BulkPoint Class Reference

Base point accessor class. More...

#include <integral_points.hh>

Inheritance diagram for BulkPoint:

Collaboration diagram for BulkPoint:

Public Member Functions
	BulkPoint ()
	Default constructor. More...
	BulkPoint (const ElementCacheMap *elm_cache_map, uint elem_idx, uint loc_point_idx)
	Constructor. More...
std::shared_ptr< EvalPoints >	eval_points () const
	Getter of EvalPoints object. More...
const ElementCacheMap *	elm_cache_map () const
unsigned int	elem_patch_idx () const
unsigned int	eval_point_idx () const
	Return index in EvalPoints object. More...
unsigned int	value_cache_idx () const
	Return index in ElementCacheMap. More...
void	inc ()
	Iterates to next point. More...
bool	operator== (const BulkPoint &other)
	Comparison of accessors. More...

Protected Attributes
const ElementCacheMap *	elm_cache_map_
unsigned int	elem_patch_idx_
	Index of element in the patch. More...
unsigned int	local_point_idx_
	Index of the local point in the integral object. More...

Detailed Description

Base point accessor class.

Point accessor allow iterate over bulk quadrature points defined in local element coordinates.

Definition at line 53 of file integral_points.hh.

Constructor & Destructor Documentation

BulkPoint() [1/2]

BulkPoint::BulkPoint ( )

inline

Default constructor.

Definition at line 56 of file integral_points.hh.

Here is the caller graph for this function:

BulkPoint() [2/2]

BulkPoint::BulkPoint ( const ElementCacheMap *  elm_cache_map, uint  elem_idx, uint  loc_point_idx  )

inline

Constructor.

Definition at line 60 of file integral_points.hh.

Member Function Documentation

elem_patch_idx()

unsigned int BulkPoint::elem_patch_idx ( ) const

inline

Definition at line 77 of file integral_points.hh.

Here is the caller graph for this function:

elm_cache_map()

const ElementCacheMap* BulkPoint::elm_cache_map ( ) const

inline

Definition at line 71 of file integral_points.hh.

Here is the caller graph for this function:

eval_point_idx()

unsigned int BulkPoint::eval_point_idx ( ) const

inline

Return index in EvalPoints object.

Definition at line 82 of file integral_points.hh.

Here is the caller graph for this function:

eval_points()

std::shared_ptr<EvalPoints> BulkPoint::eval_points ( ) const

inline

Getter of EvalPoints object.

Definition at line 65 of file integral_points.hh.

inc()

void BulkPoint::inc ( )

inline

Iterates to next point.

Definition at line 92 of file integral_points.hh.

operator==()

bool BulkPoint::operator== ( const BulkPoint &  other )

inline

Comparison of accessors.

Definition at line 97 of file integral_points.hh.

value_cache_idx()

unsigned int BulkPoint::value_cache_idx ( ) const

inline

Return index in ElementCacheMap.

Definition at line 87 of file integral_points.hh.

Here is the caller graph for this function:

Member Data Documentation

elem_patch_idx_

unsigned int BulkPoint::elem_patch_idx_

protected

Index of element in the patch.

Definition at line 106 of file integral_points.hh.

elm_cache_map_

const ElementCacheMap* BulkPoint::elm_cache_map_

protected

Definition at line 104 of file integral_points.hh.

local_point_idx_

unsigned int BulkPoint::local_point_idx_

protected

Index of the local point in the integral object.

Definition at line 108 of file integral_points.hh.

---

The documentation for this class was generated from the following file:

• /home/runner/work/flow123d/flow123d/src/fem/integral_points.hh
