Base of classes for declaring structure of the input data. More...

#include <type_base.hh>

Inheritance diagram for Input::Type::TypeBase:

[legend]

Collaboration diagram for Input::Type::TypeBase:

Public Types
typedef std::size_t	TypeHash
	Type returned by content_hash methods. More...

typedef std::string	json_string
	String stored in JSON format. More...

typedef std::map< std::string, json_string >	attribute_map
	Defines map of Input::Type attributes. More...

typedef std::pair< std::string, std::shared_ptr< TypeBase > >	ParameterPair
	Defines pairs of (name, Input::Type), that are used for replace of parameters in generic types. More...

typedef std::vector< ParameterPair >	ParameterVector
	Define vector of parameters passed to the overloaded make_instance method. More...

typedef std::map< std::string, TypeHash >	ParameterMap
	Defines map of used parameters. More...

typedef std::pair< std::shared_ptr< TypeBase >, ParameterMap >	MakeInstanceReturnType
	Return type of make_instance methods, contains instance of generic type and map of used parameters. More...

Public Member Functions
virtual FinishStatus	finish_status () const
	Returns true if the type is fully specified and ready for read access. More...

virtual bool	is_finished () const

virtual bool	is_closed () const
	Returns true if the type is closed. More...

virtual string	type_name () const
	Returns an identification of the type. Useful for error messages. More...

virtual string	class_name () const
	Returns an identification of the class. Useful for output of the documentation. More...

string	desc () const
	Returns string with Type extensive documentation. More...

virtual bool	operator== (const TypeBase &other) const
	Comparison of types. More...

bool	operator!= (const TypeBase &other) const
	Comparison of types. More...

virtual	~TypeBase ()
	Destructor. More...

virtual FinishStatus	finish (FinishStatus finish_type=FinishStatus::regular_)
	Finish method. Finalize construction of "Lazy types": Record, Selection, Abstract and generic type. More...

virtual TypeHash	content_hash () const =0
	Hash of the type specification. More...

std::string	hash_str () const
	Format the hash of this type. More...

virtual MakeInstanceReturnType	make_instance (ParameterVector vec=ParameterVector())=0

bool	is_root_of_generic_subtree () const
	Indicates if type is marked with flag `root_of_generic_subtree_`. More...

Static Public Member Functions
static void	delete_unfinished_types ()
	Finishes and marks all types registered in type repositories and unused in IST. More...

static std::string	hash_str (TypeHash hash)
	Format given hash for output. More...

Static Public Attributes
static const TypeHash	none_hash = std::numeric_limits<TypeHash>::max()

Protected Types
typedef string	KeyHash
	The type of hash values used in associative array that translates key names to indices in Record and Selection. More...

Protected Member Functions
	TypeBase ()
	The default constructor. More...

	TypeBase (const TypeBase &other)
	Copy constructor. More...

void	add_attribute_ (std::string name, json_string val)
	Add attribute of given `name` to attribute map. More...

bool	validate_json (json_string str) const
	Check if `str` is valid JSON string. More...

json_string	print_parameter_map_to_json (ParameterMap parameter_map) const
	Create JSON output from `parameter_map` formatted as value of attribute. More...

json_string	print_parameter_map_keys_to_json (ParameterMap param_map) const

void	set_generic_attributes (ParameterMap param_map)

void	copy_attributes (attribute_map other_attributes)

Static Protected Member Functions
static KeyHash	key_hash (const string &str)
	Hash function. More...

static bool	is_valid_identifier (const string &key)
	Check that a `key` is valid identifier. More...

Protected Attributes
std::shared_ptr< attribute_map >	attributes_
	map of type attributes (e. g. input_type, name etc.) More...

bool	root_of_generic_subtree_
	flag is true if type should be root of generic subtree More...

TypeHash	generic_type_hash_
	hash string of generic type if type is derived, or empty string More...

ParameterMap	parameter_map_
	map of parameters if type is part of generic subtree More...

Friends
class	Array

class	Record

class	OutputBase

Detailed Description

Base of classes for declaring structure of the input data.

