This class is a collection of time marks to manage various events occurring during simulation time. More...

#include <time_marks.hh>

Collaboration diagram for TimeMarks:

Public Types
typedef TimeMarksIterator	iterator
	Iterator class for iteration over time marks of particular type. This is always const_iterator. More...

Public Member Functions
	TimeMarks ()

void	reinit ()

TimeMark::Type	new_mark_type ()

TimeMark::Type	type_fixed_time ()

TimeMark::Type	type_output ()

TimeMark::Type	type_input ()

void	add (const TimeMark &mark)

void	add_time_marks (double time, double dt, double end_time, TimeMark::Type type)

bool	is_current (const TimeGovernor &tg, const TimeMark::Type &mask) const

TimeMarks::iterator	next (const TimeGovernor &tg, const TimeMark::Type &mask) const

TimeMarks::iterator	last (const TimeGovernor &tg, const TimeMark::Type &mask) const

TimeMarks::iterator	last (const TimeMark::Type &mask) const

TimeMarks::iterator	begin (TimeMark::Type mask=TimeMark::every_type) const
	Iterator for the begin mimics container-like of TimeMarks. More...

TimeMarks::iterator	end (TimeMark::Type mask=TimeMark::every_type) const
	Iterator for the end mimics container-like of TimeMarks. More...

Private Attributes
TimeMark::Type	next_mark_type_
	MarkType that will be used at next new_time_mark() call. More...

std::vector< TimeMark >	marks_
	TimeMarks list sorted according to the their time. More...

TimeMark::Type	type_fixed_time_
	Predefined type for fixed time. More...

TimeMark::Type	type_output_
	Predefined type for output. More...

TimeMark::Type	type_input_
	Predefined type for change of boundary condition. More...

Friends
std::ostream &	operator<< (std::ostream &stream, const TimeMarks &marks)
	Friend output operator. More...

Detailed Description

This class is a collection of time marks to manage various events occurring during simulation time.

TimeMark and their types

One TimeMark consists of time and type (TimeMark::Type), see the constructor TimeMark::TimeMark. The type of mark is bitmap where individual bits corresponds to some base event types like changing a BC, output solution, coupling time with another equation and so on. Base types can be combined by bitwise or (operator|).

Special types are predefined in TimeMarks class. These are returned by their getters:

type_fixed_time() - marks of this type are considered as fixed times by a TimeGovernor which is connected to particular TimeMarks object.
type_output() - this type marks times at which solution should be computed and written to output.
type_bc_change() - this type marks times at which BC is is changed and model has to be updated.

TimeMarks collection

TimeMarks collect marks of various types and provides methods for iterating over stored marks. You can selectively access only marks matching given type mask. See TimeMark::match_mask.

You can add one new mark through method add or add evenly spaced marks of same type by TimeMarks::add_time_marks.

You can allocate new TimeMark::Type in the context of one TimeMarks object by TimeMarks::new_mark_type.

For a given TimeGovernor (not necessarily connected one) you can ask about existence of mark in current time interval (TimeMarks::is_current) and see TimeMarks close to the current time (TimeMarks::next and TimeMarks::last). The current time interval is left-open and right-closed: (t,t+dt]. Repeatedly used TimeMarks::next always returns the same TimeMark if the time of the TimeGovernor is not changed.

In most cases there will be only one TimeMarks object for the whole solved problem and used by TimeGovernors of individual equations. However this is not necessary.

See also: TimeMark

Definition at line 157 of file time_marks.hh.

Member Typedef Documentation

typedef TimeMarksIterator TimeMarks::iterator

Iterator class for iteration over time marks of particular type. This is always const_iterator.

Definition at line 161 of file time_marks.hh.

Constructor & Destructor Documentation

TimeMarks::TimeMarks ( )

Default constructor.

Definition at line 44 of file time_marks.cc.

Member Function Documentation

void TimeMarks::add ( const TimeMark & mark )

Basic method for inserting TimeMarks.

Parameters

mark	Reference to TimeMark object.

Definition at line 74 of file time_marks.cc.

Here is the caller graph for this function:

void TimeMarks::add_time_marks	(	double	time,
		double	dt,
		double	end_time,
		TimeMark::Type	type
	)

Method for creating and inserting equally spaced TimeMarks.

Parameters

time	Time of the first TimeMark.
dt	Lenght of interval between equally spaced TimeMarks.
end_time	No marks after the end_time.
type	Type of inserted TimeMarks or their combinations.

