#include <transport_operator_splitting.hh>
Inheritance diagram for TransportEqFields:
Collaboration diagram for TransportEqFields:
Public Member Functions | |
| TransportEqFields () | |
| virtual | ~TransportEqFields () |
 Public Member Functions inherited from FieldSet | |
| TYPEDEF_ERR_INFO (EI_FieldType, std::string) | |
| DECLARE_INPUT_EXCEPTION (ExcUnknownField,<< "Unknown field "<< FieldCommon::EI_Field::qval<< " in the "<< EI_FieldType::val<< ": \n") | |
| DECLARE_INPUT_EXCEPTION (ExcFieldExists,<< "Field "<< FieldCommon::EI_Field::qval<< " exists in equation. You cannot set user field of same name.\n") | |
| FieldSet () | |
| Default constructor. More... | |
| Input::Type::Record | make_field_descriptor_type (const std::string &equation_name) const |
| void | set_field (const std::string &dest_field_name, FieldCommon &source) |
| FieldCommon * | field (const std::string &field_name) const |
| FieldCommon & | operator[] (const std::string &field_name) const |
| void | set_components (const std::vector< string > &names) |
| void | set_mesh (const Mesh &mesh) |
| void | set_input_list (Input::Array input_list, const TimeGovernor &tg) |
| void | flags_add (FieldFlag::Flags::Mask mask) |
| bool | set_time (const TimeStep &time, LimitSide limit_side) |
| void | output_type (OutputTime::DiscreteSpace rt) |
| void | mark_input_times (const TimeGovernor &tg) |
| bool | changed () const |
| bool | is_constant (Region reg) const |
| bool | is_jump_time () const |
| void | cache_reallocate (const ElementCacheMap &cache_map, FieldSet &used_fieldset) |
| void | cache_update (ElementCacheMap &cache_map) |
| void | set_dependency (FieldSet &used_fieldset) |
| void | add_coords_field () |
| void | set_surface_depth (std::shared_ptr< SurfaceDepth > surface_depth) |
| Set surface depth object to "d" field. More... | |
| Range< FieldListAccessor > | fields_range () const |
| Returns range of Fields held in field_list. More... | |
| const Mesh * | mesh () const |
| Returns pointer to mesh. More... | |
| std::string | print_dependency () const |
| Return order of evaluated fields by dependency and region_idx. More... | |
| void | set_default_fieldset () |
Public Attributes | |
| Field< 3, FieldValue< 3 >::Scalar > | porosity |
| Mobile porosity - usually saturated water content in the case of unsaturated flow model. More... | |
| Field< 3, FieldValue< 3 >::Scalar > | water_content |
| Water content - result of unsaturated water flow model or porosity. More... | |
| Field< 3, FieldValue< 3 >::Scalar > | cross_section |
| Pointer to DarcyFlow field cross_section. More... | |
| Field< 3, FieldValue< 3 >::VectorFixed > | flow_flux |
| Flow flux, can be result of water flow model. More... | |
| MultiField< 3, FieldValue< 3 >::Scalar > | sources_density |
| Concentration sources - density of substance source, only positive part is used. More... | |
| MultiField< 3, FieldValue< 3 >::Scalar > | sources_sigma |
| Concentration sources - Robin type, in_flux = sources_sigma * (sources_conc - mobile_conc) More... | |
| MultiField< 3, FieldValue< 3 >::Scalar > | sources_conc |
Additional Inherited Members | |
| Public Types inherited from FieldSet | |
| enum | UserFieldShape { scalar , vector , tensor } |
| Public Types inherited from FieldFlag | |
| typedef FlagArray< FieldFlag > | Flags |
| typedef Flags::Mask | Mask |
| Static Public Member Functions inherited from FieldSet | |
| static const Input::Type::Selection & | get_user_field_shape_selection () |
| Input selection of user field shape. More... | |
| static const Input::Type::Record & | make_user_field_type (const std::string &equation_name) |
| Declare input record type of field defined by user. More... | |
| Static Public Attributes inherited from FieldFlag | |
| static constexpr unsigned int | flags_size_ = 3 |
| Number of bits used by Field itself. More... | |
| static constexpr Mask | equation_input {1 << 0} |
| The field is data parameter of the owning equation. (default on) More... | |
