#include <heat_model.hh>

Inheritance diagram for HeatTransferModel:

Collaboration diagram for HeatTransferModel:

Classes
class	ModelEqData

Public Member Functions
	HeatTransferModel ()

void	init_data (unsigned int n_subst_) override
	Initialize model data. E.g. set vector field dimensions. More...

void	set_component_names (std::vector< string > &names, const Input::Record &in_rec) override
	Temporary solution for sharing data from other equations. More...

bool	mass_matrix_changed () override
	Check if mass matrix coefficients have changed. More...

bool	stiffness_matrix_changed () override
	Check if stiffness matrix coefficients have changed. More...

bool	rhs_changed () override
	Check if right hand side coefficients have changed. More...

void	compute_mass_matrix_coefficient (const std::vector< arma::vec3 > &point_list, const ElementAccessor< 3 > &ele_acc, std::vector< double > &mm_coef) override

void	compute_advection_diffusion_coefficients (const std::vector< arma::vec3 > &point_list, const std::vector< arma::vec3 > &velocity, const ElementAccessor< 3 > &ele_acc, std::vector< std::vector< arma::vec3 > > &ad_coef, std::vector< std::vector< arma::mat33 > > &dif_coef) override

void	compute_init_cond (const std::vector< arma::vec3 > &point_list, const ElementAccessor< 3 > &ele_acc, std::vector< arma::vec > &init_values) override

void	compute_dirichlet_bc (const std::vector< arma::vec3 > &point_list, const ElementAccessor< 3 > &ele_acc, std::vector< arma::vec > &bc_values) override

void	compute_source_coefficients (const std::vector< arma::vec3 > &point_list, const ElementAccessor< 3 > &ele_acc, std::vector< arma::vec > &sources_conc, std::vector< arma::vec > &sources_density, std::vector< arma::vec > &sources_sigma) override

void	compute_sources_sigma (const std::vector< arma::vec3 > &point_list, const ElementAccessor< 3 > &ele_acc, std::vector< arma::vec > &sources_sigma) override

	~HeatTransferModel () override

Public Member Functions inherited from AdvectionDiffusionModel
virtual	~AdvectionDiffusionModel ()
	Destructor. More...

Protected Member Functions
virtual ModelEqData &	data ()=0
	Derived class should implement getter for ModelEqData instance. More...

Static Protected Member Functions
static IT::Record &	get_input_type (const string &implementation, const string &description)

Protected Attributes
bool	flux_changed
	Indicator of change in advection vector field. More...

Detailed Description

Definition at line 38 of file heat_model.hh.

Constructor & Destructor Documentation

HeatTransferModel::HeatTransferModel ( )

Definition at line 94 of file heat_model.cc.

HeatTransferModel::~HeatTransferModel ( )

override

Definition at line 300 of file heat_model.cc.

Member Function Documentation

void HeatTransferModel::compute_advection_diffusion_coefficients	(	const std::vector< arma::vec3 > &	point_list,
		const std::vector< arma::vec3 > &	velocity,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< std::vector< arma::vec3 > > &	ad_coef,
		std::vector< std::vector< arma::mat33 > > &	dif_coef
	)

overridevirtual

Compute coefficients of stiffness matrix.

Parameters

point_list	Points at which to evaluate.
velocity	Velocity field (input). Temporary solution before we can pass data from other equations.
ele_acc	Element accessor.
ad_coef	Coefficients of advection (output).
dif_coef	Coefficients of diffusion (output).

Implements AdvectionDiffusionModel.

Definition at line 176 of file heat_model.cc.

void HeatTransferModel::compute_dirichlet_bc	(	const std::vector< arma::vec3 > &	point_list,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< arma::vec > &	bc_values
	)

overridevirtual

Computes the Dirichlet boundary condition values.

Parameters

point_list	Points at which to evaluate.
ele_acc	Element accessor.
bc_values	Vector of b.c. values (output).

Implements AdvectionDiffusionModel.

