Abstract linear system class. More...

#include <la_linsys_new.hh>

Inheritance diagram for LinSys:

Collaboration diagram for LinSys:

Public Types
enum	SetValuesMode { INSERT =INSERT_VALUES, ADD =ADD_VALUES, ALLOCATE, DONE, NONE, INSERT =INSERT_VALUES, ADD =ADD_VALUES, ALLOCATE, DONE, NONE }

enum	SetValuesMode { INSERT =INSERT_VALUES, ADD =ADD_VALUES, ALLOCATE, DONE, NONE, INSERT =INSERT_VALUES, ADD =ADD_VALUES, ALLOCATE, DONE, NONE }

enum	LinSysType { PETSC_MPIAIJ_preallocate_by_assembly, PETSC_MPIAIJ_assembly_by_triples, BDDC, PETSC_schur_complement }

Public Member Functions
	LinSys (const Distribution *rows_ds)

	LinSys (LinSys &other)

unsigned int	size ()

unsigned int	vec_lsize ()

virtual const Mat &	get_matrix ()

virtual const Vec &	get_rhs ()

void	set_matrix_changed ()

void	set_rhs_changed ()

bool	is_matrix_changed ()

bool	is_rhs_changed ()

virtual PetscErrorCode	set_matrix (Mat &matrix, MatStructure str)

virtual PetscErrorCode	set_rhs (Vec &rhs)

virtual PetscErrorCode	mat_zero_entries ()

virtual PetscErrorCode	rhs_zero_entries ()

const Vec &	get_solution ()

void	set_solution (double *sol_array)

double *	get_solution_array ()

virtual void	get_whole_solution (std::vector< double > &globalSolution)

virtual void	set_whole_solution (std::vector< double > &globalSolution)

virtual void	start_allocation ()

virtual void	start_add_assembly ()

virtual void	start_insert_assembly ()

virtual void	finish_assembly ()=0

virtual void	mat_set_values (int nrow, int rows, int ncol, int cols, double *vals)=0

void	mat_set_value (int row, int col, double val)

virtual void	rhs_set_values (int nrow, int rows, double vals)=0

void	rhs_set_value (int row, double val)

void	set_values (int nrow, int rows, int ncol, int cols, PetscScalar mat_vals, PetscScalar rhs_vals)
	Set values in the system matrix and values in the right-hand side vector on corresponding rows. More...

void	set_values (std::vector< int > &row_dofs, std::vector< int > &col_dofs, const arma::mat &matrix, const arma::vec &rhs, const arma::vec &row_solution, const arma::vec &col_solution)

void	add_constraint (int row, double value)

virtual void	apply_constrains (double scalar)=0

virtual int	solve ()=0

double	get_residual_norm ()

double	get_relative_accuracy ()

virtual double	get_absolute_accuracy ()

void	set_symmetric (bool flag=true)

bool	is_symmetric ()

void	set_positive_definite (bool flag=true)

void	set_negative_definite (bool flag=true)

bool	is_positive_definite ()

bool	is_negative_definite ()

bool	is_new ()

bool	is_preallocated ()

void	set_spd_via_symmetric_general (bool flag=true)

bool	is_spd_via_symmetric_general ()

virtual void	view ()

virtual void	set_from_input (const Input::Record in_rec)

virtual double	get_solution_precision ()=0

virtual	~LinSys ()

	LinSys (unsigned int lsize, double *sol_array=NULL)

unsigned int	size ()

unsigned int	vec_lsize ()

const Distribution &	ds ()

const Mat &	get_matrix ()

const Vec &	get_rhs ()

const Vec &	get_solution ()

double *	get_solution_array ()

virtual void	start_allocation ()=0

void	start_add_assembly ()

void	start_insert_assembly ()

void	partial_assembly ()

void	finish_assembly ()

virtual void	mat_set_values (int nrow, int rows, int ncol, int cols, PetscScalar *vals)=0

void	mat_set_value (int row, int col, PetscScalar val)

void	rhs_set_values (int nrow, int rows, PetscScalar vals)

void	rhs_set_value (int row, PetscScalar val)

void	set_values (int nrow, int rows, int ncol, int cols, PetscScalar mat_vals, PetscScalar rhs_vals, std::vector< bool > &constrains_row_mask=std::vector(0), double *constrain_values=NULL)

void	add_constrain (int row, double value)

void	apply_constrains (std::vector< Constrain > &constraints)

virtual int	solve ()

void	set_symmetric (bool flag=true)

bool	is_symmetric ()

void	set_positive_definite (bool flag=true)

bool	is_positive_definite ()

void	view (std::ostream output_stream, int *output_mapping=NULL)

virtual	~LinSys ()

Public Attributes
LinSysType	type
	Particular type of the linear system. More...

