#include <concentration_model.hh>

Inheritance diagram for ConcentrationTransportModel:

Collaboration diagram for ConcentrationTransportModel:

Classes
class	ModelEqData

Public Member Functions
	ConcentrationTransportModel ()

UnitSI	balance_units ()

void	set_components (SubstanceList &substances, const Input::Record &in_rec) override
	Read or set names of solution components. More...

void	compute_mass_matrix_coefficient (const std::vector< arma::vec3 > &point_list, const ElementAccessor< 3 > &ele_acc, std::vector< double > &mm_coef) override

void	compute_advection_diffusion_coefficients (const std::vector< arma::vec3 > &point_list, const std::vector< arma::vec3 > &velocity, const ElementAccessor< 3 > &ele_acc, std::vector< std::vector< arma::vec3 > > &ad_coef, std::vector< std::vector< arma::mat33 > > &dif_coef) override

void	compute_init_cond (const std::vector< arma::vec3 > &point_list, const ElementAccessor< 3 > &ele_acc, std::vector< arma::vec > &init_values) override

void	compute_dirichlet_bc (const std::vector< arma::vec3 > &point_list, const ElementAccessor< 3 > &ele_acc, std::vector< arma::vec > &bc_values) override

void	compute_source_coefficients (const std::vector< arma::vec3 > &point_list, const ElementAccessor< 3 > &ele_acc, std::vector< arma::vec > &sources_conc, std::vector< arma::vec > &sources_density, std::vector< arma::vec > &sources_sigma) override

void	compute_sources_sigma (const std::vector< arma::vec3 > &point_list, const ElementAccessor< 3 > &ele_acc, std::vector< arma::vec > &sources_sigma) override

	~ConcentrationTransportModel () override

Public Member Functions inherited from AdvectionDiffusionModel
virtual	~AdvectionDiffusionModel ()
	Destructor. More...

Static Public Member Functions
static string	balance_prefix ()

Protected Member Functions
virtual ModelEqData &	data ()=0
	Derived class should implement getter for ModelEqData instance. More...

void	calculate_dispersivity_tensor (const arma::vec3 &velocity, double Dm, double alphaL, double alphaT, double porosity, double cross_cut, arma::mat33 &K)

Static Protected Member Functions
static IT::Record &	get_input_type (const string &implementation, const string &description)

Protected Attributes
bool	flux_changed
	Indicator of change in advection vector field. More...

Detailed Description

Definition at line 39 of file concentration_model.hh.

Constructor & Destructor Documentation

ConcentrationTransportModel::ConcentrationTransportModel ( )

Definition at line 120 of file concentration_model.cc.

ConcentrationTransportModel::~ConcentrationTransportModel ( )

override

Definition at line 244 of file concentration_model.cc.

Member Function Documentation

static string ConcentrationTransportModel::balance_prefix ( )

inlinestatic

Definition at line 110 of file concentration_model.hh.

UnitSI ConcentrationTransportModel::balance_units ( )

Definition at line 90 of file concentration_model.cc.

void ConcentrationTransportModel::calculate_dispersivity_tensor	(	const arma::vec3 &	velocity,
		double	Dm,
		double	alphaL,
		double	alphaT,
		double	porosity,
		double	cross_cut,
		arma::mat33 &	K
	)

protected

Formula to calculate the dispersivity tensor.

Parameters

velocity	Fluid velocity.
Dm	Molecular diffusivity.
alphaL	Longitudal dispersivity.
alphaT	Transversal dispersivity.
porosity	Porosity.
cross_cut	Cross-section.
K	Dispersivity tensor (output).

Definition at line 145 of file concentration_model.cc.

Here is the caller graph for this function:

void ConcentrationTransportModel::compute_advection_diffusion_coefficients	(	const std::vector< arma::vec3 > &	point_list,
		const std::vector< arma::vec3 > &	velocity,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< std::vector< arma::vec3 > > &	ad_coef,
		std::vector< std::vector< arma::mat33 > > &	dif_coef
	)

overridevirtual

Compute coefficients of stiffness matrix.

