The class for outputting data during time. More...

#include <output_time.hh>

Inheritance diagram for OutputTime:

Collaboration diagram for OutputTime:

[legend]

Public Types
enum	DiscreteSpace { NODE_DATA = 0, CORNER_DATA = 1, ELEM_DATA = 2 }

Public Member Functions
	OutputTime ()
	Default constructor. Only for testing. More...

	OutputTime (const Input::Record &in_rec)
	Constructor of OutputTime object. It opens base file for writing. More...

virtual	~OutputTime ()
	Destructor of OutputTime. It doesn't do anything, because all necessary destructors will be called in destructor of Output. More...

template<int spacedim, class Value >
void	register_data (const DiscreteSpace type, MultiField< spacedim, Value > &multi_field)
	Generic method for registering output data stored in MultiField. More...

template<int spacedim, class Value >
void	register_data (const DiscreteSpace ref_type, Field< spacedim, Value > &field)
	Generic method for registering of output data stored in Field. More...

void	write_time_frame ()

void	add_admissible_field_names (const Input::Array &in_array)
	Registers names of output fields that can be written using this stream. More...

void	clear_data (void)
	Clear data for output computed by method `compute_field_data`. More...

void	mark_output_times (const TimeGovernor &tg)

	TYPEDEF_ERR_INFO (EI_FieldName, std::string)

	DECLARE_EXCEPTION (ExcOutputVariableVector,<< "Can not output field "<< EI_FieldName::qval<< " returning variable size vectors. Try convert to MultiField.\n")

Static Public Member Functions
static const Input::Type::Record &	get_input_type ()
	The specification of output stream. More...

static Input::Type::Abstract &	get_input_format_type ()
	The specification of output file format. More...

static std::shared_ptr< OutputTime >	create_output_stream (const Input::Record &in_rec)
	This method delete all object instances of class OutputTime stored in output_streams vector. More...

Public Attributes
Input::AbstractRecord	format_record_

Static Public Attributes
static const unsigned int	N_DISCRETE_SPACES = 3

Protected Types
typedef std::shared_ptr< OutputDataBase >	OutputDataPtr

typedef std::vector< OutputDataPtr >	OutputDataFieldVec

typedef unsigned int	DiscreteSpaceFlags

Protected Member Functions
template<int spacedim, class Value >
void	compute_field_data (DiscreteSpace type, Field< spacedim, Value > &field)

void	fix_main_file_extension (std::string extension)

virtual int	write_data (void)=0
	Virtual method for writing data to output file. More...

Protected Attributes
int	rank

OutputDataFieldVec	output_data_vec_ [N_DISCRETE_SPACES]

int	current_step

double	time

double	write_time

std::map< std::string, DiscreteSpaceFlags >	output_names

Input::Record	input_record_

ofstream	_base_file

string	_base_filename

Mesh *	_mesh

Detailed Description

The class for outputting data during time.

This class is descendant of Output class. This class is used for outputting data varying in time. Own output to specific file formats is done at other places to. See output_vtk.cc and output_msh.cc.

Definition at line 42 of file output_time.hh.

Member Typedef Documentation

typedef unsigned int OutputTime::DiscreteSpaceFlags

protected

Maps names of output fields required by user to their indices in output_data_vec_.

Definition at line 211 of file output_time.hh.

typedef std::vector< OutputDataPtr > OutputTime::OutputDataFieldVec

protected

Definition at line 184 of file output_time.hh.

typedef std::shared_ptr<OutputDataBase> OutputTime::OutputDataPtr

protected

Map field name to its OutputData object.

Definition at line 183 of file output_time.hh.

Member Enumeration Documentation

enum OutputTime::DiscreteSpace

Enumerator
NODE_DATA
CORNER_DATA
ELEM_DATA

Definition at line 78 of file output_time.hh.

Constructor & Destructor Documentation

OutputTime::OutputTime ( )

Default constructor. Only for testing.

Definition at line 61 of file output_time.cc.

Here is the caller graph for this function:

OutputTime::OutputTime ( const Input::Record & in_rec )

Constructor of OutputTime object. It opens base file for writing.

Parameters

[in] in_rec The reference on the input record

Definition at line 67 of file output_time.cc.

OutputTime::~OutputTime ( void )

virtual

Destructor of OutputTime. It doesn't do anything, because all necessary destructors will be called in destructor of Output.

Definition at line 84 of file output_time.cc.

Member Function Documentation

void OutputTime::add_admissible_field_names ( const Input::Array & in_array )

Registers names of output fields that can be written using this stream.

Parameters

in_array Array of admissible fields (array of selections).

Definition at line 151 of file output_time.cc.

void OutputTime::clear_data ( void )

Clear data for output computed by method compute_field_data.

