Template for classes storing finite set of named values. More...

#include <type_selection.hh>

Inheritance diagram for Input::Type::Selection:

Collaboration diagram for Input::Type::Selection:

Classes
struct	Key
	Structure for description of one key in selection. More...

class	SelectionData
	Internal data class. More...

Public Types
typedef std::vector< struct Key >::const_iterator	keys_const_iterator
	Public typedef of constant iterator into array of keys. More...

Public Types inherited from Input::Type::TypeBase
typedef std::size_t	TypeHash
	Type returned by content_hash methods. More...

typedef std::string	json_string
	String stored in JSON format. More...

typedef std::map< std::string, json_string >	attribute_map
	Defines map of Input::Type attributes. More...

typedef std::pair< std::string, std::shared_ptr< TypeBase > >	ParameterPair
	Defines pairs of (name, Input::Type), that are used for replace of parameters in generic types. More...

typedef std::vector< ParameterPair >	ParameterVector
	Define vector of parameters passed to the overloaded make_instance method. More...

typedef std::map< std::string, TypeHash >	ParameterMap
	Defines map of used parameters. More...

typedef std::pair< std::shared_ptr< TypeBase >, ParameterMap >	MakeInstanceReturnType
	Return type of make_instance methods, contains instance of generic type and map of used parameters. More...

Public Member Functions
	TYPEDEF_ERR_INFO (EI_Selection, const Selection)

	TYPEDEF_ERR_INFO (EI_Value, const int)

	DECLARE_EXCEPTION (ExcSelectionKeyNotFound,<< "Key "<< EI_KeyName::qval<<" not found in Selection:\n"<< EI_Selection::val)

	DECLARE_EXCEPTION (ExcSelectionValueNotFound,<< "Value "<< EI_Value::val<<" not found in Selection:\n"<< EI_Selection::val)

	Selection ()
	Default constructor. Empty selection. More...

	Selection (const Selection &other)
	Copy constructor. More...

	Selection (const string &name, const std::string &description="")
	Creates a handle pointing to the new SelectionData. More...

Selection &	add_value (const int value, const std::string &key, const std::string &description="", TypeBase::attribute_map attributes=TypeBase::attribute_map())
	Adds one new `value` with name given by `key` to the Selection. More...

Selection &	add_attribute (std::string key, TypeBase::json_string value)

const Selection &	close () const
	Close the Selection, no more values can be added. More...

TypeHash	content_hash () const override
	Implements `TypeBase::content_hash`. More...

FinishStatus	finish_status () const override
	Implements `TypeBase::finish_status`. More...

bool	is_finished () const override
	Implements `TypeBase::is_finished`. More...

string	type_name () const override
	Implements `Type::TypeBase::type_name`. More...

string	class_name () const override
	Override `Type::TypeBase::class_name`. More...

bool	operator== (const TypeBase &other) const override
	Implements `TypeBase::operator==` compare also Selection names. More...

keys_const_iterator	begin () const
	Container-like access to the keys of the Selection. More...

keys_const_iterator	end () const
	Container-like access to the keys of the Selection. More...

keys_const_iterator	key_iterator (const string &key) const
	Returns iterator to the key struct for given key string. More...

int	name_to_int (const string &key) const
	Converts given value name `key` to the value. More...

string	int_to_name (const int &value) const
	Returns value name for the given `value`. More...

Selection &	copy_values (const Selection &sel)
	Copy all keys and values from `sel`. More...

bool	has_name (const string &key) const
	Just check if there is a particular name in the Selection. More...

bool	has_value (const int &val) const
	Check if there is a particular value in the Selection. More...

unsigned int	size () const
	Returns number of values in the Selection. More...

FinishStatus	finish (FinishStatus finish_type=FinishStatus::regular_) override
	Finish declaration of the Selection type. More...

bool	is_closed () const override
	Implements `TypeBase::is_closed`. More...

MakeInstanceReturnType	make_instance (std::vector< ParameterPair > vec=std::vector< ParameterPair >()) override

Public Member Functions inherited from Input::Type::TypeBase
string	desc () const
	Returns string with Type extensive documentation. More...

bool	operator!= (const TypeBase &other) const
	Comparison of types. More...

virtual	~TypeBase ()
	Destructor. More...

std::string	hash_str () const
	Format the hash of this type. More...

virtual MakeInstanceReturnType	make_instance (ParameterVector vec=ParameterVector())=0

bool	is_root_of_generic_subtree ()
	Indicates if type is marked with flag `root_of_generic_subtree_`. More...

Private Member Functions
void	finished_check () const
	Assertion for finished Selection (methods are called in correct order). More...

string	key_list () const
	Create string from values of keys. More...

Private Attributes
std::shared_ptr< SelectionData >	data_
	Handle to actual Selection data. More...

Friends
class	OutputBase

Additional Inherited Members
Static Public Member Functions inherited from Input::Type::TypeBase
static void	delete_unfinished_types ()
	Finishes and marks all types registered in type repositories and unused in IST. More...

static std::string	hash_str (TypeHash hash)
	Format given hash for output. More...

Protected Types inherited from Input::Type::TypeBase
typedef string	KeyHash
	The type of hash values used in associative array that translates key names to indices in Record and Selection. More...