Static Public Attributes
static Input::Type::AbstractRecord	input_type

Protected Types
typedef std::pair< unsigned, double >	Constraint_

typedef std::vector< Constraint_ >	ConstraintVec_

Protected Member Functions
virtual void	preallocate_matrix ()=0

virtual void	preallocate_values (int nrow, int rows, int ncol, int cols)=0

Protected Attributes
double	r_tol_

double	a_tol_

int	max_it_

MPI_Comm	comm_

SetValuesMode	status_
	Set value status of the linear system. More...

const unsigned	lsize_
	local number of matrix rows (non-overlapping division of rows) More...

unsigned	size_
	global number of matrix rows, i.e. problem size More...

const Distribution *	rows_ds_
	final distribution of rows of MH matrix More...

bool	symmetric_

bool	positive_definite_

bool	negative_definite_

bool	spd_via_symmetric_general_

bool	matrix_changed_
	true if the matrix was changed since the last solve More...

bool	rhs_changed_
	true if the right hand side was changed since the last solve More...

Vec	solution_
	PETSc vector constructed with vb array. More...

double *	v_solution_
	local solution array pointing into Vec solution_ More...

bool	own_solution_
	Indicates if the solution array has been allocated by this class. More...

double	residual_norm_
	local solution array pointing into Vec solution_ More...

ConstraintVec_	constraints_

std::vector< double >	globalSolution_
	global solution in numbering for linear system More...

Input::Record	in_rec_

Distribution	vec_ds
	Distribution of continuous blocks of system rows among the processors. More...

bool	symmetric
	Flag for the symmetric system. More...

bool	positive_definite
	Flag for positive definite system. More...

bool	own_solution
	Indicates if the solution array has been allocated by this class. More...

SetValuesMode	status
	Set value status of the linear system. More...

Mat	matrix
	Petsc matrix of the problem. More...

Vec	rhs
	PETSc vector constructed with vx array. More...

Vec	solution
	PETSc vector constructed with vb array. More...

double *	v_rhs
	RHS vector. More...

double *	v_solution
	Vector of solution. More...

int *	subdomain_indices
	Remember indices which created mapping. More...

Mat	local_matrix
	local matrix of subdomain (used in LinSys_MATIS) More...

Private Member Functions
LinSys *	block (i, j) MatrixArray *matrix() virtual solve(Vector solution

Private Attributes
LinSys Vector	RHS

Friends
class	SchurComplement

void	SchurComplement::form_schur ()

Detailed Description

Abstract linear system class.

LinSys - matrix and a particular way how to compute solution for given RHS, i.e. this class can perform action of the matrix inverse

This is abstract class for members of possible hierarchical tree of the whole system.

Linear system consists of Matrix, RHS and solution. It provides general methods for:

matrix preallocation
assembling matrix and RHS
application of linear constrains (Dirichlet conditions) either during assembly or on assembled system
solution of the system
output in Matlab format

Method operates on the system as single object. But some methods for matrix only manipulation can be provided until we have matrix as separate class.

TODO:

simplify constructors
introduce set_solution_vector() and set_rhs() in order to solve multiple systems with same matrix
simplify constructor, make common interface, rather introduce particular seters for particular solvers
which parameters expose through Input::Record
why we need lsize in constructors if we have Distribution

Linear system consists of Matrix, RHS and solution. It provides general methods for:

matrix preallocation
assembling matrix and RHS
application of linear constrains (Dirichlet conditions) either during assembly or on assembled system
solution of the system
output in Matlab format

Method operates on the system as single object. But some methods for matrix only manipulation can be provided until we have matrix as separate class.

Definition at line 182 of file la_linsys_new.hh.