Definition at line 223 of file output_time.cc.

Here is the caller graph for this function:

template<int spacedim, class Value >

void OutputTime::compute_field_data	(	DiscreteSpace	type,
		Field< spacedim, Value > &	field
	)

protected

Interpolate given field into output discrete space and store the values into private storage for postponed output.

Definition at line 282 of file output_time.impl.hh.

std::shared_ptr< OutputTime > OutputTime::create_output_stream ( const Input::Record & in_rec )

static

This method delete all object instances of class OutputTime stored in output_streams vector.

This method tries to create new instance of OutputTime according record in configuration file.

Definition at line 134 of file output_time.cc.

Here is the caller graph for this function:

OutputTime::DECLARE_EXCEPTION	(	ExcOutputVariableVector	,
		<< "Can not output field "<< EI_FieldName::qval<< " returning variable size vectors. Try convert to MultiField.\n"
	)

Declaration of exception

void OutputTime::fix_main_file_extension ( std::string extension )

protected

Change main filename to have prescribed extension.

Definition at line 103 of file output_time.cc.

Here is the caller graph for this function:

Abstract & OutputTime::get_input_format_type ( )

static

The specification of output file format.

Definition at line 55 of file output_time.cc.

Here is the caller graph for this function:

const Record & OutputTime::get_input_type ( )

static

The specification of output stream.

Returns: This variable defines record for output stream

Definition at line 34 of file output_time.cc.

Here is the caller graph for this function:

void OutputTime::mark_output_times ( const TimeGovernor & tg )

Add time marks matching given tg.output_mark_type as well as general output type TimeMarks::type_output(). The time marks denotes times when output should be performed according to the input record of the output stream, namely keys: time_step, time_list, and include_input_times.

Definition at line 168 of file output_time.cc.

template<int spacedim, class Value >

void OutputTime::register_data	(	const DiscreteSpace	type,
		MultiField< spacedim, Value > &	multi_field
	)

Generic method for registering output data stored in MultiField.

Parameters

ref_type	Type of output (element, node, corner data).
multi_field	The actual field for output.

Definition at line 249 of file output_time.impl.hh.

template<int spacedim, class Value >

void OutputTime::register_data	(	const DiscreteSpace	ref_type,
		Field< spacedim, Value > &	field
	)

Generic method for registering of output data stored in Field.

Parameters

ref_type	Type of output (element, node, corner data).
field	The actual field for output.

Definition at line 266 of file output_time.impl.hh.

OutputTime::TYPEDEF_ERR_INFO	(	EI_FieldName	,
		std::string
	)

Declaration of new exception info used in following exception

virtual int OutputTime::write_data ( void )

protectedpure virtual

Virtual method for writing data to output file.

Implemented in OutputVTK, and OutputMSH.

Here is the caller graph for this function:

void OutputTime::write_time_frame ( )

Write all data registered as a new time frame.

Definition at line 201 of file output_time.cc.

Member Data Documentation

ofstream OutputTime::_base_file

protected

Base output stream

Definition at line 222 of file output_time.hh.

string OutputTime::_base_filename

protected

Name of base output file

Definition at line 227 of file output_time.hh.

Mesh* OutputTime::_mesh

protected

Cached pointer at mesh used by this output stream

Definition at line 232 of file output_time.hh.

int OutputTime::current_step

protected

Current step

Definition at line 195 of file output_time.hh.

Input::AbstractRecord OutputTime::format_record_

Record for current output stream

Definition at line 153 of file output_time.hh.

Input::Record OutputTime::input_record_

protected

Record for current output stream

Definition at line 217 of file output_time.hh.

const unsigned int OutputTime::N_DISCRETE_SPACES = 3

static

Types of reference data

Definition at line 77 of file output_time.hh.

OutputDataFieldVec OutputTime::output_data_vec_[N_DISCRETE_SPACES]

protected

Registered output data. Single map for every value of DiscreteSpace corresponding to nodes, elements and corners.

Definition at line 190 of file output_time.hh.

std::map<std::string, DiscreteSpaceFlags> OutputTime::output_names

protected

Definition at line 212 of file output_time.hh.

int OutputTime::rank

protected

Cached MPI rank of process (is tested in methods)

Definition at line 178 of file output_time.hh.

double OutputTime::time

protected

The newest time of registered data

Definition at line 200 of file output_time.hh.

double OutputTime::write_time

protected

The last time, when data was wrote to this stream

Definition at line 205 of file output_time.hh.

The documentation for this class was generated from the following files:

/home/cygwin64/F123-windows-release/flow123d/src/io/output_time.hh
/home/cygwin64/F123-windows-release/flow123d/src/io/output_time.cc
/home/cygwin64/F123-windows-release/flow123d/src/io/output_time.impl.hh
