#include <darcy_flow_mh_output.hh>

Collaboration diagram for DarcyFlowMHOutput:

Classes
class	OutputFields

Public Member Functions
	DarcyFlowMHOutput (DarcyFlowMH_Steady *flow, Input::Record in_rec)

	~DarcyFlowMHOutput ()

void	output ()
	Calculate values for output. More...

Static Public Attributes
static Input::Type::Record	input_type

Private Member Functions
void	make_side_flux ()

void	make_element_scalar ()

void	make_element_vector ()

void	make_sides_scalar ()

void	make_node_scalar_param ()
	Calculate nodes scalar, store it in double* node_scalars instead of node->scalar. More...

void	make_node_scalar ()

void	make_corner_scalar (vector< double > &node_scalar)

void	make_neighbour_flux ()

void	output_internal_flow_data ()

void	compute_l2_difference ()

void	water_balance ()

double	calc_water_balance ()

Private Attributes
DarcyFlowMH_Steady *	darcy_flow

Mesh *	mesh_

Input::Record	in_rec_
	Accessor to the input record for the DarcyFlow output. More...

vector< double >	corner_pressure

vector< double >	ele_pressure

vector< double >	ele_piezo_head

vector< double >	subdomains

vector< double >	ele_flux

std::vector< double >	l2_diff_pressure

std::vector< double >	l2_diff_velocity

std::vector< double >	l2_diff_divergence

Vec	vec_corner_pressure

DOFHandlerMultiDim *	dh

MappingP1< 1, 3 >	map1

MappingP1< 2, 3 >	map2

MappingP1< 3, 3 >	map3

FE_P_disc< 1, 1, 3 >	fe1

FE_P_disc< 1, 2, 3 >	fe2

FE_P_disc< 1, 3, 3 >	fe3

OutputFields	output_fields

OutputTime *	output_stream

FILE *	balance_output_file
	Temporary solution for writing balance into separate file. More...

FILE *	raw_output_file
	Raw data output file. More...

Detailed Description

Actually this class only collect former code from postprocess.* This code depends on values stored in mesh and has to be changed to use fields or other data provided by interface to darcy_flow. We have to relay on the interface in order to allow different implementation of darcy_flow.

Principal functionalities of current postprocess are:

move computed values into mesh - this can be removed after we get new output classes, other dependent code can use directly field interface
compute interpolation to nodes - this can be external and operate directly on fields
compute water balances over materials and boundary parts - is feasible through field interface

Further functionality of this class should be:

prepare data for general output classes

Definition at line 67 of file darcy_flow_mh_output.hh.

Constructor & Destructor Documentation

DarcyFlowMHOutput::DarcyFlowMHOutput	(	DarcyFlowMH_Steady *	flow,
		Input::Record	in_rec
	)

Definition at line 95 of file darcy_flow_mh_output.cc.

DarcyFlowMHOutput::~DarcyFlowMHOutput ( )

Definition at line 170 of file darcy_flow_mh_output.cc.

Member Function Documentation

double DarcyFlowMHOutput::calc_water_balance ( )

private

void DarcyFlowMHOutput::compute_l2_difference ( )

private

Temporary hack. Calculate approximation of L2 norm for: 1) difference between regularized pressure and analytical solution (using FunctionPython) 2) difference between RT velocities and analytical solution 3) difference of divergence

TODO: 1) implement field objects 2) implement DG_P2 finite elements 3) implement pressure postprocessing (result is DG_P2 field) 4) implement calculation of L2 norm for two field (compute the norm and values on individual elements as P0 field)

Definition at line 859 of file darcy_flow_mh_output.cc.

Here is the caller graph for this function:

void DarcyFlowMHOutput::make_corner_scalar ( vector< double > & node_scalar)

private

Definition at line 288 of file darcy_flow_mh_output.cc.

Here is the caller graph for this function:

void DarcyFlowMHOutput::make_element_scalar ( )

private

Definition at line 239 of file darcy_flow_mh_output.cc.

Here is the caller graph for this function:

void DarcyFlowMHOutput::make_element_vector ( )

private

Definition at line 259 of file darcy_flow_mh_output.cc.

Here is the caller graph for this function:

void DarcyFlowMHOutput::make_neighbour_flux ( )

private

void DarcyFlowMHOutput::make_node_scalar ( )

private

void DarcyFlowMHOutput::make_node_scalar_param ( )

private

Calculate nodes scalar, store it in double* node_scalars instead of node->scalar.

< tmp variable for storing particular distance node –> element, node –> side*/

Iterators

< number of nodes in the mesh */

< index of each node */

< sum elements joined to node */

< sum sides joined to node */

< sum distances to all joined elements */

< Sum distances to all joined sides */

tmp variables, will be replaced by ini keys TODO include them into ini file

< scalar is counted via elements*/

< scalar is counted via sides */

init arrays

first pass - calculate sums (weights)

< get Node pointer from element */

< get nod index from mesh */

< get Node pointer from element */

< get nod index from mesh */

second pass - calculate scalar

< get Node pointer from element */

< get nod index from mesh */

TODO - calculate it again or store it in prior pass

< get Node pointer from element */

< get nod index from mesh */

TODO - calculate it again or store it in prior pass

free memory

Definition at line 318 of file darcy_flow_mh_output.cc.

Here is the caller graph for this function:

void DarcyFlowMHOutput::make_side_flux ( )

private

void DarcyFlowMHOutput::make_sides_scalar ( )

private

void DarcyFlowMHOutput::output ( )

Calculate values for output.

Definition at line 195 of file darcy_flow_mh_output.cc.

