#include <integral_acc.hh>

Inheritance diagram for EdgeIntegralAcc< qdim >:

Collaboration diagram for EdgeIntegralAcc< qdim >:

[legend]

Public Member Functions
	EdgeIntegralAcc ()
	Default constructor. More...

	EdgeIntegralAcc (std::shared_ptr< EvalPoints > eval_points, Quadrature quad, PatchFEValues< 3 > pfev, ElementCacheMap *element_cache_map)
	Constructor of edge integral. More...

	~EdgeIntegralAcc ()
	Destructor. More...

Range< EdgePoint >	points (const DHCellSide &cell_side) const
	Returns range of side local points for appropriate cell side accessor. More...

FeQ< Scalar >	JxW ()
	Same as BulkValues::JxW but register at side quadrature points. More...

ElQ< Vector >	normal_vector ()
	Register the normal vector to a side at side quadrature points. More...

FeQ< Vector >	coords ()
	Create side accessor of coords entity. More...

ElQ< Scalar >	determinant ()
	Create bulk accessor of jac determinant entity. More...

FeQArray< Scalar >	scalar_shape (uint component_idx=0)
	Same as BulkValues::scalar_shape but register at side quadrature points. More...

FeQArray< Vector >	vector_shape (uint component_idx=0)
	Same as BulkValues::vector_shape but register at side quadrature points. More...

FeQArray< Vector >	grad_scalar_shape (uint component_idx=0)
	Same as BulkValues::grad_scalar_shape but register at side quadrature points. More...

FeQArray< Tensor >	grad_vector_shape (uint component_idx=0)
	Return the value of the `function_no-th` gradient vector shape function at the `p` bulk quadrature point. More...

FeQArray< Tensor >	vector_sym_grad (uint component_idx=0)
	Return the value of the `function_no-th` vector symmetric gradient at the `p` side quadrature point. More...

FeQArray< Scalar >	vector_divergence (uint component_idx=0)
	Return the value of the `function_no-th` vector divergence at the `p` side quadrature point. More...

Public Member Functions inherited from EdgeIntegral
	EdgeIntegral ()
	Default constructor. More...

	EdgeIntegral (std::shared_ptr< EvalPoints > eval_points, Quadrature *quad, unsigned int dim)
	Constructor of edge integral. More...

	~EdgeIntegral ()
	Destructor. More...

unsigned int	n_sides () const
	Getter of n_sides. More...

int	get_subset_idx () const
	Return index of data block according to subset in EvalPoints object. More...

uint	side_begin (const DHCellSide &cell_side) const

Range< EdgePoint >	points (const DHCellSide &cell_side, const ElementCacheMap *elm_cache_map) const
	Returns range of side local points for appropriate cell side accessor - obsolete method. More...

Public Member Functions inherited from internal::BaseIntegral
	BaseIntegral ()
	Default constructor. More...

	BaseIntegral (std::shared_ptr< EvalPoints > eval_points, unsigned int dim)
	Constructor of bulk or side subset. More...

virtual	~BaseIntegral ()
	Destructor. More...

std::shared_ptr< EvalPoints >	eval_points () const
	Getter of eval_points. More...

unsigned int	dim () const
	Returns dimension. More...

Private Attributes
internal::IntegralFactory< qdim >	factory_
	Defines interface of operation accessors declaration. More...

Friends
class	EvalPoints

class	EdgePoint

class	CouplingPoint

class	BoundaryPoint

template<unsigned int quaddim>
class	CouplingIntegralAcc

template<unsigned int quaddim>
class	BoundaryIntegralAcc

Additional Inherited Members
Protected Attributes inherited from EdgeIntegral
std::shared_ptr< internal_integrals::Edge >	internal_edge_
	Internal integral object. More...

Protected Attributes inherited from internal::BaseIntegral
std::shared_ptr< EvalPoints >	eval_points_
	Pointer to EvalPoints. More...

unsigned int	dim_
	Dimension of the cell on which points are placed. More...

Detailed Description

template<unsigned int qdim>
class EdgeIntegralAcc< qdim >

New Integral accessor class, replace of EdgeIntegral, will be merged with EdgeIntegral

IN DEVELOPMENT

Definition at line 514 of file integral_acc.hh.

Constructor & Destructor Documentation

◆ EdgeIntegralAcc() [1/2]

template<unsigned int qdim>

EdgeIntegralAcc< qdim >::EdgeIntegralAcc ( )

inline

Default constructor.

Definition at line 517 of file integral_acc.hh.

◆ EdgeIntegralAcc() [2/2]

template<unsigned int qdim>

EdgeIntegralAcc< qdim >::EdgeIntegralAcc	(	std::shared_ptr< EvalPoints >	eval_points,
		Quadrature *	quad,
		PatchFEValues< 3 > *	pfev,
		ElementCacheMap *	element_cache_map
	)

inline

Constructor of edge integral.

