Mixed-hybrid of steady Darcy flow with sources and variable density. More...

#include <darcy_flow_mh.hh>

Inheritance diagram for DarcyFlowMH_Steady:

Collaboration diagram for DarcyFlowMH_Steady:

Classes
class	EqData

Public Member Functions
	DarcyFlowMH_Steady (Mesh &mesh, const Input::Record in_rec, bool make_tg=true)
	CREATE AND FILL GLOBAL MH MATRIX OF THE WATER MODEL. More...

virtual void	update_solution ()

virtual void	get_solution_vector (double *&vec, unsigned int &vec_size)

virtual void	get_parallel_solution_vector (Vec &vector)

void	get_partitioning_vector (int *&elem_part, unsigned &lelem_part)

virtual void	postprocess ()
	postprocess velocity field (add sources) More...

virtual void	output_data () override
	Write computed fields. More...

	~DarcyFlowMH_Steady ()

Public Member Functions inherited from DarcyFlowMH
	DarcyFlowMH (Mesh &mesh, const Input::Record in_rec)

void	get_velocity_seq_vector (Vec &velocity_vec)

const MH_DofHandler &	get_mh_dofhandler ()

virtual void	set_concentration_vector (Vec &vc)

Public Member Functions inherited from EquationBase
	EquationBase ()

	EquationBase (Mesh &mesh, const Input::Record in_rec)

virtual	~EquationBase ()

virtual void	zero_time_step ()

virtual void	initialize ()
	Initialize fields. More...

virtual void	choose_next_time ()

virtual void	set_time_upper_constraint (double dt)

virtual void	set_time_lower_constraint (double dt)

TimeGovernor const &	time ()

virtual void	set_time_governor (TimeGovernor &time)

double	planned_time ()

double	solved_time ()

Mesh &	mesh ()

TimeMark::Type	mark_type ()

FieldSet &	data ()

Static Public Attributes
static Input::Type::Record	input_type

Static Public Attributes inherited from DarcyFlowMH
static Input::Type::Selection	mh_mortar_selection

static Input::Type::AbstractRecord	input_type

static Input::Type::Record	bc_segment_rec

static Input::Type::AbstractRecord	bc_input_type

static std::vector < Input::Type::Record >	bc_input_types

Protected Member Functions
void	make_serial_scatter ()

virtual void	modify_system ()

virtual void	setup_time_term ()

void	prepare_parallel (const Input::AbstractRecord in_rec)

void	make_row_numberings ()

void	create_linear_system ()

virtual void	read_init_condition ()

void	assembly_steady_mh_matrix ()

void	assembly_linear_system ()

void	set_mesh_data_for_bddc (LinSys_BDDC *bddc_ls)

double	solution_precision () const

Protected Member Functions inherited from DarcyFlowMH
void	setup_velocity_vector ()

Protected Attributes
DarcyFlowMHOutput *	output_object

int	size

int	n_schur_compls

double *	solution

LinSys *	schur0

Distribution *	edge_ds

Distribution *	el_ds

Distribution *	side_ds

boost::shared_ptr< Distribution >	rows_ds

int *	el_4_loc

int *	row_4_el

int *	side_id_4_loc

int *	side_row_4_id

int *	edge_4_loc

int *	row_4_edge

std::vector< double >	solution_

std::vector< unsigned >	solver_indices_

boost::shared_ptr < LocalToGlobalMap >	global_row_4_sub_row

Vec	sol_vec

VecScatter	par_to_all

EqData	data_

Protected Attributes inherited from DarcyFlowMH
bool	solution_changed_for_scatter

Vec	velocity_vector

MH_DofHandler	mh_dh

MortarMethod	mortar_method_

Protected Attributes inherited from EquationBase
bool	equation_empty_
	flag is true if only default constructor was called More...

Mesh *	mesh_

TimeGovernor *	time_

Input::Record	input_record_

FieldSet *	eq_data_

Friends
class	DarcyFlowMHOutput

class	P0_CouplingAssembler

class	P1_CouplingAssembler

Additional Inherited Members
Public Types inherited from DarcyFlowMH
enum	MortarMethod { NoMortar = 0, MortarP0 = 1, MortarP1 = 2 }

Detailed Description

Mixed-hybrid of steady Darcy flow with sources and variable density.

solve equations:

$q= -{\mathbf{K}} \nabla h -{\mathbf{K}} R \nabla z$

$\mathrm{div} q = f$

where

is flux $[ms^{-1}]$ for 3d, $[m^2s^{-1}]$ for 2d and $[m^3s^{-1}]$ for 1d.
$\mathbf{K}$ is hydraulic tensor ( its orientation for 2d, 1d case is questionable )
$h = \frac{\pi}{\rho_0 g}+z$ is pressure head, $\pi, \rho_0, g$ are the pressure, water density, and acceleration of gravity , respectively. Assumes gravity force acts counter to the direction of the axis.
is destity or gravity variability coefficient. For density driven flow it should be

$R = \frac{\rho}{\rho_0} -1 = \rho_0^{-1}\sum_{i=1}^s c_i$

where is concentration in $kg m^{-3}$ .

TODO:
- consider create auxiliary classes for creation of inverse of block A

Definition at line 263 of file darcy_flow_mh.hh.

Constructor & Destructor Documentation

DarcyFlowMH_Steady::DarcyFlowMH_Steady	(	Mesh &	mesh_in,
		const Input::Record	in_rec,
		bool	make_tg = `true`
	)

CREATE AND FILL GLOBAL MH MATRIX OF THE WATER MODEL.

Parameters {Solver,NSchurs} number of performed Schur complements (0,1,2) for water flow MH-system

Definition at line 196 of file darcy_flow_mh.cc.

DarcyFlowMH_Steady::~DarcyFlowMH_Steady ( )

Definition at line 1208 of file darcy_flow_mh.cc.

Member Function Documentation

void DarcyFlowMH_Steady::assembly_linear_system ( )

protected

Assembly or update whole linear system.

Definition at line 984 of file darcy_flow_mh.cc.

Here is the caller graph for this function:

void DarcyFlowMH_Steady::assembly_steady_mh_matrix ( )

protected

Abstract assembly method used for both assembly and preallocation. Assembly only steady part of the equation. TODO:

use general preallocation methods in DofHandler
include alos time term
add support for Robin type sources
support for nonlinear solvers - assembly either residual vector, matrix, or both (using FADBAD++)

Definition at line 386 of file darcy_flow_mh.cc.

Here is the caller graph for this function:

void DarcyFlowMH_Steady::create_linear_system ( )

protected

Create and preallocate MH linear system (including matrix, rhs and solution vectors)

Definition at line 873 of file darcy_flow_mh.cc.

Here is the caller graph for this function:

void DarcyFlowMH_Steady::get_parallel_solution_vector ( Vec & vector)

virtual

Child class have to implement getter for parallel solution vector. DEPRECATED

Reimplemented from EquationBase.

Definition at line 362 of file darcy_flow_mh.cc.

void DarcyFlowMH_Steady::get_partitioning_vector	(	int *&	elem_part,
		unsigned &	lelem_part
	)

virtual

Reimplemented from DarcyFlowMH.

Definition at line 354 of file darcy_flow_mh.cc.

void DarcyFlowMH_Steady::get_solution_vector	(	double *&	vector,
		unsigned int &	size
	)

virtual

Child class have to implement getter for sequential solution vector. DEPRECATED

Reimplemented from EquationBase.

Definition at line 327 of file darcy_flow_mh.cc.

Here is the caller graph for this function:

void DarcyFlowMH_Steady::make_row_numberings ( )

protected

Make connectivity graph of the second Schur complement and compute optimal partitioning. This verison assign 1D and 2D edges to one processor, represent them as a weighted vertex, and 2D-3D neghbourings as weighted edges. 3D edges are then distributed over all procesors. Make connectivity graph of elements of mesh - dual graph: elements vertices of graph.

Definition at line 1368 of file darcy_flow_mh.cc.

Here is the caller graph for this function:

void DarcyFlowMH_Steady::make_serial_scatter ( )

protected

Definition at line 1416 of file darcy_flow_mh.cc.

virtual void DarcyFlowMH_Steady::modify_system ( )

inlineprotectedvirtual

Reimplemented in DarcyFlowLMH_Unsteady, and DarcyFlowMH_Unsteady.

Definition at line 292 of file darcy_flow_mh.hh.

Here is the caller graph for this function:

void DarcyFlowMH_Steady::output_data ( void )

overridevirtual

Write computed fields.

Reimplemented from EquationBase.

Definition at line 316 of file darcy_flow_mh.cc.

Here is the caller graph for this function:

void DarcyFlowMH_Steady::postprocess ( )

virtual

postprocess velocity field (add sources)

Reimplemented in DarcyFlowLMH_Unsteady.

Definition at line 289 of file darcy_flow_mh.cc.

Here is the caller graph for this function:

void DarcyFlowMH_Steady::prepare_parallel ( const Input::AbstractRecord in_rec)

protected

Definition at line 1462 of file darcy_flow_mh.cc.

Here is the caller graph for this function:

virtual void DarcyFlowMH_Steady::read_init_condition ( )

inlineprotectedvirtual

Read initial condition into solution vector. Must be called after create_linear_system.

Reimplemented in DarcyFlowLMH_Unsteady, and DarcyFlowMH_Unsteady.

Definition at line 312 of file darcy_flow_mh.hh.

void DarcyFlowMH_Steady::set_mesh_data_for_bddc ( LinSys_BDDC * bddc_ls)

protected

type for storage of global to local map

Definition at line 1035 of file darcy_flow_mh.cc.

Here is the caller graph for this function:

virtual void DarcyFlowMH_Steady::setup_time_term ( )

inlineprotectedvirtual

Reimplemented in DarcyFlowLMH_Unsteady, and DarcyFlowMH_Unsteady.

