#include <integral_acc.hh>

Inheritance diagram for BulkIntegralAcc< qdim >:

Collaboration diagram for BulkIntegralAcc< qdim >:

[legend]

Public Member Functions
	BulkIntegralAcc ()
	Default constructor. More...

	BulkIntegralAcc (std::shared_ptr< EvalPoints > eval_points, Quadrature quad, PatchFEValues< 3 > pfev, ElementCacheMap *element_cache_map)
	Constructor of bulk integral. More...

	~BulkIntegralAcc ()
	Destructor. More...

Range< BulkPoint >	points (unsigned int element_patch_idx) const
	Returns range of bulk local points for appropriate cell accessor. More...

FeQ< Scalar >	JxW ()
	Register the product of Jacobian determinant and the quadrature weight at bulk quadrature points. More...

FeQ< Vector >	coords ()
	Create bulk accessor of coords entity. More...

ElQ< Scalar >	determinant ()
	Create bulk accessor of jac determinant entity. More...

FeQArray< Scalar >	scalar_shape (uint component_idx=0)
	Return the value of the `function_no-th` shape function at the `p` bulk quadrature point. More...

FeQArray< Vector >	vector_shape (uint component_idx=0)
	Return the value of the `function_no-th` vector shape function at the `p` bulk quadrature point. More...

FeQArray< Vector >	grad_scalar_shape (uint component_idx=0)
	Return the value of the `function_no-th` gradient shape function at the `p` bulk quadrature point. More...

FeQArray< Tensor >	grad_vector_shape (uint component_idx=0)
	Return the value of the `function_no-th` gradient vector shape function at the `p` bulk quadrature point. More...

FeQArray< Tensor >	vector_sym_grad (uint component_idx=0)
	Return the value of the `function_no-th` vector symmetric gradient at the `p` bulk quadrature point. More...

FeQArray< Scalar >	vector_divergence (uint component_idx=0)
	Return the value of the `function_no-th` vector divergence at the `p` bulk quadrature point. More...

Public Member Functions inherited from BulkIntegral
	BulkIntegral ()
	Default constructor. More...

	BulkIntegral (std::shared_ptr< EvalPoints > eval_points, Quadrature *quad, unsigned int dim)
	Constructor of bulk integral. More...

	~BulkIntegral ()
	Destructor. More...

int	get_subset_idx () const
	Return index of data block according to subset in EvalPoints object. More...

Range< BulkPoint >	points (unsigned int element_patch_idx, const ElementCacheMap *elm_cache_map) const
	Returns range of bulk local points for appropriate cell accessor - obsolete method. More...

Public Member Functions inherited from internal::BaseIntegral
	BaseIntegral ()
	Default constructor. More...

	BaseIntegral (std::shared_ptr< EvalPoints > eval_points, unsigned int dim)
	Constructor of bulk or side subset. More...

virtual	~BaseIntegral ()
	Destructor. More...

std::shared_ptr< EvalPoints >	eval_points () const
	Getter of eval_points. More...

unsigned int	dim () const
	Returns dimension. More...

Private Attributes
internal::IntegralFactory< qdim >	factory_
	Defines interface of operation accessors declaration. More...

Additional Inherited Members
Protected Attributes inherited from BulkIntegral
std::shared_ptr< internal_integrals::Bulk >	internal_bulk_
	Internal integral object. More...

Protected Attributes inherited from internal::BaseIntegral
std::shared_ptr< EvalPoints >	eval_points_
	Pointer to EvalPoints. More...

unsigned int	dim_
	Dimension of the cell on which points are placed. More...

Detailed Description

template<unsigned int qdim>
class BulkIntegralAcc< qdim >

New Integral accessor class, replace of BulkIntegral, will be merged with BulkIntegral

IN DEVELOPMENT

Definition at line 306 of file integral_acc.hh.

Constructor & Destructor Documentation

◆ BulkIntegralAcc() [1/2]

template<unsigned int qdim>

BulkIntegralAcc< qdim >::BulkIntegralAcc ( )

inline

Default constructor.

