#include <field_set.hh>

Inheritance diagram for FieldSet:

Collaboration diagram for FieldSet:

Public Member Functions
	DECLARE_EXCEPTION (ExcUnknownField,<< "Field set has no field with name: "<< FieldCommonBase::EI_Field::qval)

Input::Type::Record	make_field_descriptor_type (const std::string &equation_name) const

Input::Type::Selection	make_output_field_selection (const string &name, const string &desc="")

void	set_field (const std::string &dest_field_name, FieldCommonBase &source)

FieldCommonBase &	get_field (const std::string &field_name) const

void	set_mesh (const Mesh &mesh)

void	set_input_list (Input::Array input_list)

void	set_limit_side (LimitSide side)

void	mark_input_times (TimeMark::Type mark_type)

bool	changed () const

bool	is_constant (Region reg) const

void	set_time (const TimeGovernor &time)

void	output_type (OutputTime::DiscreteSpace rt)

void	output (OutputTime *stream)

FieldCommonBase &	add_field (FieldCommonBase *field, const string &name, const string &desc, const string &d_val="")

Protected Member Functions
FieldCommonBase *	field_by_name (const std::string &field_name) const

Protected Attributes
std::vector< FieldCommonBase * >	field_list
	List of all fields. More...

const Mesh *	mesh_ = nullptr
	value set by last set_mesh(); set the same to added fields More...

Input::Array	input_list_
	value set by last set_input_list(); set the same to added fields More...

LimitSide	side_ = LimitSide::unknown
	value set by last set_time_limit(); set the same to added fields More...

Detailed Description

TODO: implementation robust against destroying fields before the FieldSet.

Definition at line 20 of file field_set.hh.

Member Function Documentation

FieldCommonBase& FieldSet::add_field	(	FieldCommonBase *	field,
		const string &	name,
		const string &	desc,
		const string &	d_val = `""`
	)

inline

Adds given field into list of fields for group operations on fields. Parameters are: field pointer, name of the key in the input, desc - description of the key, and optional parameter d_val with default value. This method is rather called through the macro ADD_FIELD

Definition at line 241 of file field_set.hh.

bool FieldSet::changed ( ) const

inline

Collective interface to FieldCommonBase::set_mesh().

Definition at line 198 of file field_set.hh.

Here is the caller graph for this function:

FieldSet::DECLARE_EXCEPTION	(	ExcUnknownField	,
		<< "Field set has no field with name: "<< FieldCommonBase::EI_Field::qval
	)

FieldCommonBase* FieldSet::field_by_name ( const std::string & field_name) const

inlineprotected

Return pointer to the field of given name. REturn nullptr if not found.

Definition at line 250 of file field_set.hh.

Here is the caller graph for this function:

FieldCommonBase& FieldSet::get_field ( const std::string & field_name) const

inline

Returns pointer to the field given by name field_name. Throws if the field with given name is not found.

Definition at line 157 of file field_set.hh.

Here is the caller graph for this function:

bool FieldSet::is_constant ( Region reg) const

inline

Collective interface to FieldCommonBase::set_mesh().

Definition at line 207 of file field_set.hh.

Here is the caller graph for this function:

Input::Type::Record FieldSet::make_field_descriptor_type ( const std::string & equation_name) const

inline

Add an existing Field to the list. It stores just pointer to the field. Be careful to not destroy passed Field before the FieldSet.

Using operator allows elegant setting and adding of a field to the field set:

        Field<...> init_quantity; // member of a FieldSet descendant

        field_set +=
            some_field
            .disable_where(type, {dirichlet, neumann}); // this must come first since it is not member of FieldCommonBase
            .name("init_temperature")
            .description("Initial temperature");

  /
FieldSet &operator +=(FieldCommonBase &field) {
    FieldCommonBase *found_field = field_by_name(field.name());
    if (found_field) {
        ASSERT(&field==found_field, "Another field of the same name exists when adding field: %s\n", field.name().c_str());
    } else {
        field_list.push_back(&field);
        if (mesh_) field.set_mesh(*mesh_);
        if (!input_list_.is_empty()) field.set_input_list(input_list_);
        if (side_ != LimitSide::unknown) field.set_limit_side(side_);
    }
    return *this;
}
/**
   Add other FieldSet to current one.
  /
FieldSet &operator +=(const FieldSet &other) {
    for(auto field_ptr : other.field_list) this->operator +=(*field_ptr);
    return *this;
}
/**
   Make new FieldSet as a subset of *this. The new FieldSet contains fields with names given by the @p names parameter.
  /
FieldSet subset(std::vector<std::string> names) const {
    FieldSet set;
    for(auto name : names) set += this->get_field( name);
    return set;
}
unsigned int size() const {
    return field_list.size();
}
/**
   Returns input type for a field descriptor, that can contain any of the fields in the set.
   Typical usage is from derived class, where we add fields in the constructor and make auxiliary temporary instance
   to get the record odf the field descriptor. Simplest example:

   @code
   class EqData : public FieldSet {
   public:
        // fields
        Field<..> field_a;
        Field<..> field_b
        EqData() {
            add(field_a);
            add(field_b);
        }
   }

   Input::Type::Record SomEquation::input_type=
        Record("SomeEquation","equation's description")
        .declare_key("data",Input::Type::Array(EqData().make_field_descriptor_type()),"List of field descriptors.");

Definition at line 95 of file field_set.hh.

Input::Type::Selection FieldSet::make_output_field_selection	(	const string &	name,
		const string &	desc = `""`
	)

inline

Make Selection with strings for all field names in the FieldSet.

Definition at line 118 of file field_set.hh.

Here is the caller graph for this function:

void FieldSet::mark_input_times ( TimeMark::Type mark_type)

inline

Collective interface to FieldCommonBase::mar_input_times().

Definition at line 192 of file field_set.hh.

Here is the caller graph for this function:

void FieldSet::output ( OutputTime * stream)

inline

Collective interface to FieldCommonBase::output().

Definition at line 231 of file field_set.hh.

Here is the caller graph for this function:

void FieldSet::output_type ( OutputTime::DiscreteSpace rt)

inline

Collective interface to FieldCommonBase::output_type().

Parameters

rt	Discrete function space (element, node or corner data).

Definition at line 224 of file field_set.hh.

Here is the caller graph for this function:

void FieldSet::set_field	(	const std::string &	dest_field_name,
		FieldCommonBase &	source
	)

inline

Use FieldCommonBase::copy_from() to set field of the field set given by the first parameter dest_field_name. The source field is given as the second parameter source. The field copies share same input descriptor list and same instances of FieldBase classes but each copy can be set to different time and different limit side.

Definition at line 147 of file field_set.hh.

Here is the caller graph for this function:
