#include <patch_point_values.hh>

Collaboration diagram for PatchPointValues< spacedim >:

[legend]

Classes
struct	PatchFeData

Public Member Functions
	PatchPointValues (uint dim, uint quad_order, bool is_bulk, PatchFeData &patch_fe_data)

virtual	~PatchPointValues ()

void	initialize ()

void	reset ()
	Reset number of columns (points and elements) More...

uint	n_elems () const
	Getter for n_elems_. More...

uint	n_points () const
	Getter for n_points_. More...

Quadrature *	get_quadrature () const
	Getter for quadrature. More...

void	resize_tables (uint n_elems, uint n_points)
	Resize data tables. Method is called before reinit of patch. More...

uint	register_bulk_point (uint elem_table_row, uint value_patch_idx, uint elem_idx, uint i_point_on_elem)

uint	register_side_point (uint elem_table_row, uint value_patch_idx, uint elem_idx, uint side_idx, uint i_point_on_side)

AssemblyArena &	asm_arena () const
	return reference to assembly arena More...

PatchArena &	patch_arena () const
	return reference to patch arena More...

template<class ElementDomain >
NodeAccessor< spacedim >	node (unsigned int i_elm, unsigned int i_n)

Public Attributes
IntTableArena	int_table_

std::vector< OpSizeType >	int_sizes_
	Set size and type of rows of int_table_, value is set implicitly in constructor of descendants. More...

uint	n_points_
	Number of points in patch. More...

uint	n_elems_
	Number of elements in patch. More...

uint	i_elem_
	Index of registered element in table, helper value used during patch creating. More...

Quadrature *	quad_
	Quadrature of given dimension and order passed in constructor. More...

std::vector< uint >	elements_map_
	Map of element patch indices to PatchOp::result_ and int_table_ tables. More...

std::vector< uint >	points_map_
	Map of point patch indices to PatchOp::result_ and int_table_ tables. More...

PatchFeData &	patch_fe_data_
	Reference to PatchFeData structure shared with PatchFeValues. More...

std::vector< ElementAccessor< spacedim > >	elem_list_
	List of elements on patch. More...

std::vector< Side >	side_list_
	List of sides on patch. More...

Detailed Description

template<unsigned int spacedim = 3>
class PatchPointValues< spacedim >

v Class for storing FE data of quadrature points on one patch.

Store data of bulk or side quadrature points of one dimension.

Definition at line 55 of file patch_point_values.hh.

Constructor & Destructor Documentation

◆ PatchPointValues()

template<unsigned int spacedim = 3>

PatchPointValues< spacedim >::PatchPointValues	(	uint	dim,
		uint	quad_order,
		bool	is_bulk,
		PatchFeData &	patch_fe_data
	)

inline

Constructor

Parameters

dim	Set dimension

Definition at line 83 of file patch_point_values.hh.

◆ ~PatchPointValues()

template<unsigned int spacedim = 3>

virtual PatchPointValues< spacedim >::~PatchPointValues ( )

inlinevirtual

Destructor.

Definition at line 99 of file patch_point_values.hh.

Member Function Documentation

◆ asm_arena()

template<unsigned int spacedim = 3>

AssemblyArena& PatchPointValues< spacedim >::asm_arena ( ) const

inline

return reference to assembly arena

Definition at line 183 of file patch_point_values.hh.

◆ get_quadrature()

template<unsigned int spacedim = 3>

Quadrature* PatchPointValues< spacedim >::get_quadrature ( ) const

inline

Getter for quadrature.

Definition at line 129 of file patch_point_values.hh.

◆ initialize()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::initialize ( )

inline

Initialize object, set number of columns (quantities) in tables.

Definition at line 104 of file patch_point_values.hh.

◆ n_elems()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::n_elems ( ) const

inline

Getter for n_elems_.

Definition at line 119 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ n_points()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::n_points ( ) const

inline

Getter for n_points_.

Definition at line 124 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ node()

template<unsigned int spacedim = 3>

template<class ElementDomain >

NodeAccessor<spacedim> PatchPointValues< spacedim >::node	(	unsigned int	i_elm,
		unsigned int	i_n
	)

◆ patch_arena()

template<unsigned int spacedim = 3>

PatchArena& PatchPointValues< spacedim >::patch_arena ( ) const

inline

return reference to patch arena

Definition at line 188 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ register_bulk_point()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::register_bulk_point	(	uint	elem_table_row,
		uint	value_patch_idx,
		uint	elem_idx,
		uint	i_point_on_elem
	)

inline

Register bulk point, add to int_table_

Parameters

elem_table_row	Index of element in temporary element table.
value_patch_idx	Index of point in ElementCacheMap.
elem_idx	Index of element in Mesh.
i_point_on_elem	Index of point on element

Definition at line 152 of file patch_point_values.hh.

◆ register_side_point()

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::register_side_point	(	uint	elem_table_row,
		uint	value_patch_idx,
		uint	elem_idx,
		uint	side_idx,
		uint	i_point_on_side
	)

inline

Register side point, add to int_table_

Parameters

elem_table_row	Index of side in temporary element table.
value_patch_idx	Index of point in ElementCacheMap.
elem_idx	Index of element in Mesh.
side_idx	Index of side on element.
i_point_on_side	Index of point on side

Definition at line 171 of file patch_point_values.hh.

◆ reset()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::reset ( )

inline

Reset number of columns (points and elements)

Definition at line 110 of file patch_point_values.hh.

Here is the caller graph for this function:

◆ resize_tables()

template<unsigned int spacedim = 3>

void PatchPointValues< spacedim >::resize_tables	(	uint	n_elems,
		uint	n_points
	)

inline

Resize data tables. Method is called before reinit of patch.

Definition at line 134 of file patch_point_values.hh.

Member Data Documentation

◆ elem_list_

template<unsigned int spacedim = 3>

std::vector<ElementAccessor<spacedim> > PatchPointValues< spacedim >::elem_list_

List of elements on patch.

Definition at line 225 of file patch_point_values.hh.

◆ elements_map_

template<unsigned int spacedim = 3>

std::vector<uint> PatchPointValues< spacedim >::elements_map_

Map of element patch indices to PatchOp::result_ and int_table_ tables.

Definition at line 220 of file patch_point_values.hh.

◆ i_elem_

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::i_elem_

Index of registered element in table, helper value used during patch creating.

Definition at line 217 of file patch_point_values.hh.

◆ int_sizes_

template<unsigned int spacedim = 3>

std::vector<OpSizeType> PatchPointValues< spacedim >::int_sizes_

Set size and type of rows of int_table_, value is set implicitly in constructor of descendants.

Definition at line 212 of file patch_point_values.hh.

◆ int_table_

template<unsigned int spacedim = 3>

IntTableArena PatchPointValues< spacedim >::int_table_

Hold integer values of quadrature points of defined operations.

Table contains following rows: 0: Index of quadrature point on patch 1: Row of element/side in PatchOp::result_ table in registration step (before expansion) 2: Element idx in Mesh

last two rows are allocated only for side point table 3: Index of side in element - short vector, size of column = number of sides 4: Index of side in element - long vector, size of column = number of points Number of used rows is given by n_points_.

Definition at line 209 of file patch_point_values.hh.

◆ n_elems_

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::n_elems_

Number of elements in patch.

Definition at line 216 of file patch_point_values.hh.

◆ n_points_

template<unsigned int spacedim = 3>

uint PatchPointValues< spacedim >::n_points_

Number of points in patch.

Definition at line 215 of file patch_point_values.hh.

◆ patch_fe_data_

template<unsigned int spacedim = 3>

PatchFeData& PatchPointValues< spacedim >::patch_fe_data_

Reference to PatchFeData structure shared with PatchFeValues.

Definition at line 223 of file patch_point_values.hh.

◆ points_map_

template<unsigned int spacedim = 3>

std::vector<uint> PatchPointValues< spacedim >::points_map_

Map of point patch indices to PatchOp::result_ and int_table_ tables.

Definition at line 221 of file patch_point_values.hh.

◆ quad_

template<unsigned int spacedim = 3>

Quadrature* PatchPointValues< spacedim >::quad_

Quadrature of given dimension and order passed in constructor.

Definition at line 218 of file patch_point_values.hh.

◆ side_list_

template<unsigned int spacedim = 3>

std::vector<Side> PatchPointValues< spacedim >::side_list_

List of sides on patch.

Definition at line 226 of file patch_point_values.hh.

The documentation for this class was generated from the following file:

/home/runner/work/flow123d/flow123d/src/fem/patch_point_values.hh