Member Typedef Documentation

typedef std::pair<unsigned,double> LinSys::Constraint_

protected

Definition at line 111 of file linsys.hh.

typedef std::vector< Constraint_ > LinSys::ConstraintVec_

protected

Definition at line 112 of file linsys.hh.

Member Enumeration Documentation

enum LinSys::LinSysType

Enumerator
PETSC_MPIAIJ_preallocate_by_assembly
PETSC_MPIAIJ_assembly_by_triples
BDDC
PETSC_schur_complement

Definition at line 81 of file linsys_proposed.hh.

enum LinSys::SetValuesMode

Enumerator
INSERT
ADD
ALLOCATE
DONE
NONE
INSERT
ADD
ALLOCATE
DONE
NONE

Definition at line 73 of file linsys_proposed.hh.

enum LinSys::SetValuesMode

Enumerator
INSERT
ADD
ALLOCATE
DONE
NONE
INSERT
ADD
ALLOCATE
DONE
NONE

Definition at line 94 of file linsys.hh.

Constructor & Destructor Documentation

LinSys::LinSys ( const Distribution * rows_ds)

inline

Constructor. Constructor of abstract class should not be called directly, but is used for initialization of member common to all particular solvers.

Parameters

comm	- MPI communicator

TODO: Vector solution_ is now initialized to NULL, but it should be rather allocated in the constructor instead of the method set_solution().

Definition at line 125 of file linsys.hh.

LinSys::LinSys ( LinSys & other)

inline

Copy constructor.

Definition at line 140 of file linsys.hh.

virtual LinSys::~LinSys ( )

inlinevirtual

Definition at line 577 of file linsys.hh.

LinSys::LinSys	(	unsigned int	lsize,
		double *	sol_array = `NULL`
	)

Constructor. Constructor of abstract class should not be called directly, but is used for initialization of member common to all particular solvers.

Parameters

lsize	- local size of the solution vector
sol_array	- optionally one can provide pointer to array allocated to size lsize, where the solution should be stored,

virtual LinSys::~LinSys ( )

virtual

Member Function Documentation

void LinSys::add_constrain	(	int	row,
		double	value
	)

Adds Dirichlet constrain.

Parameters

row	- global numeb of row that should be eliminated.
value	- solution value at the given row

void LinSys::add_constraint	(	int	row,
		double	value
	)

inline

Adds Dirichlet constrain.

Parameters

row	- global number of row that should be eliminated.
value	- solution value at the given row

Definition at line 440 of file linsys.hh.

void LinSys::apply_constrains ( std::vector< Constrain > & constraints)

Apply constrains to assembled matrix. Constrains are given by pairs: global row index, value. i.e. typedef pair<unsigned int, double> Constrain;

What is th meaning of ( const double factor ) form Cambridge code?

virtual void LinSys::apply_constrains ( double scalar)

pure virtual

Apply constrains to assembled matrix. Constrains are given by pairs: global row index, value. i.e. typedef pair<unsigned int, double> Constrain;

What is th meaning of ( const double factor ) form Cambridge code?

Implemented in LinSys_PETSC, and LinSys_BDDC.

LinSys* LinSys::block	(	i	,
		j
	)

private

const Distribution& LinSys::ds ( )

inline

Returns whole Distribution class for distribution of the solution.

Definition at line 119 of file linsys_proposed.hh.

void LinSys::finish_assembly ( )

Finish assembly of the whole system. For PETSC this should call MatEndAssembly with MAT_FINAL_ASSEMBLY

virtual void LinSys::finish_assembly ( )

pure virtual

Finish assembly of the whole system. For PETSC this should call MatEndAssembly with MAT_FINAL_ASSEMBLY

Implemented in LinSys_PETSC, and LinSys_BDDC.

Here is the caller graph for this function:

virtual double LinSys::get_absolute_accuracy ( )

inlinevirtual

Returns information on absolute solver accuracy

Reimplemented in LinSys_PETSC.