Definition at line 294 of file darcy_flow_mh.hh.

Here is the caller graph for this function:

double DarcyFlowMH_Steady::solution_precision ( ) const

protectedvirtual

Implements DarcyFlowMH.

Definition at line 321 of file darcy_flow_mh.cc.

void DarcyFlowMH_Steady::update_solution ( void )

virtual

Calculation of the next time step and its output.

Reimplemented from EquationBase.

Definition at line 262 of file darcy_flow_mh.cc.

Friends And Related Function Documentation

friend class DarcyFlowMHOutput

friend

Definition at line 371 of file darcy_flow_mh.hh.

friend class P0_CouplingAssembler

friend

Definition at line 372 of file darcy_flow_mh.hh.

friend class P1_CouplingAssembler

friend

Definition at line 373 of file darcy_flow_mh.hh.

Member Data Documentation

EqData DarcyFlowMH_Steady::data_

protected

Definition at line 369 of file darcy_flow_mh.hh.

int* DarcyFlowMH_Steady::edge_4_loc

protected

Definition at line 357 of file darcy_flow_mh.hh.

Distribution* DarcyFlowMH_Steady::edge_ds

protected

Definition at line 348 of file darcy_flow_mh.hh.

int* DarcyFlowMH_Steady::el_4_loc

protected

Definition at line 353 of file darcy_flow_mh.hh.

Distribution* DarcyFlowMH_Steady::el_ds

protected

Definition at line 349 of file darcy_flow_mh.hh.

boost::shared_ptr<LocalToGlobalMap> DarcyFlowMH_Steady::global_row_4_sub_row

protected

Definition at line 363 of file darcy_flow_mh.hh.

it::Record DarcyFlowMH_Steady::input_type

static

Initial value:

= it::Record("Steady_MH", "Mixed-Hybrid  solver for STEADY saturated Darcy flow.")
    .derive_from(DarcyFlowMH::input_type)
    .declare_key("input_fields", it::Array(
                DarcyFlowMH_Steady::EqData().make_field_descriptor_type("DarcyFlowMH")
                .declare_key("bc_piezo_head", FieldBase< 3, FieldValue<3>::Scalar >::get_input_type(), "Boundary condition for pressure as piezometric head." )
                .declare_key("init_piezo_head", FieldBase< 3, FieldValue<3>::Scalar >::get_input_type(), "Initial condition for pressure as piezometric head." )
                .declare_key(OldBcdInput::flow_old_bcd_file_key(), it::FileName::input(), "File with mesh dependent boundary conditions (obsolete).")
                ), it::Default::obligatory(), ""  )

Definition at line 276 of file darcy_flow_mh.hh.

int DarcyFlowMH_Steady::n_schur_compls

protected

Definition at line 338 of file darcy_flow_mh.hh.

DarcyFlowMHOutput* DarcyFlowMH_Steady::output_object

protected

Definition at line 335 of file darcy_flow_mh.hh.

VecScatter DarcyFlowMH_Steady::par_to_all

protected

Definition at line 367 of file darcy_flow_mh.hh.

int* DarcyFlowMH_Steady::row_4_edge

protected

Definition at line 358 of file darcy_flow_mh.hh.

int* DarcyFlowMH_Steady::row_4_el

protected

Definition at line 354 of file darcy_flow_mh.hh.

boost::shared_ptr<Distribution> DarcyFlowMH_Steady::rows_ds

protected

Definition at line 351 of file darcy_flow_mh.hh.

LinSys* DarcyFlowMH_Steady::schur0

protected

Definition at line 342 of file darcy_flow_mh.hh.

Distribution* DarcyFlowMH_Steady::side_ds

protected

Definition at line 350 of file darcy_flow_mh.hh.

int* DarcyFlowMH_Steady::side_id_4_loc

protected

Definition at line 355 of file darcy_flow_mh.hh.

int* DarcyFlowMH_Steady::side_row_4_id

protected

Definition at line 356 of file darcy_flow_mh.hh.

int DarcyFlowMH_Steady::size

protected

Definition at line 337 of file darcy_flow_mh.hh.

Vec DarcyFlowMH_Steady::sol_vec

protected

Definition at line 366 of file darcy_flow_mh.hh.

double* DarcyFlowMH_Steady::solution

protected

Definition at line 339 of file darcy_flow_mh.hh.

std::vector<double> DarcyFlowMH_Steady::solution_

protected

Definition at line 361 of file darcy_flow_mh.hh.

std::vector<unsigned> DarcyFlowMH_Steady::solver_indices_

protected

Definition at line 362 of file darcy_flow_mh.hh.

The documentation for this class was generated from the following files:

/home/jb/workspace/flow123d/src/flow/darcy_flow_mh.hh
/home/jb/workspace/flow123d/src/flow/darcy_flow_mh.cc

Classes

Public Member Functions

Static Public Attributes

Protected Member Functions

Protected Attributes

Friends

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Friends And Related Function Documentation

Member Data Documentation