Definition at line 309 of file integral_acc.hh.

◆ BulkIntegralAcc() [2/2]

template<unsigned int qdim>

BulkIntegralAcc< qdim >::BulkIntegralAcc	(	std::shared_ptr< EvalPoints >	eval_points,
		Quadrature *	quad,
		PatchFEValues< 3 > *	pfev,
		ElementCacheMap *	element_cache_map
	)

inline

Constructor of bulk integral.

Definition at line 312 of file integral_acc.hh.

◆ ~BulkIntegralAcc()

template<unsigned int qdim>

BulkIntegralAcc< qdim >::~BulkIntegralAcc ( )

inline

Destructor.

Definition at line 320 of file integral_acc.hh.

Member Function Documentation

◆ coords()

template<unsigned int qdim>

FeQ<Vector> BulkIntegralAcc< qdim >::coords ( )

inline

Create bulk accessor of coords entity.

Definition at line 342 of file integral_acc.hh.

◆ determinant()

template<unsigned int qdim>

ElQ<Scalar> BulkIntegralAcc< qdim >::determinant ( )

inline

Create bulk accessor of jac determinant entity.

Definition at line 351 of file integral_acc.hh.

◆ grad_scalar_shape()

template<unsigned int qdim>

FeQArray<Vector> BulkIntegralAcc< qdim >::grad_scalar_shape ( uint component_idx = 0 )

inline

Return the value of the function_no-th gradient shape function at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 387 of file integral_acc.hh.

◆ grad_vector_shape()

template<unsigned int qdim>

FeQArray<Tensor> BulkIntegralAcc< qdim >::grad_vector_shape ( uint component_idx = 0 )

inline

Return the value of the function_no-th gradient vector shape function at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 398 of file integral_acc.hh.

◆ JxW()

template<unsigned int qdim>

FeQ<Scalar> BulkIntegralAcc< qdim >::JxW ( )

inline

Register the product of Jacobian determinant and the quadrature weight at bulk quadrature points.

Parameters

quad	Quadrature.

Definition at line 336 of file integral_acc.hh.

◆ points()

template<unsigned int qdim>

Range< BulkPoint > BulkIntegralAcc< qdim >::points ( unsigned int element_patch_idx ) const

inline

Returns range of bulk local points for appropriate cell accessor.

Definition at line 324 of file integral_acc.hh.

◆ scalar_shape()

template<unsigned int qdim>

FeQArray<Scalar> BulkIntegralAcc< qdim >::scalar_shape ( uint component_idx = 0 )

inline

Return the value of the function_no-th shape function at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 362 of file integral_acc.hh.

◆ vector_divergence()

template<unsigned int qdim>

FeQArray<Scalar> BulkIntegralAcc< qdim >::vector_divergence ( uint component_idx = 0 )

inline

Return the value of the function_no-th vector divergence at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 420 of file integral_acc.hh.

◆ vector_shape()

template<unsigned int qdim>

FeQArray<Vector> BulkIntegralAcc< qdim >::vector_shape ( uint component_idx = 0 )

inline

Return the value of the function_no-th vector shape function at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 373 of file integral_acc.hh.

◆ vector_sym_grad()

template<unsigned int qdim>

FeQArray<Tensor> BulkIntegralAcc< qdim >::vector_sym_grad ( uint component_idx = 0 )

inline

Return the value of the function_no-th vector symmetric gradient at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 409 of file integral_acc.hh.

Member Data Documentation

◆ factory_

template<unsigned int qdim>

internal::IntegralFactory<qdim> BulkIntegralAcc< qdim >::factory_

private

Defines interface of operation accessors declaration.

Definition at line 427 of file integral_acc.hh.

The documentation for this class was generated from the following files:

/home/runner/work/flow123d/flow123d/src/fem/eval_points.hh
/home/runner/work/flow123d/flow123d/src/fem/integral_acc.hh