Definition at line 475 of file linsys.hh.

const Mat& LinSys::get_matrix ( )

inline

Returns PETSC matrix (only for PETSC solvers)

Definition at line 125 of file linsys_proposed.hh.

virtual const Mat& LinSys::get_matrix ( )

inlinevirtual

Returns PETSC matrix (only for PETSC solvers)

If matrix is changed, method set_matrix_changed() must be called. Example: MatDiagonalSet(schur->get_matrix(), new_diagonal, ADD_VALUES); schur->set_matrix_changed();

Reimplemented in LinSys_PETSC.

Definition at line 180 of file linsys.hh.

Here is the caller graph for this function:

double LinSys::get_relative_accuracy ( )

inline

Returns information on relative solver accuracy

Definition at line 468 of file linsys.hh.

double LinSys::get_residual_norm ( )

inline

Returns norm of the initial right hand side

Definition at line 461 of file linsys.hh.

const Vec& LinSys::get_rhs ( )

inline

Returns RHS vector (only for PETSC solvers)

Definition at line 131 of file linsys_proposed.hh.

virtual const Vec& LinSys::get_rhs ( )

inlinevirtual

Returns RHS vector (only for PETSC solvers)

If vector is changed, method set_rhs_changed() must be called. Example: VecScale(schur->get_rhs(), -1.0); schur->set_rhs_changed();

Reimplemented in LinSys_PETSC.

Definition at line 195 of file linsys.hh.

Here is the caller graph for this function:

const Vec& LinSys::get_solution ( )

inline

Returns PETSC vector with solution. Underlying array can be provided on construction. Can this be implemented for BDDC?

Definition at line 138 of file linsys_proposed.hh.

const Vec& LinSys::get_solution ( )

inline

Returns PETSC vector with solution. Underlying array can be provided on construction.

Definition at line 260 of file linsys.hh.

Here is the caller graph for this function:

double* LinSys::get_solution_array ( )

inline

Returns local part of solution vector. Can this be implemented for BDDC?

Definition at line 145 of file linsys_proposed.hh.

double* LinSys::get_solution_array ( )

inline

Returns PETSC subarray with solution. Underlying array can be provided on construction.

Definition at line 284 of file linsys.hh.

Here is the caller graph for this function:

virtual double LinSys::get_solution_precision ( )

pure virtual

Get precision of solving

Implemented in LinSys_PETSC, SchurComplement, and LinSys_BDDC.

Here is the caller graph for this function:

virtual void LinSys::get_whole_solution ( std::vector< double > & globalSolution)

inlinevirtual

Returns whole solution vector.

Reimplemented in LinSys_PETSC, and LinSys_BDDC.

Definition at line 293 of file linsys.hh.

bool LinSys::is_matrix_changed ( )

inline

Returns true if the system matrix has changed since the last solve.

Definition at line 215 of file linsys.hh.

Here is the caller graph for this function:

bool LinSys::is_negative_definite ( )

inline

Definition at line 520 of file linsys.hh.

Here is the caller graph for this function:

bool LinSys::is_new ( )

inline

TODO: In fact we want to know if the matrix is already preallocated However to do this we need explicit finalisation of preallocating cycle.

Definition at line 525 of file linsys.hh.

bool LinSys::is_positive_definite ( )

inline

Definition at line 284 of file linsys_proposed.hh.

bool LinSys::is_positive_definite ( )

inline

Definition at line 517 of file linsys.hh.

Here is the caller graph for this function:

bool LinSys::is_preallocated ( )

inline

Definition at line 529 of file linsys.hh.

Here is the caller graph for this function:

bool LinSys::is_rhs_changed ( )

inline

Returns true if the system RHS has changed since the last solve.

Definition at line 221 of file linsys.hh.

bool LinSys::is_spd_via_symmetric_general ( )

inline

Definition at line 545 of file linsys.hh.

bool LinSys::is_symmetric ( )

inline

Definition at line 272 of file linsys_proposed.hh.

bool LinSys::is_symmetric ( )

inline

Definition at line 490 of file linsys.hh.

Here is the caller graph for this function:

void LinSys::mat_set_value	(	int	row,
		int	col,
		PetscScalar	val
	)

inline

Shortcut for assembling just one element into the matrix. Similarly we can provide method accepting armadillo matrices.

Definition at line 183 of file linsys_proposed.hh.

void LinSys::mat_set_value	(	int	row,
		int	col,
		double	val
	)

inline

Shortcut for assembling just one element into the matrix. Similarly we can provide method accepting armadillo matrices.