Current lazy implementation have complexity O(m*n) where m is number of inserted time marks and n number of time marks in the array. TODO: O(n+m) implementation

Definition at line 97 of file time_marks.cc.

TimeMarks::iterator TimeMarks::begin ( TimeMark::Type mask = TimeMark::every_type ) const

Iterator for the begin mimics container-like of TimeMarks.

Definition at line 149 of file time_marks.cc.

Here is the caller graph for this function:

TimeMarks::iterator TimeMarks::end ( TimeMark::Type mask = TimeMark::every_type ) const

Iterator for the end mimics container-like of TimeMarks.

Definition at line 156 of file time_marks.cc.

Here is the caller graph for this function:

bool TimeMarks::is_current	(	const TimeGovernor &	tg,
		const TimeMark::Type &	mask
	)		const

Find the last time mark matching given mask, and returns true if it is in the time interval of current time step.

Definition at line 108 of file time_marks.cc.

TimeMarks::iterator TimeMarks::last	(	const TimeGovernor &	tg,
		const TimeMark::Type &	mask
	)		const

Return the last TimeMark with time less or equal to tg.time() that match the mask. The time governor tg is used also for time comparisons.

Parameters

tg	the time governor
mask	mask of marks to iterate on

Definition at line 127 of file time_marks.cc.

Here is the caller graph for this function:

TimeMarks::iterator TimeMarks::last ( const TimeMark::Type & mask ) const

Returns iterator to the last time mark matching given mask.

Definition at line 140 of file time_marks.cc.

TimeMark::Type TimeMarks::new_mark_type ( )

Add a new base mark within the context of the particular TimeMarks instance. User should keep the returned value (MarkType is basically a bitmap) for further queries and TimeMark insertions. ATTENTION: You can not use the TimeMark::Type with other TimeMarks instance! Types are added as they are prepared in next_mark_type_. Next mark type is updated by (left) bit shifting operator.

Definition at line 66 of file time_marks.cc.

Here is the caller graph for this function:

TimeMarks::iterator TimeMarks::next	(	const TimeGovernor &	tg,
		const TimeMark::Type &	mask
	)		const

Return the first TimeMark with time strictly greater then tg.time() that match the mask. The time governor tg is used also for time comparisons.

Parameters

tg	the time governor
mask	mask of marks to iterate on

TODO: have also method which accepts double (time) instead of the whole TimeGovernor. and compare without safety.

Definition at line 116 of file time_marks.cc.

void TimeMarks::reinit ( )

Reset state after construction (through default constructor). Useful for unit tests.

Definition at line 51 of file time_marks.cc.

Here is the caller graph for this function:

TimeMark::Type TimeMarks::type_fixed_time ( )

inline

Predefined base TimeMark type that is taken into account by the TimeGovernor. Is defined by constructor as 0x01.

Definition at line 185 of file time_marks.hh.

TimeMark::Type TimeMarks::type_input ( )

inline

Predefined base TimeMark type for times when the boundary condition is changed. Is defined by constructor as 0x04.

Definition at line 195 of file time_marks.hh.

Here is the caller graph for this function:

TimeMark::Type TimeMarks::type_output ( )

inline

Predefined base TimeMark type for output times. Is defined by constructor as 0x02.

Definition at line 190 of file time_marks.hh.

Here is the caller graph for this function:

Friends And Related Function Documentation

std::ostream& operator<<	(	std::ostream &	stream,
		const TimeMarks &	marks
	)

friend

Friend output operator.

Member Data Documentation

std::vector<TimeMark> TimeMarks::marks_

private

TimeMarks list sorted according to the their time.

Definition at line 263 of file time_marks.hh.

TimeMark::Type TimeMarks::next_mark_type_

private

MarkType that will be used at next new_time_mark() call.

Definition at line 260 of file time_marks.hh.

TimeMark::Type TimeMarks::type_fixed_time_

private

Predefined type for fixed time.

Definition at line 266 of file time_marks.hh.

TimeMark::Type TimeMarks::type_input_

private

Predefined type for change of boundary condition.

Definition at line 270 of file time_marks.hh.

TimeMark::Type TimeMarks::type_output_

private

Predefined type for output.

Definition at line 268 of file time_marks.hh.

The documentation for this class was generated from the following files:

/home/cygwin64/F123-windows-release/flow123d/src/tools/time_marks.hh
/home/cygwin64/F123-windows-release/flow123d/src/tools/time_marks.cc