Provides methods and class members common to all types. Namely, the type name, finished status (nontrivial only for types with complex initialization - Record, AbstractRecosd, Selection), attributes, data of generic types and output of the documentation.

Definition at line 92 of file type_base.hh.

Member Typedef Documentation

typedef std::map<std::string, json_string> Input::Type::TypeBase::attribute_map

Defines map of Input::Type attributes.

Definition at line 101 of file type_base.hh.

typedef std::string Input::Type::TypeBase::json_string

String stored in JSON format.

Definition at line 99 of file type_base.hh.

typedef string Input::Type::TypeBase::KeyHash

protected

The type of hash values used in associative array that translates key names to indices in Record and Selection.

For simplicity, we currently use whole strings as "hash".

Definition at line 258 of file type_base.hh.

typedef std::pair< std::shared_ptr<TypeBase>, ParameterMap > Input::Type::TypeBase::MakeInstanceReturnType

Return type of make_instance methods, contains instance of generic type and map of used parameters.

Definition at line 111 of file type_base.hh.

typedef std::map< std::string, TypeHash > Input::Type::TypeBase::ParameterMap

Defines map of used parameters.

Definition at line 109 of file type_base.hh.

typedef std::pair< std::string, std::shared_ptr<TypeBase> > Input::Type::TypeBase::ParameterPair

Defines pairs of (name, Input::Type), that are used for replace of parameters in generic types.

Definition at line 104 of file type_base.hh.

typedef std::vector<ParameterPair> Input::Type::TypeBase::ParameterVector

Define vector of parameters passed to the overloaded make_instance method.

Definition at line 106 of file type_base.hh.

typedef std::size_t Input::Type::TypeBase::TypeHash

Type returned by content_hash methods.

Definition at line 95 of file type_base.hh.

Constructor & Destructor Documentation

Input::Type::TypeBase::~TypeBase ( )

virtual

Destructor.

Definition at line 90 of file type_base.cc.

Input::Type::TypeBase::TypeBase ( )

protected

The default constructor.

Definition at line 78 of file type_base.cc.

Input::Type::TypeBase::TypeBase ( const TypeBase & other )

protected

Copy constructor.

Definition at line 84 of file type_base.cc.

Member Function Documentation

void Input::Type::TypeBase::add_attribute_	(	std::string	name,
		json_string	val
	)

protected

Add attribute of given name to attribute map.

Parameter val must contain valid JSON string.

Definition at line 134 of file type_base.cc.

Here is the caller graph for this function:

string Input::Type::TypeBase::class_name ( ) const

virtual

Returns an identification of the class. Useful for output of the documentation.

Reimplemented in Input::Type::FileName, Input::Type::String, Input::Type::Double, Input::Type::Integer, Input::Type::Bool, Input::Type::Array, Input::Type::Record, Input::Type::AdHocAbstract, Input::Type::Abstract, Input::Type::Selection, Input::Type::Tuple, and Input::Type::Parameter.

Definition at line 211 of file type_base.cc.

Here is the caller graph for this function:

virtual TypeHash Input::Type::TypeBase::content_hash ( ) const

pure virtual

Hash of the type specification.

Provides unique id computed from its content (definition) so that same types have same hash.

Hash is counted using type, name and other class members specific for descendants.

Implemented in Input::Type::FileName, Input::Type::String, Input::Type::Double, Input::Type::Integer, Input::Type::Bool, Input::Type::Array, Input::Type::AdHocAbstract, Input::Type::Record, Input::Type::Abstract, Input::Type::Selection, Input::Type::Instance, Input::Type::Tuple, and Input::Type::Parameter.

Here is the caller graph for this function:

void Input::Type::TypeBase::copy_attributes ( attribute_map other_attributes )

protected

Copy attributes to the instance of the generic type. Remove all internal attributes starting with '_'.

Definition at line 182 of file type_base.cc.

Here is the caller graph for this function:

void Input::Type::TypeBase::delete_unfinished_types ( )

static

Finishes and marks all types registered in type repositories and unused in IST.