Definition at line 345 of file linsys.hh.

Here is the caller graph for this function:

virtual void LinSys::mat_set_values	(	int	nrow,
		int *	rows,
		int	ncol,
		int *	cols,
		PetscScalar *	vals
	)

pure virtual

Assembly full rectangular submatrix into the system matrix. Should be virtual, implemented differently in particular solvers.

virtual void LinSys::mat_set_values	(	int	nrow,
		int *	rows,
		int	ncol,
		int *	cols,
		double *	vals
	)

pure virtual

Assembly full rectangular submatrix into the system matrix. Should be virtual, implemented differently in particular solvers.

Implemented in LinSys_PETSC, and LinSys_BDDC.

Here is the caller graph for this function:

virtual PetscErrorCode LinSys::mat_zero_entries ( )

inlinevirtual

Clears entries of the matrix

Reimplemented in LinSys_PETSC, and LinSys_BDDC.

Definition at line 244 of file linsys.hh.

Here is the caller graph for this function:

void LinSys::partial_assembly ( )

May not be necessary. For PETSC this should call MatEndAssembly with MAT_PARTIAL_ASSEMBLY

virtual void LinSys::preallocate_matrix ( )

protectedpure virtual

Protected methods used in preallocate_by_assembly solvers.

Implemented in LinSys_MATIS, LinSys_MPIAIJ, and LinSys_PETSC.

virtual void LinSys::preallocate_values	(	int	nrow,
		int *	rows,
		int	ncol,
		int *	cols
	)

protectedpure virtual

Protected methods used in preallocate_by_assembly solvers.

Implemented in LinSys_MATIS, LinSys_MPIAIJ, and LinSys_PETSC.

void LinSys::rhs_set_value	(	int	row,
		PetscScalar	val
	)

inline

Shorcut for assembling just one element into RHS vector.

Definition at line 204 of file linsys_proposed.hh.

void LinSys::rhs_set_value	(	int	row,
		double	val
	)

inline

Shorcut for assembling just one element into RHS vector.

Definition at line 357 of file linsys.hh.

Here is the caller graph for this function:

void LinSys::rhs_set_values	(	int	nrow,
		int *	rows,
		PetscScalar *	vals
	)

inline

Set values of the system right-hand side. Should be virtual, implemented differently in particular solvers.

Definition at line 190 of file linsys_proposed.hh.

virtual void LinSys::rhs_set_values	(	int	nrow,
		int *	rows,
		double *	vals
	)

pure virtual

Set values of the system right-hand side. Should be virtual, implemented differently in particular solvers.

Implemented in LinSys_PETSC, and LinSys_BDDC.

Here is the caller graph for this function:

virtual PetscErrorCode LinSys::rhs_zero_entries ( )

inlinevirtual

Clears entries of the right-hand side

Reimplemented in LinSys_PETSC, and LinSys_BDDC.

Definition at line 252 of file linsys.hh.

Here is the caller graph for this function:

virtual void LinSys::set_from_input ( const Input::Record in_rec)

inlinevirtual

Sets basic parameters of LinSys defined by user in input file and used to calculate

Reimplemented in LinSys_PETSC, and LinSys_BDDC.

Definition at line 562 of file linsys.hh.

Here is the caller graph for this function:

virtual PetscErrorCode LinSys::set_matrix	(	Mat &	matrix,
		MatStructure	str
	)

inlinevirtual

Sets PETSC matrix (only for PETSC solvers)

Reimplemented in LinSys_PETSC.

Definition at line 228 of file linsys.hh.

void LinSys::set_matrix_changed ( )

inline

Sets matrix changed flag.

Definition at line 203 of file linsys.hh.

Here is the caller graph for this function:

void LinSys::set_negative_definite ( bool flag = true)

inline

Provides user knowledge about negative definiteness.

Definition at line 508 of file linsys.hh.

Here is the caller graph for this function:

void LinSys::set_positive_definite ( bool flag = true)

inline

Provides user knowledge about positive definiteness.

Definition at line 278 of file linsys_proposed.hh.

void LinSys::set_positive_definite ( bool flag = true)

inline

Provides user knowledge about positive definiteness.

