FEObjects Class Reference

#include <transport_dg.hh>

Collaboration diagram for FEObjects:

Public Member Functions
	FEObjects (Mesh *mesh_, unsigned int fe_order)
	~FEObjects ()
template<unsigned int dim>
FiniteElement< dim, 3 > *	fe ()
template<unsigned int dim>
FiniteElement< dim, 3 > *	fe_rt ()
template<unsigned int dim>
Quadrature< dim > *	q ()
template<unsigned int dim>
Mapping< dim, 3 > *	mapping ()
DOFHandlerMultiDim *	dh ()
template<>
FiniteElement< 0, 3 > *	fe ()
template<>
FiniteElement< 1, 3 > *	fe ()
template<>
FiniteElement< 2, 3 > *	fe ()
template<>
FiniteElement< 3, 3 > *	fe ()
template<>
FiniteElement< 0, 3 > *	fe_rt ()
template<>
FiniteElement< 1, 3 > *	fe_rt ()
template<>
FiniteElement< 2, 3 > *	fe_rt ()
template<>
FiniteElement< 3, 3 > *	fe_rt ()
template<>
Quadrature< 0 > *	q ()
template<>
Quadrature< 1 > *	q ()
template<>
Quadrature< 2 > *	q ()
template<>
Quadrature< 3 > *	q ()
template<>
Mapping< 0, 3 > *	mapping ()
template<>
Mapping< 1, 3 > *	mapping ()
template<>
Mapping< 2, 3 > *	mapping ()
template<>
Mapping< 3, 3 > *	mapping ()

Private Attributes
FiniteElement< 1, 3 > *	fe1_
	Finite elements for the solution of the advection-diffusion equation. More...
FiniteElement< 2, 3 > *	fe2_
FiniteElement< 3, 3 > *	fe3_
FiniteElement< 1, 3 > *	fe_rt1_
	Finite elements for the water velocity field. More...
FiniteElement< 2, 3 > *	fe_rt2_
FiniteElement< 3, 3 > *	fe_rt3_
Quadrature< 0 > *	q0_
	Quadratures used in assembling methods. More...
Quadrature< 1 > *	q1_
Quadrature< 2 > *	q2_
Quadrature< 3 > *	q3_
Mapping< 0, 3 > *	map0_
	Auxiliary mappings of reference elements. More...
Mapping< 1, 3 > *	map1_
Mapping< 2, 3 > *	map2_
Mapping< 3, 3 > *	map3_
DOFHandlerMultiDim *	dh_
	Object for distribution of dofs. More...

Detailed Description

Auxiliary container class for Finite element and related objects of all dimensions. Its purpose is to provide templated access to these objects, applicable in the assembling methods.

Definition at line 53 of file transport_dg.hh.

Constructor & Destructor Documentation

FEObjects::FEObjects	(	Mesh *	mesh_,
		unsigned int	fe_order
	)

Definition at line 92 of file transport_dg.cc.

FEObjects::~FEObjects

(

)

Definition at line 151 of file transport_dg.cc.

Member Function Documentation

DOFHandlerMultiDim * FEObjects::dh ( )

inline

Definition at line 190 of file transport_dg.cc.

template<unsigned int dim>

FiniteElement<dim,3>* FEObjects::fe ( )

inline

template<>

FiniteElement<2,3>* FEObjects::fe

(

)

Definition at line 172 of file transport_dg.cc.

template<>

FiniteElement<3,3>* FEObjects::fe

(

)

Definition at line 173 of file transport_dg.cc.

template<>

FiniteElement<0,3>* FEObjects::fe

(

)

Definition at line 170 of file transport_dg.cc.

template<>

FiniteElement<1,3>* FEObjects::fe

(

)

Definition at line 171 of file transport_dg.cc.

template<unsigned int dim>

FiniteElement<dim,3>* FEObjects::fe_rt ( )

inline

template<>

FiniteElement<0,3>* FEObjects::fe_rt

(

)

Definition at line 175 of file transport_dg.cc.

template<>

FiniteElement<1,3>* FEObjects::fe_rt

(

)

Definition at line 176 of file transport_dg.cc.

template<>

FiniteElement<2,3>* FEObjects::fe_rt

(

)

Definition at line 177 of file transport_dg.cc.

template<>

FiniteElement<3,3>* FEObjects::fe_rt

(

)

Definition at line 178 of file transport_dg.cc.

template<unsigned int dim>

Mapping<dim,3>* FEObjects::mapping ( )

inline

template<>

Mapping<2,3>* FEObjects::mapping

(

)

Definition at line 187 of file transport_dg.cc.

template<>

Mapping<3,3>* FEObjects::mapping

(

)

Definition at line 188 of file transport_dg.cc.

template<>

Mapping<1,3>* FEObjects::mapping

(

)

Definition at line 186 of file transport_dg.cc.

template<>

Mapping<0,3>* FEObjects::mapping

(

)

Definition at line 185 of file transport_dg.cc.

template<unsigned int dim>

Quadrature<dim>* FEObjects::q ( )

inline

template<>

Quadrature<2>* FEObjects::q

(

)

Definition at line 182 of file transport_dg.cc.

template<>

Quadrature<1>* FEObjects::q

(

)

Definition at line 181 of file transport_dg.cc.

template<>

Quadrature<3>* FEObjects::q

(

)

Definition at line 183 of file transport_dg.cc.

template<>

Quadrature<0>* FEObjects::q

(

)

Definition at line 180 of file transport_dg.cc.

Member Data Documentation

DOFHandlerMultiDim* FEObjects::dh_

private

Object for distribution of dofs.

Definition at line 98 of file transport_dg.hh.

FiniteElement<1,3>* FEObjects::fe1_

private

Finite elements for the solution of the advection-diffusion equation.

Definition at line 76 of file transport_dg.hh.

FiniteElement<2,3>* FEObjects::fe2_

private

Definition at line 77 of file transport_dg.hh.

FiniteElement<3,3>* FEObjects::fe3_

private

Definition at line 78 of file transport_dg.hh.

FiniteElement<1,3>* FEObjects::fe_rt1_

private

Finite elements for the water velocity field.

Definition at line 81 of file transport_dg.hh.

FiniteElement<2,3>* FEObjects::fe_rt2_

private

Definition at line 82 of file transport_dg.hh.

FiniteElement<3,3>* FEObjects::fe_rt3_

private

Definition at line 83 of file transport_dg.hh.

Mapping<0,3>* FEObjects::map0_

private

Auxiliary mappings of reference elements.

Definition at line 92 of file transport_dg.hh.

Mapping<1,3>* FEObjects::map1_

private

Definition at line 93 of file transport_dg.hh.

Mapping<2,3>* FEObjects::map2_

private

Definition at line 94 of file transport_dg.hh.

Mapping<3,3>* FEObjects::map3_

private

Definition at line 95 of file transport_dg.hh.

Quadrature<0>* FEObjects::q0_

private

Quadratures used in assembling methods.

Definition at line 86 of file transport_dg.hh.

Quadrature<1>* FEObjects::q1_

private

Definition at line 87 of file transport_dg.hh.

Quadrature<2>* FEObjects::q2_

private

Definition at line 88 of file transport_dg.hh.

Quadrature<3>* FEObjects::q3_

private

Definition at line 89 of file transport_dg.hh.

---

The documentation for this class was generated from the following files:

• /home/jb/workspace/flow123d/src/transport/transport_dg.hh
• /home/jb/workspace/flow123d/src/transport/transport_dg.cc
