#include <heat_model.hh>

Inheritance diagram for HeatTransferModel::ModelEqData:

Collaboration diagram for HeatTransferModel::ModelEqData:

Public Member Functions
	ModelEqData ()

Public Member Functions inherited from FieldSet
	DECLARE_EXCEPTION (ExcUnknownField,<< "Field set has no field with name: "<< FieldCommon::EI_Field::qval)

Input::Type::Record	make_field_descriptor_type (const std::string &equation_name) const

Input::Type::Selection	make_output_field_selection (const string &name, const string &desc="")

void	set_field (const std::string &dest_field_name, FieldCommon &source)

FieldCommon *	field (const std::string &field_name) const

FieldCommon &	operator[] (const std::string &field_name) const

void	set_components (const std::vector< string > &names)

void	set_mesh (const Mesh &mesh)

void	set_input_list (Input::Array input_list)

void	set_limit_side (LimitSide side)

void	flags_add (FieldFlag::Flags::Mask mask)

void	set_time (const TimeStep &time)

void	output_type (OutputTime::DiscreteSpace rt)

void	mark_input_times (TimeMark::Type mark_type)

bool	changed () const

bool	is_constant (Region reg) const

void	output (OutputTime *stream)

FieldCommon &	add_field (FieldCommon *field, const string &name, const string &desc, const string &d_val="")

Static Public Member Functions
static constexpr const char *	name ()

static string	default_output_field ()

static IT::Selection &	get_output_selection_input_type (const string &implementation, const string &description)

Public Attributes
BCField< 3, FieldValue< 3 >::Scalar >	bc_temperature
	Dirichlet boundary condition for temperature. More...

Field< 3, FieldValue< 3 >::Scalar >	init_temperature
	Initial temperature. More...

Field< 3, FieldValue< 3 >::Scalar >	porosity
	Porosity of solid. More...

Field< 3, FieldValue< 3 >::Scalar >	fluid_density
	Density of fluid. More...

Field< 3, FieldValue< 3 >::Scalar >	fluid_heat_capacity
	Heat capacity of fluid. More...

Field< 3, FieldValue< 3 >::Scalar >	fluid_heat_conductivity
	Heat conductivity of fluid. More...

Field< 3, FieldValue< 3 >::Scalar >	solid_density
	Density of solid. More...

Field< 3, FieldValue< 3 >::Scalar >	solid_heat_capacity
	Heat capacity of solid. More...

Field< 3, FieldValue< 3 >::Scalar >	solid_heat_conductivity
	Heat conductivity of solid. More...

Field< 3, FieldValue< 3 >::Scalar >	disp_l
	Longitudal heat dispersivity. More...

Field< 3, FieldValue< 3 >::Scalar >	disp_t
	Transversal heat dispersivity. More...

Field< 3, FieldValue< 3 >::Scalar >	fluid_thermal_source
	Thermal source in fluid. More...

Field< 3, FieldValue< 3 >::Scalar >	solid_thermal_source
	Thermal source in solid. More...

Field< 3, FieldValue< 3 >::Scalar >	fluid_heat_exchange_rate
	Heat exchange rate in fluid. More...

Field< 3, FieldValue< 3 >::Scalar >	solid_heat_exchange_rate
	Heat exchange rate in solid. More...

Field< 3, FieldValue< 3 >::Scalar >	fluid_ref_temperature
	Reference temperature in fluid. More...

Field< 3, FieldValue< 3 >::Scalar >	solid_ref_temperature
	Reference temperature in solid. More...

Field< 3, FieldValue< 3 >::Scalar >	cross_section
	Pointer to DarcyFlow field cross_section. More...

MultiField< 3, FieldValue< 3 >::Scalar >	output_field

Additional Inherited Members
Public Types inherited from FieldFlag
typedef FlagArray< FieldFlag >	Flags

typedef Flags::Mask	Mask

Static Public Attributes inherited from FieldFlag
static constexpr unsigned int	flags_size_ = 3
	Number of bits used by Field itself. More...

static constexpr Mask	equation_input {1}
	The field is data parameter of the owning equation. (default on) More...

static constexpr Mask	declare_input {2}
	The field can be set from input. The key in input field descriptor is declared. (default on) More...

static constexpr Mask	allow_output {4}
	The field can output. Is part of generated output selection. (default on) More...

static constexpr Mask	input_copy = ~declare_input & equation_input
	A field that is input of its equation and can not read from input, thus must be set by copy. More...

static constexpr Mask	in_time_term {8}
	A field is part of time term of the equation. More...

static constexpr Mask	in_main_matrix {16}
	A field is part of main "stiffness matrix" of the equation. More...

static constexpr Mask	in_rhs {32}
	A field is part of the right hand side of the equation. More...

static constexpr Mask	equation_result = allow_output & ~declare_input & ~equation_input
	Match result fields. These are never given by input or copy of input. More...

static constexpr Mask	equation_external_output = allow_output & input_copy
	Match an output field, that can be also copy of other field. More...

Protected Attributes inherited from FieldSet
std::vector< FieldCommon * >	field_list
	List of all fields. More...

Detailed Description

Definition at line 41 of file heat_model.hh.

Constructor & Destructor Documentation

HeatTransferModel::ModelEqData::ModelEqData ( )

Definition at line 51 of file heat_model.cc.

Member Function Documentation

static string HeatTransferModel::ModelEqData::default_output_field ( )

inlinestatic

Definition at line 91 of file heat_model.hh.

IT::Selection & HeatTransferModel::ModelEqData::get_output_selection_input_type	(	const string &	implementation,
		const string &	description
	)

static

Definition at line 200 of file heat_model.cc.

static constexpr const char* HeatTransferModel::ModelEqData::name ( )

inlinestatic

Definition at line 89 of file heat_model.hh.

Member Data Documentation

BCField<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::bc_temperature

Dirichlet boundary condition for temperature.

Definition at line 45 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar > HeatTransferModel::ModelEqData::cross_section

Pointer to DarcyFlow field cross_section.

Definition at line 80 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::disp_l

Longitudal heat dispersivity.

Definition at line 63 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::disp_t

Transversal heat dispersivity.

Definition at line 65 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::fluid_density

Density of fluid.

Definition at line 51 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::fluid_heat_capacity

Heat capacity of fluid.

Definition at line 53 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::fluid_heat_conductivity

Heat conductivity of fluid.

Definition at line 55 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::fluid_heat_exchange_rate

Heat exchange rate in fluid.

Definition at line 71 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::fluid_ref_temperature

Reference temperature in fluid.

Definition at line 75 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::fluid_thermal_source

Thermal source in fluid.

Definition at line 67 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::init_temperature

Initial temperature.

Definition at line 47 of file heat_model.hh.

MultiField<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::output_field

Definition at line 83 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::porosity

Porosity of solid.

Definition at line 49 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::solid_density

Density of solid.

Definition at line 57 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::solid_heat_capacity

Heat capacity of solid.

Definition at line 59 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::solid_heat_conductivity

Heat conductivity of solid.

Definition at line 61 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::solid_heat_exchange_rate

Heat exchange rate in solid.

Definition at line 73 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::solid_ref_temperature

Reference temperature in solid.

Definition at line 77 of file heat_model.hh.

Field<3, FieldValue<3>::Scalar> HeatTransferModel::ModelEqData::solid_thermal_source

Thermal source in solid.

Definition at line 69 of file heat_model.hh.

The documentation for this class was generated from the following files:

/home/cygwin64/F123-windows-release/flow123d/src/transport/heat_model.hh
/home/cygwin64/F123-windows-release/flow123d/src/transport/heat_model.cc