Definition at line 496 of file linsys.hh.

Here is the caller graph for this function:

virtual PetscErrorCode LinSys::set_rhs ( Vec & rhs)

inlinevirtual

Sets RHS vector (only for PETSC solvers)

Reimplemented in LinSys_PETSC.

Definition at line 236 of file linsys.hh.

void LinSys::set_rhs_changed ( )

inline

Sets rhs changed flag (only for PETSC solvers)

Definition at line 209 of file linsys.hh.

Here is the caller graph for this function:

void LinSys::set_solution ( double * sol_array)

inline

Create PETSc solution

Definition at line 268 of file linsys.hh.

Here is the caller graph for this function:

void LinSys::set_spd_via_symmetric_general ( bool flag = true)

inline

Provides user knowledge about positive definiteness via symmetric general approach. This is useful for solving Darcy flow by mixed hybrid method, where blocks on subdomains are saddle point but interface among subdomains is only at the block of Lagrange multipliers and is symmetric positive definite. Problem condensed to interface can thus be solved by PCG method, although original problem is saddle point.

Definition at line 539 of file linsys.hh.

void LinSys::set_symmetric ( bool flag = true)

inline

Provides user knowledge about symmetry.

Definition at line 266 of file linsys_proposed.hh.

void LinSys::set_symmetric ( bool flag = true)

inline

Provides user knowledge about symmetry.

Definition at line 481 of file linsys.hh.

Here is the caller graph for this function:

void LinSys::set_values	(	int	nrow,
		int *	rows,
		int	ncol,
		int *	cols,
		PetscScalar *	mat_vals,
		PetscScalar *	rhs_vals,
		std::vector< bool > &	constrains_row_mask = `std::vector(0)`,
		double *	constrain_values = `NULL`
	)

inline

Shortcut to assembly into matrix and RHS in one call. This can also apply constrains at assembly time (only in add assembly regime).

Constrains can either be set before through add_constrain. Or by additional parameters if we have only per element knowledge about boundary conditions.

Definition at line 215 of file linsys_proposed.hh.

void LinSys::set_values	(	int	nrow,
		int *	rows,
		int	ncol,
		int *	cols,
		PetscScalar *	mat_vals,
		PetscScalar *	rhs_vals
	)

inline

Set values in the system matrix and values in the right-hand side vector on corresponding rows.

Definition at line 362 of file linsys.hh.

Here is the caller graph for this function:

void LinSys::set_values	(	std::vector< int > &	row_dofs,
		std::vector< int > &	col_dofs,
		const arma::mat &	matrix,
		const arma::vec &	rhs,
		const arma::vec &	row_solution,
		const arma::vec &	col_solution
	)

inline

Shortcut to assembly into matrix and RHS in one call, possibly apply Dirichlet boundary conditions. row_dofs - are global indices of rows of dense matrix and rows of dense vector in global system col_dofs - are global indices of columns of the matrix, and possibly

Application of Dirichlet conditions: 1) Rows with negative dofs are set to zero. 2) Cols with negative dofs are eliminated. 3) If there are entries on global diagonal. We determine value K either from diagonal of local matrix, or (if it is zero) from diagonal average.

Definition at line 381 of file linsys.hh.

virtual void LinSys::set_whole_solution ( std::vector< double > & globalSolution)

inlinevirtual

Inserts solution vector.

Reimplemented in LinSys_BDDC.

Definition at line 301 of file linsys.hh.

unsigned int LinSys::size ( )

inline

Returns global system size.

Definition at line 106 of file linsys_proposed.hh.

unsigned int LinSys::size ( )

inline

Returns global system size.

Definition at line 156 of file linsys.hh.