Parameters

point_list	Points at which to evaluate.
velocity	Velocity field (input). Temporary solution before we can pass data from other equations.
ele_acc	Element accessor.
ad_coef	Coefficients of advection (output).
dif_coef	Coefficients of diffusion (output).

Implements AdvectionDiffusionModel.

Definition at line 165 of file concentration_model.cc.

void ConcentrationTransportModel::compute_dirichlet_bc	(	const std::vector< arma::vec3 > &	point_list,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< arma::vec > &	bc_values
	)

overridevirtual

Computes the Dirichlet boundary condition values.

Parameters

point_list	Points at which to evaluate.
ele_acc	Element accessor.
bc_values	Vector of b.c. values (output).

Implements AdvectionDiffusionModel.

Definition at line 201 of file concentration_model.cc.

void ConcentrationTransportModel::compute_init_cond	(	const std::vector< arma::vec3 > &	point_list,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< arma::vec > &	init_values
	)

overridevirtual

Compute initial conditions.

Parameters

point_list	Points at which to evaluate.
ele_acc	Element accessor.
init_values	Vector of intial values (output).

Implements AdvectionDiffusionModel.

Definition at line 193 of file concentration_model.cc.

void ConcentrationTransportModel::compute_mass_matrix_coefficient	(	const std::vector< arma::vec3 > &	point_list,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< double > &	mm_coef
	)

overridevirtual

Compute coefficients of mass matrix.

Parameters

point_list	Points at which to evaluate.
ele_acc	Element accessor.
mm_coef	Coefficient vector (output).

Implements AdvectionDiffusionModel.

Definition at line 131 of file concentration_model.cc.

void ConcentrationTransportModel::compute_source_coefficients	(	const std::vector< arma::vec3 > &	point_list,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< arma::vec > &	sources_conc,
		std::vector< arma::vec > &	sources_density,
		std::vector< arma::vec > &	sources_sigma
	)

overridevirtual

Compute coefficients of volume sources.

Parameters

point_list	Points at which to evaluate.
ele_acc	Element accessor.
sources_conc	Source concentrations (output).
sources_density	Source densities (output).
sources_sigma	Source sigmas (output).

Implements AdvectionDiffusionModel.

Definition at line 209 of file concentration_model.cc.

void ConcentrationTransportModel::compute_sources_sigma	(	const std::vector< arma::vec3 > &	point_list,
		const ElementAccessor< 3 > &	ele_acc,
		std::vector< arma::vec > &	sources_sigma
	)

overridevirtual

Compute coefficients of volume sources.

Parameters

point_list	Points at which to evaluate.
ele_acc	Element accessor.
sources_sigma	Source sigmas (output).

Implements AdvectionDiffusionModel.

Definition at line 230 of file concentration_model.cc.

virtual ModelEqData& ConcentrationTransportModel::data ( )

protectedpure virtual

Derived class should implement getter for ModelEqData instance.

Here is the caller graph for this function:

IT::Record & ConcentrationTransportModel::get_input_type	(	const string &	implementation,
		const string &	description
	)

staticprotected

Create input type that can be passed to the derived class.

Parameters

implementation	String characterizing the numerical method, e.g. DG, FEM, FVM.
description	Comment used to describe the record key.

Returns

Definition at line 98 of file concentration_model.cc.

void ConcentrationTransportModel::set_components	(	SubstanceList &	substances,
		const Input::Record &	in_rec
	)

overridevirtual

Read or set names of solution components.

Implements AdvectionDiffusionModel.

Definition at line 125 of file concentration_model.cc.

Member Data Documentation

bool ConcentrationTransportModel::flux_changed

protected

Indicator of change in advection vector field.

Definition at line 103 of file concentration_model.hh.

The documentation for this class was generated from the following files:

/home/cygwin64/F123-windows-release/flow123d/src/transport/concentration_model.hh
/home/cygwin64/F123-windows-release/flow123d/src/transport/concentration_model.cc
