??? More...

#include <vector>
#include <mpi.h>
#include "mesh/mesh_types.hh"
#include "mesh/nodes.hh"
#include "mesh/elements.h"
#include "mesh/sides.h"
#include "mesh/edges.h"
#include "mesh/neighbours.h"
#include "mesh/boundaries.h"
#include "mesh/intersection.hh"
#include "input/input_type.hh"
#include "input/accessors.hh"
#include "boost/shared_ptr.hpp"
#include "mesh/side_impl.hh"
#include "mesh/element_impls.hh"
#include "mesh/neighbours_impl.hh"

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	ElementAccessor< spacedim >

class	BoundarySegment

class	Mesh

Macros
#define	ELM 0

#define	BC 1

#define	NODE 2

#define	MESH_CRITICAL_VOLUME 1.0E-12

#define	FOR_NODES(_mesh_, i)

#define	NODE_FULL_ITER(_mesh_, i) (_mesh_)->node_vector.full_iter(i)

#define	NODE_FULL_ITER_NULL(_mesh_) NodeFullIter((_mesh_)->node_vector)

#define	ELEM_FULL_ITER(_mesh_, i) (_mesh_)->element.full_iter(i)

#define	FOR_NODE_ELEMENTS(i, j) for((j)=0;(j)<(i)->n_elements();(j)++)

#define	FOR_NODE_SIDES(i, j) for((j)=0;(j)<(i)->n_sides;(j)++)

#define	FOR_ELEMENTS(_mesh_, __i)

#define	ELEMENT_FULL_ITER(_mesh_, i) (_mesh_)->element.full_iter(i)

#define	ELEMENT_FULL_ITER_NULL(_mesh_) ElementFullIter((_mesh_)->element)

#define	FOR_BOUNDARIES(_mesh_, i)

#define	BOUNDARY_FULL_ITER(_mesh_, i) (_mesh_)->boundary.full_iter(i)

#define	BOUNDARY_NULL(_mesh_) BoundaryFullIter((_mesh_)->boundary)

#define	FOR_EDGES(_mesh_, __i)

#define	FOR_SIDES(_mesh_, it)

#define	FOR_SIDE_NODES(i, j) for((j)=0;(j)<(i)->n_nodes;(j)++)

#define	FOR_NEIGHBOURS(_mesh_, it)

#define	FOR_NEIGH_ELEMENTS(i, j) for((j)=0;(j)<(i)->n_elements;(j)++)

#define	FOR_NEIGH_SIDES(i, j) for((j)=0;(j)<(i)->n_sides;(j)++)

Detailed Description

???

Please make a following refer to Flow123d on your project site if you use the program for any purpose, especially for academic research: Flow123d, Research Centre: Advanced Remedial Technologies, Technical University of Liberec, Czech Republic

This program is free software; you can redistribute it and/or modify it under the terms of the GNU General Public License version 3 as published by the Free Software Foundation.

This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details.

You should have received a copy of the GNU General Public License along with this program; if not, write to the Free Software Foundation, Inc., 59 Temple Place - Suite 330, Boston, MA 021110-1307, USA.

$Id$ $Revision$ $LastChangedBy$ $LastChangedDate$

Definition in file mesh.h.

Macro Definition Documentation

#define BC 1

Definition at line 58 of file mesh.h.

#define BOUNDARY_FULL_ITER	(	_mesh_,
		i
	)	(_mesh_)->boundary.full_iter(i)

Macro for conversion form Iter to FullIter for boundaries.

Definition at line 385 of file mesh.h.

#define BOUNDARY_NULL ( _mesh_) BoundaryFullIter((_mesh_)->boundary)

Macro to get "NULL" BoundaryFullIter.

Definition at line 391 of file mesh.h.

#define ELEM_FULL_ITER	(	_mesh_,
		i
	)	(_mesh_)->element.full_iter(i)

Macro for conversion form Iter to FullIter for elements.

Definition at line 91 of file mesh.h.

#define ELEMENT_FULL_ITER	(	_mesh_,
		i
	)	(_mesh_)->element.full_iter(i)

Macro for conversion form Iter to FullIter for elements.