Here is the caller graph for this function:

virtual int LinSys::solve ( )

virtual

   Solve the system.

   parameters should by provided in input file (currently INI file, but will be changed to JSON)

   If we realize that we need to set something, rather add some set_* function.

   double tol = 1.e-7,                        //!< tolerance on relative residual ||res||/||rhs||
   int  numLevels = 2,                        //!< number of levels
   std::vector<int> *  numSubAtLevels = NULL, //!< number of subdomains at levels
   int verboseLevel = 0,                      //!< level of verbosity of BDDCML library

!< ( 0 - only fatal errors reported, !< 1 - mild output, !< 2 - detailed output ) int maxIt = 1000, //!< maximum number of iterations int ndecrMax = 30 ); //!< maximum number of iterations with non-decreasing residual !< ( used to stop diverging process )

   Returns convergence reason (form PETSC)

Reimplemented in SchurComplement, LinSys_PETSC, and LinSys_BDDC.

virtual int LinSys::solve ( )

pure virtual

Solve the system and return convergence reason.

Implemented in SchurComplement, LinSys_PETSC, and LinSys_BDDC.

Here is the caller graph for this function:

void LinSys::start_add_assembly ( )

Switch linear system into adding assembly. (the only one supported by triplets ??)

virtual void LinSys::start_add_assembly ( )

inlinevirtual

Switch linear system into adding assembly. (the only one supported by triplets ??)

Reimplemented in LinSys_PETSC.

Definition at line 317 of file linsys.hh.

Here is the caller graph for this function:

virtual void LinSys::start_allocation ( )

pure virtual

Switch linear system into allocating assembly. (only for PETSC_MPIAIJ_preallocate_by_assembly)

Implemented in LinSys_MATIS, LinSys_MPIAIJ, and LinSys_PETSC.

virtual void LinSys::start_allocation ( )

inlinevirtual

Switch linear system into allocating assembly. (only for PETSC_MPIAIJ_preallocate_by_assembly)

Reimplemented in LinSys_MATIS, LinSys_MPIAIJ, and LinSys_PETSC.

Definition at line 309 of file linsys.hh.

Here is the caller graph for this function:

void LinSys::start_insert_assembly ( )

Switch linear system into insert assembly. (not currently used)

virtual void LinSys::start_insert_assembly ( )

inlinevirtual

Switch linear system into insert assembly. (not currently used)

Reimplemented in LinSys_PETSC.

Definition at line 325 of file linsys.hh.

unsigned int LinSys::vec_lsize ( )

inline

Returns local system size. (for partitioning of solution vectors) for PETSC_MPIAIJ it is also partitioning of the matrix

Definition at line 113 of file linsys_proposed.hh.

unsigned int LinSys::vec_lsize ( )

inline

Returns local system size. (for partitioning of solution vectors) for PETSC_MPIAIJ it is also partitioning of the matrix

Definition at line 165 of file linsys.hh.

void LinSys::view	(	std::ostream	output_stream,
		int *	output_mapping = `NULL`
	)

Output the system in the Matlab format possibly with given ordering. Rather we shoud provide output operator <<, since it is more flexible.

virtual void LinSys::view ( )

inlinevirtual

Output the system in the Matlab format possibly with given ordering. Rather we shoud provide output operator <<, since it is more flexible.

Reimplemented in LinSys_PETSC.

Definition at line 554 of file linsys.hh.

Friends And Related Function Documentation

SchurComplement

friend

Definition at line 89 of file linsys.hh.

void SchurComplement::form_schur ( )

friend

Member Data Documentation

double LinSys::a_tol_

protected

Definition at line 586 of file linsys.hh.

MPI_Comm LinSys::comm_

protected

Definition at line 589 of file linsys.hh.

ConstraintVec_ LinSys::constraints_

protected

Definition at line 611 of file linsys.hh.

std::vector<double> LinSys::globalSolution_

protected

global solution in numbering for linear system

Definition at line 613 of file linsys.hh.

Input::Record LinSys::in_rec_

protected

Definition at line 615 of file linsys.hh.

it::AbstractRecord LinSys::input_type

static

Initial value:

= it::AbstractRecord("LinSys", "Linear solver setting.")
    .declare_key("r_tol", it::Double(0.0, 1.0), it::Default("1.0e-7"),
                "Relative residual tolerance (to initial error).")
    .declare_key("max_it", it::Integer(0), it::Default("10000"),
                "Maximum number of outer iterations of the linear solver.")

Definition at line 92 of file linsys.hh.

Mat LinSys::local_matrix

protected

local matrix of subdomain (used in LinSys_MATIS)

Definition at line 321 of file linsys_proposed.hh.

const unsigned LinSys::lsize_

protected

local number of matrix rows (non-overlapping division of rows)

Definition at line 592 of file linsys.hh.

