Calculates finite element data on a side. More...

#include <fe_values.hh>

Inheritance diagram for FESideValues< dim, spacedim >:

Collaboration diagram for FESideValues< dim, spacedim >:

Public Member Functions
	FESideValues (Mapping< dim, spacedim > &_mapping, Quadrature< dim-1 > &_sub_quadrature, FiniteElement< dim, spacedim > &_fe, UpdateFlags flags)
	Constructor. More...

virtual	~FESideValues ()
	Destructor. More...

void	reinit (ElementFullIter &cell, unsigned int sid)
	Update cell-dependent data (gradients, Jacobians etc.) More...

Public Member Functions inherited from FEValuesBase< dim, spacedim >
	FEValuesBase ()
	Default constructor. More...

virtual	~FEValuesBase ()

void	allocate (Mapping< dim, spacedim > &_mapping, Quadrature< dim > &_quadrature, FiniteElement< dim, spacedim > &_fe, UpdateFlags flags)
	Allocates space for computed data. More...

UpdateFlags	update_each (UpdateFlags flags)
	Determine quantities to be recomputed on each cell. More...

double	shape_value (const unsigned int function_no, const unsigned int point_no)
	Return the value of the `function_no-th` shape function at the `point_no-th` quadrature point. More...

arma::vec::fixed< spacedim >	shape_grad (const unsigned int function_no, const unsigned int point_no)
	Return the gradient of the `function_no-th` shape function at the `point_no-th` quadrature point. More...

arma::vec::fixed< spacedim >	shape_vector (const unsigned int function_no, const unsigned int point_no)
	Return the value of the `function_no-th` shape function at the `point_no-th` quadrature point. More...

arma::mat::fixed< spacedim, spacedim >	shape_grad_vector (const unsigned int function_no, const unsigned int point_no)
	Return the gradient of the `function_no-th` shape function at the `point_no-th` quadrature point. More...

double	determinant (const unsigned int point_no)
	Return the relative volume change of the cell (Jacobian determinant). More...

double	JxW (const unsigned int point_no)
	Return the product of Jacobian determinant and the quadrature weight at given quadrature point. More...

arma::vec::fixed< spacedim >	point (const unsigned int point_no)
	Return coordinates of the quadrature point in the actual cell system. More...

vector< arma::vec::fixed < spacedim > > &	point_list ()
	Return coordinates of all quadrature points in the actual cell system. More...

arma::vec::fixed< spacedim >	normal_vector (unsigned int point_no)
	Returns the normal vector to a side at given quadrature point. More...

unsigned int	n_points ()
	Returns the number of quadrature points. More...

unsigned int	n_dofs ()
	Returns the number of shape functions. More...

Quadrature< dim > *	get_quadrature () const
	Returns the quadrature in use. More...

FiniteElement< dim, spacedim > *	get_fe () const
	Returns the finite element in use. More...

Mapping< dim, spacedim > *	get_mapping () const
	Returns the mapping in use. More...

Public Member Functions inherited from FEValuesSpaceBase< spacedim >
virtual	~FEValuesSpaceBase ()

Private Attributes
const Quadrature< dim-1 > *	sub_quadrature
	Quadrature for the integration on the element sides. More...

Quadrature< dim >	side_quadrature [RefElement< dim >::n_sides][RefElement< dim >::n_side_permutations]

MappingInternalData *	side_mapping_data [RefElement< dim >::n_sides][RefElement< dim >::n_side_permutations]

FEInternalData *	side_fe_data [RefElement< dim >::n_sides][RefElement< dim >::n_side_permutations]

Additional Inherited Members
Protected Attributes inherited from FEValuesBase< dim, spacedim >
Mapping< dim, spacedim > *	mapping
	The mapping from the reference cell to the actual cell. More...

Quadrature< dim > *	quadrature
	The quadrature rule used to calculate integrals. More...

FiniteElement< dim, spacedim > *	fe
	The used finite element. More...

MappingInternalData *	mapping_data
	Precomputed mapping data. More...

FEInternalData *	fe_data
	Precomputed finite element data. More...

FEValuesData< dim, spacedim >	data
	Data computed by the mapping and finite element. More...

Detailed Description

template<unsigned int dim, unsigned int spacedim>
class FESideValues< dim, spacedim >

Calculates finite element data on a side.

FESideValues takes care of the calculation of finite element data on a side of the actual cell such as values of shape functions at quadrature points, gradients of shape functions, Jacobians of the mapping from the reference cell etc.

Parameters

dim	Dimension of the reference cell.
spacedim	Dimension of the Euclidean space where the actual cell lives.

Definition at line 461 of file fe_values.hh.

Constructor & Destructor Documentation

template<unsigned int dim, unsigned int spacedim>

FESideValues< dim, spacedim >::FESideValues	(	Mapping< dim, spacedim > &	_mapping,
		Quadrature< dim-1 > &	_sub_quadrature,
		FiniteElement< dim, spacedim > &	_fe,
		UpdateFlags	flags
	)

Constructor.

Initializes structures and calculates cell-independent data.

Parameters

_mapping	The mapping between the reference and actual cell.
_sub_quadrature	The quadrature rule on the side.
_fe	The finite element.
flags	The update flags.

Definition at line 182 of file fe_values.cc.

template<unsigned int dim, unsigned int spacedim>

FESideValues< dim, spacedim >::~FESideValues ( )

virtual

Destructor.

Definition at line 207 of file fe_values.cc.

Member Function Documentation

template<unsigned int dim, unsigned int spacedim>

void FESideValues< dim, spacedim >::reinit	(	ElementFullIter &	cell,
		unsigned int	sid
	)

Update cell-dependent data (gradients, Jacobians etc.)

Parameters

cell	The actual cell.
sid	Number of the side of the cell.

Definition at line 225 of file fe_values.cc.

Here is the caller graph for this function:

Member Data Documentation

template<unsigned int dim, unsigned int spacedim>

FEInternalData* FESideValues< dim, spacedim >::side_fe_data[RefElement< dim >::n_sides][RefElement< dim >::n_side_permutations]

private

Definition at line 507 of file fe_values.hh.

template<unsigned int dim, unsigned int spacedim>

MappingInternalData* FESideValues< dim, spacedim >::side_mapping_data[RefElement< dim >::n_sides][RefElement< dim >::n_side_permutations]

private

Definition at line 505 of file fe_values.hh.

template<unsigned int dim, unsigned int spacedim>

Quadrature<dim> FESideValues< dim, spacedim >::side_quadrature[RefElement< dim >::n_sides][RefElement< dim >::n_side_permutations]

private

Definition at line 503 of file fe_values.hh.

template<unsigned int dim, unsigned int spacedim>

const Quadrature<dim-1>* FESideValues< dim, spacedim >::sub_quadrature

private

Quadrature for the integration on the element sides.

Definition at line 501 of file fe_values.hh.

The documentation for this class was generated from the following files:

/home/builder/jenkins/F123-linux-release/flow123d/src/fem/fe_values.hh
/home/builder/jenkins/F123-linux-release/flow123d/src/fem/fe_values.cc
