ConvectionTransport::EqData Class Reference

#include <transport.h>

Inheritance diagram for ConvectionTransport::EqData:

Collaboration diagram for ConvectionTransport::EqData:

Public Member Functions
	EqData ()
virtual	~EqData ()
RegionSet	read_boundary_list_item (Input::Record rec)
	Override generic method in order to allow specification of the boundary conditions through the old bcd files. More...
Public Member Functions inherited from TransportBase::TransportEqData
	TransportEqData ()
virtual	~TransportEqData ()
Public Member Functions inherited from FieldSet
	DECLARE_EXCEPTION (ExcUnknownField,<< "Field set has no field with name: "<< FieldCommonBase::EI_Field::qval)
Input::Type::Record	make_field_descriptor_type (const std::string &equation_name) const
Input::Type::Selection	make_output_field_selection (const string &name, const string &desc="")
void	set_field (const std::string &dest_field_name, FieldCommonBase &source)
FieldCommonBase &	get_field (const std::string &field_name) const
void	set_mesh (const Mesh &mesh)
void	set_input_list (Input::Array input_list)
void	set_limit_side (LimitSide side)
void	mark_input_times (TimeMark::Type mark_type)
bool	changed () const
bool	is_constant (Region reg) const
void	set_time (const TimeGovernor &time)
void	output_type (OutputTime::DiscreteSpace rt)
void	output (OutputTime *stream)
FieldCommonBase &	add_field (FieldCommonBase *field, const string &name, const string &desc, const string &d_val="")

Public Attributes
BCField< 3, FieldValue < 3 >::Vector >	bc_conc
Field< 3, FieldValue< 3 >::Vector >	init_conc
	Initial concentrations. More...
MultiField< 3, FieldValue < 3 >::Scalar >	conc_mobile
	Calculated concentrations in the mobile zone. More...
FieldSet	output_fields
	Fields indended for output, i.e. all input fields plus those representing solution. More...
Public Attributes inherited from TransportBase::TransportEqData
Field< 3, FieldValue< 3 >::Scalar >	porosity
	Mobile porosity. More...
Field< 3, FieldValue< 3 >::Scalar >	cross_section
	Pointer to DarcyFlow field cross_section. More...
Field< 3, FieldValue< 3 >::Vector >	sources_density
	Concentration sources - density of substance source, only positive part is used. More...
Field< 3, FieldValue< 3 >::Vector >	sources_sigma
	Concentration sources - Robin type, in_flux = sources_sigma * (sources_conc - mobile_conc) More...
Field< 3, FieldValue< 3 >::Vector >	sources_conc

Static Public Attributes
static Input::Type::Selection	sorption_type_selection
static Input::Type::Selection	output_selection

Additional Inherited Members
Protected Member Functions inherited from FieldSet
FieldCommonBase *	field_by_name (const std::string &field_name) const
Protected Attributes inherited from FieldSet
std::vector< FieldCommonBase * >	field_list
	List of all fields. More...
const Mesh *	mesh_ = nullptr
	value set by last set_mesh(); set the same to added fields More...
Input::Array	input_list_
	value set by last set_input_list(); set the same to added fields More...
LimitSide	side_ = LimitSide::unknown
	value set by last set_time_limit(); set the same to added fields More...

Detailed Description

Definition at line 85 of file transport.h.

Constructor & Destructor Documentation

ConvectionTransport::EqData::EqData

(

)

Definition at line 84 of file transport.cc.

virtual ConvectionTransport::EqData::~EqData ( )

inlinevirtual

Definition at line 92 of file transport.h.

Member Function Documentation

RegionSet ConvectionTransport::EqData::read_boundary_list_item

(

Input::Record

rec)

Override generic method in order to allow specification of the boundary conditions through the old bcd files.

Member Data Documentation

BCField<3, FieldValue<3>::Vector> ConvectionTransport::EqData::bc_conc

Boundary conditions (Dirichlet) for concentrations. They are applied only on water inflow part of the boundary.

Definition at line 101 of file transport.h.

MultiField<3, FieldValue<3>::Scalar> ConvectionTransport::EqData::conc_mobile

Calculated concentrations in the mobile zone.

Definition at line 113 of file transport.h.

Field<3, FieldValue<3>::Vector> ConvectionTransport::EqData::init_conc

Initial concentrations.

Definition at line 104 of file transport.h.

FieldSet ConvectionTransport::EqData::output_fields

Fields indended for output, i.e. all input fields plus those representing solution.

Definition at line 116 of file transport.h.

IT::Selection ConvectionTransport::EqData::output_selection

static

Initial value:

=
        EqData().output_fields.make_output_field_selection("ConvectionTransport_Output")
        .close()

Definition at line 89 of file transport.h.

IT::Selection ConvectionTransport::EqData::sorption_type_selection

static

Initial value:

= IT::Selection("TransportSorptionType")
    .add_value(none,"none","No sorption considered")
    .add_value(Isotherm::linear,"linear","Linear isotherm described sorption considered.")
    .add_value(Isotherm::freundlich,"freundlich","Freundlich isotherm described sorption considered")
    .add_value(Isotherm::langmuir,"langmuir","Langmuir isotherm described sorption considered")
    .close()

Definition at line 87 of file transport.h.

---

The documentation for this class was generated from the following files:

• /home/jb/workspace/flow123d/src/transport/transport.h
• /home/jb/workspace/flow123d/src/transport/transport.cc