| static constexpr Mask | declare_input {1 << 1} |
| The field can be set from input. The key in input field descriptor is declared. (default on) More... | |
| static constexpr Mask | allow_output {1 << 2} |
| The field can output. Is part of generated output selection. (default on) More... | |
| static constexpr Mask | input_copy = ~declare_input & equation_input |
| static constexpr Mask | in_time_term {1 << 8} |
| A field is part of time term of the equation. More... | |
| static constexpr Mask | in_main_matrix {1 << 9} |
| A field is part of main "stiffness matrix" of the equation. More... | |
| static constexpr Mask | in_rhs {1 << 10} |
| A field is part of the right hand side of the equation. More... | |
| static constexpr Mask | equation_result = allow_output & ~declare_input & ~equation_input |
| Match result fields. These are never given by input or copy of input. More... | |
| static constexpr Mask | equation_external_output = allow_output & input_copy |
| Match an output field, that can be also copy of other field. More... | |
| Protected Member Functions inherited from FieldSet | |
| void | topological_sort (const FieldCommon *f, unsigned int i_reg, std::unordered_set< const FieldCommon * > &used_fields) |
| Helper method sort used fields by dependency. More... | |
| Protected Attributes inherited from FieldSet | |
| std::vector< FieldCommon * > | field_list |
| List of all fields. More... | |
| const Mesh * | mesh_ |
| Pointer to the mesh. More... | |
| std::map< unsigned int, std::vector< const FieldCommon * > > | region_field_update_order_ |
| FieldCoords | X_ |
| Field holds coordinates for computing of FieldFormulas. More... | |
| FieldDepth | depth_ |
| Field holds surface depth for computing of FieldFormulas. More... | |
| FieldMeshStep | mesh_step_ |
| Field holds mesh step of element for computing of FieldFormulas. More... | |
Detailed Description
Class with fields that are common to all transport models.
Definition at line 137 of file transport_operator_splitting.hh.
Constructor & Destructor Documentation
◆ TransportEqFields()
| TransportEqFields::TransportEqFields | ( | ) |
Definition at line 106 of file transport_operator_splitting.cc.
◆ ~TransportEqFields()
|
inlinevirtual |
Definition at line 141 of file transport_operator_splitting.hh.
Member Data Documentation
◆ cross_section
| Field<3, FieldValue<3>::Scalar > TransportEqFields::cross_section |
Pointer to DarcyFlow field cross_section.
Definition at line 150 of file transport_operator_splitting.hh.
◆ flow_flux
| Field<3, FieldValue<3>::VectorFixed > TransportEqFields::flow_flux |
Flow flux, can be result of water flow model.
Definition at line 153 of file transport_operator_splitting.hh.
◆ porosity
| Field<3, FieldValue<3>::Scalar> TransportEqFields::porosity |
Mobile porosity - usually saturated water content in the case of unsaturated flow model.
Definition at line 144 of file transport_operator_splitting.hh.
◆ sources_conc
| MultiField<3, FieldValue<3>::Scalar> TransportEqFields::sources_conc |
Definition at line 159 of file transport_operator_splitting.hh.
◆ sources_density
| MultiField<3, FieldValue<3>::Scalar> TransportEqFields::sources_density |
Concentration sources - density of substance source, only positive part is used.
Definition at line 156 of file transport_operator_splitting.hh.
◆ sources_sigma
| MultiField<3, FieldValue<3>::Scalar> TransportEqFields::sources_sigma |
Concentration sources - Robin type, in_flux = sources_sigma * (sources_conc - mobile_conc)
Definition at line 158 of file transport_operator_splitting.hh.
◆ water_content
| Field<3, FieldValue<3>::Scalar> TransportEqFields::water_content |
Water content - result of unsaturated water flow model or porosity.
Definition at line 147 of file transport_operator_splitting.hh.
The documentation for this class was generated from the following files:
- /home/runner/work/flow123d/flow123d/src/transport/transport_operator_splitting.hh
- /home/runner/work/flow123d/flow123d/src/transport/transport_operator_splitting.cc
