedim = 3>

MixedPtr<FiniteElement> PatchFEValues< spacedim >::fe_

private

Mixed of shared pointers of FiniteElement object.

Definition at line 1350 of file patch_fe_values.hh.

◆ patch_fe_data_

template<unsigned int spacedim = 3>

PatchFeData PatchFEValues< spacedim >::patch_fe_data_

private

Definition at line 1346 of file patch_fe_values.hh.

◆ patch_point_vals_bulk_

template<unsigned int spacedim = 3>

std::array<FeBulk::PatchPointValues<spacedim>, 3> PatchFEValues< spacedim >::patch_point_vals_bulk_

private

Sub objects of bulk data of dimensions 1,2,3.

Definition at line 1347 of file patch_fe_values.hh.

◆ patch_point_vals_side_

template<unsigned int spacedim = 3>

std::array<FeSide::PatchPointValues<spacedim>, 3> PatchFEValues< spacedim >::patch_point_vals_side_

private

Sub objects of side data of dimensions 1,2,3.

Definition at line 1348 of file patch_fe_values.hh.

◆ used_quads_

template<unsigned int spacedim = 3>

bool PatchFEValues< spacedim >::used_quads_[2]

private

Pair of flags signs holds info if bulk and side quadratures are used.

Definition at line 1351 of file patch_fe_values.hh.

The documentation for this class was generated from the following files:

/home/runner/work/flow123d/flow123d/src/fem/finite_element.hh
/home/runner/work/flow123d/flow123d/src/fem/patch_fe_values.hh