Steps of this method: 1) finishes all types unused in IST, marks them as deleted (FinishStatus::deleted_) 2) iterates these deleted types once more, checks shared pointers link to Record keys, descendants of Abstract etc.

if count == 1, it's OK, method resets shared pointer
in other cases throws error

Definition at line 107 of file type_base.cc.

Here is the caller graph for this function:

string Input::Type::TypeBase::desc ( ) const

Returns string with Type extensive documentation.

We need this to pass Type description at throw points since the Type object can be deallocated during stack unrolling so it is not good idea to pass pointer. Maybe we can pass smart pointers. Actually this method is used in various exceptions in json_to_storage.

TODO: Some old note on this topic: !!! how to pass instance of descendant of TypeBase through EI -

can not pass it directly since TypeBase is not copyconstructable
can not use shared_ptr for same reason
can not use C pointers since the referred object can be temporary solutions:
- consistently move TypeBase to Pimpl design
- provide virtual function make_copy, that returns valid shared_ptr

Definition at line 99 of file type_base.cc.

Here is the caller graph for this function:

FinishStatus Input::Type::TypeBase::finish ( FinishStatus finish_type = FinishStatus::regular_ )

virtual

Finish method. Finalize construction of "Lazy types": Record, Selection, Abstract and generic type.

These input types are typically defined by means of static generating methods, whose allows initialization any of other input types. Since e.g. a Record can link to other input types through its keys at the initialization phase. But some setting (e.g. add descendants to Abstract) can't be done in initialization phase. Therefore, the remaining part of initialization can be done later, in finalization phase, typically from main(), by calling the method finish().

Method allows finish in different cases that is managed by finish_type:

base finish of IST requires FinishStatus::regular_ and typically finish of root type is called in this case
finish of generic types can be different of other Input::Types (e. g. for Record) and needs set finish_type to FinishStatus::generic_
input types unused in IST can be finished with parameter FinishStatus::delete_. These types can be then safely deleted from Input::TypeRepository (see also delete_unfinished_types)

Reimplemented in Input::Type::Record, Input::Type::Array, Input::Type::AdHocAbstract, Input::Type::Selection, Input::Type::Abstract, Input::Type::Instance, Input::Type::Tuple, and Input::Type::Parameter.

Definition at line 216 of file type_base.cc.

Here is the caller graph for this function:

FinishStatus Input::Type::TypeBase::finish_status ( ) const

virtual

Returns true if the type is fully specified and ready for read access.

For Record and Array types this say nothing about child types referenced in particular type object. In particular for Record and Selection, it returns true after finish() method is called.

Reimplemented in Input::Type::Array, Input::Type::Record, Input::Type::Abstract, and Input::Type::Selection.

Definition at line 191 of file type_base.cc.

std::string Input::Type::TypeBase::hash_str ( TypeHash hash )

static

Format given hash for output.

Use hex format and double quotas.

Definition at line 125 of file type_base.cc.

Here is the caller graph for this function:

std::string Input::Type::TypeBase::hash_str ( ) const

inline

Format the hash of this type.

Definition at line 220 of file type_base.hh.

Here is the caller graph for this function:

bool Input::Type::TypeBase::is_closed ( ) const

virtual

Returns true if the type is closed.

Reimplemented in Input::Type::Record, Input::Type::Abstract, and Input::Type::Selection.

Definition at line 201 of file type_base.cc.

bool Input::Type::TypeBase::is_finished ( ) const

virtual

Reimplemented in Input::Type::Array, Input::Type::Record, Input::Type::Abstract, and Input::Type::Selection.

Definition at line 196 of file type_base.cc.

bool Input::Type::TypeBase::is_root_of_generic_subtree ( ) const

inline

Indicates if type is marked with flag root_of_generic_subtree_.

Definition at line 232 of file type_base.hh.

Here is the caller graph for this function:

bool Input::Type::TypeBase::is_valid_identifier ( const string & key )

staticprotected

Check that a key is valid identifier.

I.e. consists only of valid characters, that are lower-case letters, digits and underscore, we allow identifiers starting with a digit, but it is discouraged since it slows down parsing of the input file.