Mat LinSys::matrix

protected

Petsc matrix of the problem.

Definition at line 313 of file linsys_proposed.hh.

bool LinSys::matrix_changed_

protected

true if the matrix was changed since the last solve

Definition at line 602 of file linsys.hh.

int LinSys::max_it_

protected

Definition at line 587 of file linsys.hh.

bool LinSys::negative_definite_

protected

Definition at line 599 of file linsys.hh.

bool LinSys::own_solution

protected

Indicates if the solution array has been allocated by this class.

Definition at line 310 of file linsys_proposed.hh.

bool LinSys::own_solution_

protected

Indicates if the solution array has been allocated by this class.

Definition at line 607 of file linsys.hh.

bool LinSys::positive_definite

protected

Flag for positive definite system.

Definition at line 309 of file linsys_proposed.hh.

bool LinSys::positive_definite_

protected

Definition at line 598 of file linsys.hh.

double LinSys::r_tol_

protected

Definition at line 585 of file linsys.hh.

double LinSys::residual_norm_

protected

local solution array pointing into Vec solution_

Definition at line 609 of file linsys.hh.

LinSys Vector LinSys::RHS

private

Definition at line 186 of file la_linsys_new.hh.

Vec LinSys::rhs

protected

PETSc vector constructed with vx array.

Definition at line 314 of file linsys_proposed.hh.

bool LinSys::rhs_changed_

protected

true if the right hand side was changed since the last solve

Definition at line 603 of file linsys.hh.

const Distribution* LinSys::rows_ds_

protected

final distribution of rows of MH matrix

Definition at line 595 of file linsys.hh.

unsigned LinSys::size_

protected

global number of matrix rows, i.e. problem size

Definition at line 593 of file linsys.hh.

Vec LinSys::solution

protected

PETSc vector constructed with vb array.

Definition at line 315 of file linsys_proposed.hh.

Vec LinSys::solution_

protected

PETSc vector constructed with vb array.

Definition at line 605 of file linsys.hh.

bool LinSys::spd_via_symmetric_general_

protected

Definition at line 600 of file linsys.hh.

SetValuesMode LinSys::status

protected

Set value status of the linear system.

Definition at line 311 of file linsys_proposed.hh.

SetValuesMode LinSys::status_

protected

Set value status of the linear system.

Definition at line 590 of file linsys.hh.

int* LinSys::subdomain_indices

protected

Remember indices which created mapping.

Definition at line 320 of file linsys_proposed.hh.

bool LinSys::symmetric

protected

Flag for the symmetric system.

Definition at line 308 of file linsys_proposed.hh.

bool LinSys::symmetric_

protected

Definition at line 597 of file linsys.hh.

LinSysType LinSys::type

Particular type of the linear system.

MAT_IS or MAT_MPIAIJ anyone can inquire my type

Definition at line 100 of file linsys_proposed.hh.

double* LinSys::v_rhs

protected

RHS vector.

Definition at line 316 of file linsys_proposed.hh.

double* LinSys::v_solution

protected

Vector of solution.

Definition at line 317 of file linsys_proposed.hh.

double* LinSys::v_solution_

protected

local solution array pointing into Vec solution_

Definition at line 606 of file linsys.hh.

Distribution LinSys::vec_ds

protected

Distribution of continuous blocks of system rows among the processors.

Definition at line 307 of file linsys_proposed.hh.

The documentation for this class was generated from the following files:

/home/jb/workspace/flow123d/src/la/la_linsys_new.hh
/home/jb/workspace/flow123d/src/la/linsys.hh
/home/jb/workspace/flow123d/src/la/linsys_proposed.hh
/home/jb/workspace/flow123d/src/la/linsys.cc

Public Types

Public Member Functions

Public Attributes

Static Public Attributes

Protected Types

Protected Member Functions

Protected Attributes

Private Member Functions

Private Attributes

Friends

Detailed Description

Member Typedef Documentation

Member Enumeration Documentation

Constructor & Destructor Documentation

Member Function Documentation

Friends And Related Function Documentation

Member Data Documentation