Definition at line 227 of file heat_model.cc.

void HeatTransferModel::compute_init_cond	(	const std::vector< arma::vec3 > &	point_list,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< arma::vec > &	init_values
	)

overridevirtual

Compute initial conditions.

Parameters

point_list	Points at which to evaluate.
ele_acc	Element accessor.
init_values	Vector of intial values (output).

Implements AdvectionDiffusionModel.

Definition at line 216 of file heat_model.cc.

void HeatTransferModel::compute_mass_matrix_coefficient	(	const std::vector< arma::vec3 > &	point_list,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< double > &	mm_coef
	)

overridevirtual

Compute coefficients of mass matrix.

Parameters

point_list	Points at which to evaluate.
ele_acc	Element accessor.
mm_coef	Coefficient vector (output).

Implements AdvectionDiffusionModel.

Definition at line 153 of file heat_model.cc.

void HeatTransferModel::compute_source_coefficients	(	const std::vector< arma::vec3 > &	point_list,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< arma::vec > &	sources_conc,
		std::vector< arma::vec > &	sources_density,
		std::vector< arma::vec > &	sources_sigma
	)

overridevirtual

Compute coefficients of volume sources.

Parameters

point_list	Points at which to evaluate.
ele_acc	Element accessor.
sources_conc	Source concentrations (output).
sources_density	Source densities (output).
sources_sigma	Source sigmas (output).

Implements AdvectionDiffusionModel.

Definition at line 238 of file heat_model.cc.

void HeatTransferModel::compute_sources_sigma	(	const std::vector< arma::vec3 > &	point_list,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< arma::vec > &	sources_sigma
	)

overridevirtual

Compute coefficients of volume sources.

Parameters

point_list	Points at which to evaluate.
ele_acc	Element accessor.
sources_sigma	Source sigmas (output).

Implements AdvectionDiffusionModel.

Definition at line 277 of file heat_model.cc.

virtual ModelEqData& HeatTransferModel::data ( )

protectedpure virtual

Derived class should implement getter for ModelEqData instance.

Here is the caller graph for this function:

IT::Record & HeatTransferModel::get_input_type	(	const string &	implementation,
		const string &	description
	)

staticprotected

Create input type that can be passed to the derived class.

Parameters

implementation	String characterizing the numerical method, e.g. DG, FEM, FVM.
description	Comment used to describe the record key.

Returns

Definition at line 76 of file heat_model.cc.

void HeatTransferModel::init_data ( unsigned int n_subst_)

overridevirtual

Initialize model data. E.g. set vector field dimensions.

Implements AdvectionDiffusionModel.

Definition at line 99 of file heat_model.cc.

bool HeatTransferModel::mass_matrix_changed ( )

overridevirtual

Check if mass matrix coefficients have changed.

Implements AdvectionDiffusionModel.

Definition at line 116 of file heat_model.cc.

bool HeatTransferModel::rhs_changed ( )

overridevirtual

Check if right hand side coefficients have changed.

Implements AdvectionDiffusionModel.

Definition at line 141 of file heat_model.cc.

void HeatTransferModel::set_component_names	(	std::vector< string > &	names,
		const Input::Record &	in_rec
	)

overridevirtual

Temporary solution for sharing data from other equations.

Read or set names of solution components.

Implements AdvectionDiffusionModel.

Definition at line 109 of file heat_model.cc.

bool HeatTransferModel::stiffness_matrix_changed ( )

overridevirtual

Check if stiffness matrix coefficients have changed.

Implements AdvectionDiffusionModel.

Definition at line 127 of file heat_model.cc.

Member Data Documentation

bool HeatTransferModel::flux_changed

protected

Indicator of change in advection vector field.

Definition at line 112 of file heat_model.hh.

The documentation for this class was generated from the following files:

/home/jb/workspace/flow123d/src/transport/heat_model.hh
/home/jb/workspace/flow123d/src/transport/heat_model.cc