Here is the caller graph for this function:

void DarcyFlowMHOutput::output_internal_flow_data ( )

private

Definition at line 688 of file darcy_flow_mh_output.cc.

Here is the caller graph for this function:

void DarcyFlowMHOutput::water_balance ( )

private

Calculate and output water balance over material subdomains and boudary fluxes. Works only for steady flow.

TODO:

fix it also for unsteady flow
create separate class for this caculations and output
create class for output of tables with support to output into various file formats like GNUplot of excel/open calc

Definition at line 567 of file darcy_flow_mh_output.cc.

Here is the caller graph for this function:

Member Data Documentation

FILE* DarcyFlowMHOutput::balance_output_file

private

Temporary solution for writing balance into separate file.

Definition at line 200 of file darcy_flow_mh_output.hh.

vector<double> DarcyFlowMHOutput::corner_pressure

private

This we need to allow piezo output and nead not to modify all test outputs. It should be replaced by more general scheme, where you can switch every output field on or off.Pressure head (in [m]) interpolated into nodes. Provides P1 approximation. Indexed by node indexes in mesh. Pressure head (in [m]) interpolated into nodes. Provides P1 approximation. Indexed by element-node numbering.

Definition at line 169 of file darcy_flow_mh_output.hh.

DarcyFlowMH_Steady* DarcyFlowMHOutput::darcy_flow

private

Definition at line 152 of file darcy_flow_mh_output.hh.

DOFHandlerMultiDim* DarcyFlowMHOutput::dh

private

Definition at line 187 of file darcy_flow_mh_output.hh.

vector<double> DarcyFlowMHOutput::ele_flux

private

Average flux in barycenter of every element. Indexed as elements in the mesh.

Definition at line 181 of file darcy_flow_mh_output.hh.

vector<double> DarcyFlowMHOutput::ele_piezo_head

private

Piezo-metric head (in [m]) in barycenter of elements (or equivalently mean pressure over every element). Indexed by element indexes in the mesh.

Definition at line 173 of file darcy_flow_mh_output.hh.

vector<double> DarcyFlowMHOutput::ele_pressure

private

Pressure head (in [m]) in barycenters of elements (or equivalently mean pressure over every element). Indexed by element indexes in the mesh.

Definition at line 171 of file darcy_flow_mh_output.hh.

FE_P_disc<1,1,3> DarcyFlowMHOutput::fe1

private

Definition at line 191 of file darcy_flow_mh_output.hh.

FE_P_disc<1,2,3> DarcyFlowMHOutput::fe2

private

Definition at line 192 of file darcy_flow_mh_output.hh.

FE_P_disc<1,3,3> DarcyFlowMHOutput::fe3

private

Definition at line 193 of file darcy_flow_mh_output.hh.

Input::Record DarcyFlowMHOutput::in_rec_

private

Accessor to the input record for the DarcyFlow output.

Definition at line 158 of file darcy_flow_mh_output.hh.

it::Record DarcyFlowMHOutput::input_type

static

Initial value:

= it::Record("DarcyMHOutput", "Parameters of MH output.")
    .declare_key("output_stream", OutputTime::input_type, it::Default::obligatory(),
                    "Parameters of output stream.")
    .declare_key("output_fields", it::Array(OutputFields::output_selection),
            it::Default::obligatory(), "List of fields to write to output file.")
    .declare_key("balance_output", it::FileName::output(), it::Default("water_balance.txt"),
                    "Output file for water balance table.")
    .declare_key("compute_errors", it::Bool(), it::Default("false"),
                    "SPECIAL PURPOSE. Computing errors pro non-compatible coupling.")
    .declare_key("raw_flow_output", it::FileName::output(), it::Default::optional(),
                    "Output file with raw data form MH module.")

Definition at line 96 of file darcy_flow_mh_output.hh.

std::vector<double> DarcyFlowMHOutput::l2_diff_divergence

private

Definition at line 184 of file darcy_flow_mh_output.hh.

std::vector<double> DarcyFlowMHOutput::l2_diff_pressure

private

Definition at line 184 of file darcy_flow_mh_output.hh.

std::vector<double> DarcyFlowMHOutput::l2_diff_velocity

private

Definition at line 184 of file darcy_flow_mh_output.hh.

MappingP1<1,3> DarcyFlowMHOutput::map1

private

Definition at line 188 of file darcy_flow_mh_output.hh.

MappingP1<2,3> DarcyFlowMHOutput::map2

private

Definition at line 189 of file darcy_flow_mh_output.hh.

MappingP1<3,3> DarcyFlowMHOutput::map3

private

Definition at line 190 of file darcy_flow_mh_output.hh.

Mesh* DarcyFlowMHOutput::mesh_

private

Definition at line 153 of file darcy_flow_mh_output.hh.

OutputFields DarcyFlowMHOutput::output_fields

private

Definition at line 195 of file darcy_flow_mh_output.hh.

OutputTime* DarcyFlowMHOutput::output_stream

private

Definition at line 197 of file darcy_flow_mh_output.hh.

FILE* DarcyFlowMHOutput::raw_output_file

private

Raw data output file.

Definition at line 202 of file darcy_flow_mh_output.hh.

vector<double> DarcyFlowMHOutput::subdomains

private

have to copy vector<int> provided by Mesh, in order to use FieldElementwise TEMPORARY SOLUTION

Definition at line 176 of file darcy_flow_mh_output.hh.

Vec DarcyFlowMHOutput::vec_corner_pressure

private

Definition at line 186 of file darcy_flow_mh_output.hh.

The documentation for this class was generated from the following files:

/home/jb/workspace/flow123d/src/flow/darcy_flow_mh_output.hh
/home/jb/workspace/flow123d/src/flow/darcy_flow_mh_output.cc