Definition at line 93 of file type_base.cc.

Here is the caller graph for this function:

static KeyHash Input::Type::TypeBase::key_hash ( const string & str )

inlinestaticprotected

Hash function.

Definition at line 261 of file type_base.hh.

Here is the caller graph for this function:

virtual MakeInstanceReturnType Input::Type::TypeBase::make_instance ( ParameterVector vec = ParameterVector() )

pure virtual

Create instance of generic type.

Replace parameters in input tree by type stored in vec.

Here is the caller graph for this function:

bool Input::Type::TypeBase::operator!= ( const TypeBase & other ) const

Comparison of types.

Definition at line 226 of file type_base.cc.

bool Input::Type::TypeBase::operator== ( const TypeBase & other ) const

virtual

Comparison of types.

It compares kind of type (Integer, Double, String, Record, ..), for complex types it also compares names. For arrays compare subtypes.

Reimplemented in Input::Type::FileName, Input::Type::Array, Input::Type::Record, Input::Type::Selection, and Input::Type::Tuple.

Definition at line 222 of file type_base.cc.

TypeBase::json_string Input::Type::TypeBase::print_parameter_map_keys_to_json ( ParameterMap param_map ) const

protected

JSON format of the vector of parameter names. Used for generic composed types. TODO: use ParameterVector instead of ParameterMap and merge this method with the previous one.

Definition at line 162 of file type_base.cc.

Here is the caller graph for this function:

TypeBase::json_string Input::Type::TypeBase::print_parameter_map_to_json ( ParameterMap parameter_map ) const

protected

Create JSON output from parameter_map formatted as value of attribute.

Definition at line 151 of file type_base.cc.

Here is the caller graph for this function:

void Input::Type::TypeBase::set_generic_attributes ( ParameterMap param_map )

protected

Extract and set attributes from the ParameterMap containing parameters of the subtree. Used in implementations of the make_instance method.

Definition at line 173 of file type_base.cc.

Here is the caller graph for this function:

string Input::Type::TypeBase::type_name ( ) const

virtual

Returns an identification of the type. Useful for error messages.

Reimplemented in Input::Type::FileName, Input::Type::String, Input::Type::Double, Input::Type::Integer, Input::Type::Bool, Input::Type::Array, Input::Type::Record, Input::Type::Abstract, Input::Type::Selection, and Input::Type::Parameter.

Definition at line 206 of file type_base.cc.

Here is the caller graph for this function:

bool Input::Type::TypeBase::validate_json ( json_string str ) const

protected

Check if str is valid JSON string.

Definition at line 140 of file type_base.cc.

Here is the caller graph for this function:

Friends And Related Function Documentation

friend class Array

friend

Definition at line 309 of file type_base.hh.

friend class OutputBase

friend

Definition at line 311 of file type_base.hh.

friend class Record

friend

Definition at line 310 of file type_base.hh.

Member Data Documentation

std::shared_ptr<attribute_map> Input::Type::TypeBase::attributes_

protected

map of type attributes (e. g. input_type, name etc.)

Definition at line 298 of file type_base.hh.

TypeHash Input::Type::TypeBase::generic_type_hash_

protected

hash string of generic type if type is derived, or empty string

Definition at line 304 of file type_base.hh.

const TypeHash Input::Type::TypeBase::none_hash = std::numeric_limits<TypeHash>::max()

static

Definition at line 96 of file type_base.hh.

ParameterMap Input::Type::TypeBase::parameter_map_

protected

map of parameters if type is part of generic subtree

Definition at line 307 of file type_base.hh.

bool Input::Type::TypeBase::root_of_generic_subtree_

protected

flag is true if type should be root of generic subtree

Definition at line 301 of file type_base.hh.

The documentation for this class was generated from the following files:

/opt/flow123d/flow123d/src/input/type_base.hh
/opt/flow123d/flow123d/src/input/type_base.cc

Public Types

Public Member Functions

Static Public Member Functions

Static Public Attributes

Protected Types

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Friends

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Friends And Related Function Documentation

Member Data Documentation