Definition at line 520 of file integral_acc.hh.

◆ ~EdgeIntegralAcc()

template<unsigned int qdim>

EdgeIntegralAcc< qdim >::~EdgeIntegralAcc ( )

inline

Destructor.

Definition at line 529 of file integral_acc.hh.

Member Function Documentation

◆ coords()

template<unsigned int qdim>

FeQ<Vector> EdgeIntegralAcc< qdim >::coords ( )

inline

Create side accessor of coords entity.

Definition at line 563 of file integral_acc.hh.

◆ determinant()

template<unsigned int qdim>

ElQ<Scalar> EdgeIntegralAcc< qdim >::determinant ( )

inline

Create bulk accessor of jac determinant entity.

Definition at line 569 of file integral_acc.hh.

◆ grad_scalar_shape()

template<unsigned int qdim>

FeQArray<Vector> EdgeIntegralAcc< qdim >::grad_scalar_shape ( uint component_idx = 0 )

inline

Same as BulkValues::grad_scalar_shape but register at side quadrature points.

Definition at line 587 of file integral_acc.hh.

◆ grad_vector_shape()

template<unsigned int qdim>

FeQArray<Tensor> EdgeIntegralAcc< qdim >::grad_vector_shape ( uint component_idx = 0 )

inline

Return the value of the function_no-th gradient vector shape function at the p bulk quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 598 of file integral_acc.hh.

◆ JxW()

template<unsigned int qdim>

FeQ<Scalar> EdgeIntegralAcc< qdim >::JxW ( )

inline

Same as BulkValues::JxW but register at side quadrature points.

Definition at line 547 of file integral_acc.hh.

◆ normal_vector()

template<unsigned int qdim>

ElQ<Vector> EdgeIntegralAcc< qdim >::normal_vector ( )

inline

Register the normal vector to a side at side quadrature points.

Parameters

quad	Quadrature.

Definition at line 557 of file integral_acc.hh.

◆ points()

template<unsigned int qdim>

Range< EdgePoint > EdgeIntegralAcc< qdim >::points ( const DHCellSide & cell_side ) const

inline

Returns range of side local points for appropriate cell side accessor.

Definition at line 533 of file integral_acc.hh.

◆ scalar_shape()

template<unsigned int qdim>

FeQArray<Scalar> EdgeIntegralAcc< qdim >::scalar_shape ( uint component_idx = 0 )

inline

Same as BulkValues::scalar_shape but register at side quadrature points.

Definition at line 575 of file integral_acc.hh.

◆ vector_divergence()

template<unsigned int qdim>

FeQArray<Scalar> EdgeIntegralAcc< qdim >::vector_divergence ( uint component_idx = 0 )

inline

Return the value of the function_no-th vector divergence at the p side quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 620 of file integral_acc.hh.

◆ vector_shape()

template<unsigned int qdim>

FeQArray<Vector> EdgeIntegralAcc< qdim >::vector_shape ( uint component_idx = 0 )

inline

Same as BulkValues::vector_shape but register at side quadrature points.

Definition at line 581 of file integral_acc.hh.

◆ vector_sym_grad()

template<unsigned int qdim>

FeQArray<Tensor> EdgeIntegralAcc< qdim >::vector_sym_grad ( uint component_idx = 0 )

inline

Return the value of the function_no-th vector symmetric gradient at the p side quadrature point.

Parameters

component_idx Number of the shape function.

Definition at line 609 of file integral_acc.hh.

Friends And Related Function Documentation

◆ BoundaryIntegralAcc

template<unsigned int qdim>

template<unsigned int quaddim>

friend class BoundaryIntegralAcc

friend

Definition at line 636 of file integral_acc.hh.

◆ BoundaryPoint

template<unsigned int qdim>

friend class BoundaryPoint

friend

Definition at line 632 of file integral_acc.hh.

◆ CouplingIntegralAcc

template<unsigned int qdim>

template<unsigned int quaddim>

friend class CouplingIntegralAcc

friend

Definition at line 634 of file integral_acc.hh.

◆ CouplingPoint

template<unsigned int qdim>

friend class CouplingPoint

friend

Definition at line 631 of file integral_acc.hh.

◆ EdgePoint

template<unsigned int qdim>

friend class EdgePoint

friend

Definition at line 630 of file integral_acc.hh.

◆ EvalPoints

template<unsigned int qdim>

friend class EvalPoints

friend

Definition at line 629 of file integral_acc.hh.

Member Data Documentation

◆ factory_

template<unsigned int qdim>

internal::IntegralFactory<qdim> EdgeIntegralAcc< qdim >::factory_

private

Defines interface of operation accessors declaration.

Definition at line 627 of file integral_acc.hh.

The documentation for this class was generated from the following files:

/home/runner/work/flow123d/flow123d/src/fem/eval_points.hh
/home/runner/work/flow123d/flow123d/src/fem/integral_acc.hh