Definition at line 367 of file mesh.h.

#define ELEMENT_FULL_ITER_NULL ( _mesh_) ElementFullIter((_mesh_)->element)

Macro to get "NULL" ElementFullIter.

Definition at line 373 of file mesh.h.

#define ELM 0

Definition at line 57 of file mesh.h.

#define FOR_BOUNDARIES	(	_mesh_,
		i
	)

Value:

for( std::vector<Boundary>::iterator i= (_mesh_)->boundary_.begin(); \
    i != (_mesh_)->boundary_.end(); \
    ++i)

Definition at line 377 of file mesh.h.

#define FOR_EDGES	(	_mesh_,
		__i
	)

Value:

for( vector<Edge>::iterator __i = (_mesh_)->edges.begin(); \
        __i !=(_mesh_)->edges.end(); \
        ++__i)

Provides for statement to iterate over the Edges of the Mesh. see FOR_ELEMENTS

Definition at line 398 of file mesh.h.

#define FOR_ELEMENTS	(	_mesh_,
		__i
	)

Value:

for( ElementFullIter __i( (_mesh_)->element.begin() ); \
        __i != (_mesh_)->element.end(); \
        ++__i)

Provides for statement to iterate over the Elements of the Mesh. The parameter is FullIter local variable of the cycle, so it need not be declared before. Macro assume that variable Mesh *mesh; is declared and points to a valid Mesh structure.

Definition at line 359 of file mesh.h.

#define FOR_NEIGH_ELEMENTS	(	i,
		j
	)	for((j)=0;(j)<(i)->n_elements;(j)++)

Definition at line 414 of file mesh.h.

#define FOR_NEIGH_SIDES	(	i,
		j
	)	for((j)=0;(j)<(i)->n_sides;(j)++)

Definition at line 415 of file mesh.h.

#define FOR_NEIGHBOURS	(	_mesh_,
		it
	)

Value:

for( std::vector<Neighbour>::iterator it = (_mesh_)->vb_neighbours_.begin(); \

(it)!= (_mesh_)->vb_neighbours_.end(); ++it)

Definition at line 410 of file mesh.h.

#define FOR_NODE_ELEMENTS	(	i,
		j
	)	for((j)=0;(j)<(i)->n_elements();(j)++)

Definition at line 95 of file mesh.h.

#define FOR_NODE_SIDES	(	i,
		j
	)	for((j)=0;(j)<(i)->n_sides;(j)++)

Definition at line 96 of file mesh.h.

#define FOR_NODES	(	_mesh_,
		i
	)

Value:

for( NodeFullIter i( (_mesh_)->node_vector.begin() ); \
        i != (_mesh_)->node_vector.end(); \
        ++i)

Provides for statement to iterate over the Nodes of the Mesh. The parameter is FullIter local variable of the cycle, so it need not be declared before. Macro assume that variable Mesh *mesh; is declared and points to a valid Mesh structure.

Definition at line 71 of file mesh.h.

#define FOR_SIDE_NODES	(	i,
		j
	)	for((j)=0;(j)<(i)->n_nodes;(j)++)

Definition at line 407 of file mesh.h.

#define FOR_SIDES	(	_mesh_,
		it
	)

Value:

FOR_ELEMENTS((_mesh_), ele) \

for(SideIter it = ele->side(0); it->el_idx() < ele->n_sides(); ++it)

Definition at line 403 of file mesh.h.

#define MESH_CRITICAL_VOLUME 1.0E-12

This parameter limits volume of elements from below.

Definition at line 64 of file mesh.h.

#define NODE 2

Definition at line 59 of file mesh.h.

#define NODE_FULL_ITER	(	_mesh_,
		i
	)	(_mesh_)->node_vector.full_iter(i)

Macro for conversion form Iter to FullIter for nodes.

Definition at line 79 of file mesh.h.

#define NODE_FULL_ITER_NULL ( _mesh_) NodeFullIter((_mesh_)->node_vector)

Macro to get "NULL" ElementFullIter.

Definition at line 85 of file mesh.h.