Protected Member Functions inherited from Input::Type::TypeBase
	TypeBase ()
	The default constructor. More...

	TypeBase (const TypeBase &other)
	Copy constructor. More...

void	add_attribute_ (std::string name, json_string val)
	Add attribute of given `name` to attribute map. More...

bool	validate_json (json_string str) const
	Check if `str` is valid JSON string. More...

json_string	print_parameter_map_to_json (ParameterMap parameter_map) const
	Create JSON output from `parameter_map` formatted as value of attribute. More...

json_string	print_parameter_map_keys_to_json (ParameterMap param_map) const

void	set_generic_attributes (ParameterMap param_map)

void	copy_attributes (attribute_map other_attributes)

Static Protected Member Functions inherited from Input::Type::TypeBase
static KeyHash	key_hash (const string &str)
	Hash function. More...

static bool	is_valid_identifier (const string &key)
	Check that a `key` is valid identifier. More...

Protected Attributes inherited from Input::Type::TypeBase
std::shared_ptr< attribute_map >	attributes_
	map of type attributes (e. g. input_type, name etc.) More...

bool	root_of_generic_subtree_
	flag is true if type should be root of generic subtree More...

TypeHash	generic_type_hash_
	hash string of generic type if type is derived, or empty string More...

ParameterMap	parameter_map_
	map of parameters if type is part of generic subtree More...

Detailed Description

Template for classes storing finite set of named values.

The primary purpose of this class is initialization of enum variables. Since C++ provides no reflection, in particular no access to enum identifiers as strings, you has to construct the Selection object consistent with an enum you want to initialize.

Similarly to Type::Record and Type::Abstract the Selection class is only proxy to the actual data.

Usage:

enum Colors { blue, white };
const Selection & SomeClass::get_selection_input_type() {
 return Selection("Colors", "Set of color.")
     .add_value(blue, "blue")
     .add_value(white,"white","White color") // with optional item description
     .close();
}

TODO: We can not guarantee full compatibility of the Selection with corresponding Enum type the Selection can have fewer values since we can not get number of values in the Enum. Therefore we either have to move under C++11, where enum classes may provide elementary reflection or have Selection of simple ints.

Definition at line 65 of file type_selection.hh.

Member Typedef Documentation

typedef std::vector<struct Key>::const_iterator Input::Type::Selection::keys_const_iterator

Public typedef of constant iterator into array of keys.

Definition at line 89 of file type_selection.hh.

Constructor & Destructor Documentation

Input::Type::Selection::Selection ( )

Default constructor. Empty selection.

Definition at line 27 of file type_selection.cc.

Here is the caller graph for this function:

Input::Type::Selection::Selection ( const Selection & other )

Copy constructor.

Definition at line 36 of file type_selection.cc.

Input::Type::Selection::Selection	(	const string &	name,
		const std::string &	description = `""`
	)

Creates a handle pointing to the new SelectionData.

Member Function Documentation

Selection & Input::Type::Selection::add_attribute	(	std::string	key,
		TypeBase::json_string	value
	)

Definition at line 59 of file type_selection.cc.

Selection & Input::Type::Selection::add_value	(	const int	value,
		const std::string &	key,
		const std::string &	description = `""`,
		TypeBase::attribute_map	attributes = `TypeBase::attribute_map()`
	)

Adds one new value with name given by key to the Selection.

The description of meaning of the value could be provided.

Definition at line 50 of file type_selection.cc.

Here is the caller graph for this function:

Selection::keys_const_iterator Input::Type::Selection::begin ( ) const

inline

Container-like access to the keys of the Selection.

Returns iterator to the first key.

Definition at line 291 of file type_selection.hh.

Here is the caller graph for this function:

string Input::Type::Selection::class_name ( ) const

overridevirtual

Override Type::TypeBase::class_name.

Reimplemented from Input::Type::TypeBase.

Definition at line 119 of file type_selection.cc.

const Selection & Input::Type::Selection::close ( ) const

Close the Selection, no more values can be added.

Definition at line 65 of file type_selection.cc.

Here is the caller graph for this function:

TypeBase::TypeHash Input::Type::Selection::content_hash ( ) const

overridevirtual

Implements TypeBase::content_hash.

Hash is calculated by type name, description, hash of keys and attributes.

Implements Input::Type::TypeBase.

Definition at line 84 of file type_selection.cc.

Here is the caller graph for this function:

Selection & Input::Type::Selection::copy_values ( const Selection & sel )

Copy all keys and values from sel.

Definition at line 151 of file type_selection.cc.

Input::Type::Selection::DECLARE_EXCEPTION	(	ExcSelectionKeyNotFound	,
		<< "Key "<< EI_KeyName::qval<<" not found in Selection:\n"<< EI_Selection::val
	)

Input::Type::Selection::DECLARE_EXCEPTION	(	ExcSelectionValueNotFound	,
		<< "Value "<< EI_Value::val<<" not found in Selection:\n"<< EI_Selection::val
	)

Selection::keys_const_iterator Input::Type::Selection::end ( ) const

inline

Container-like access to the keys of the Selection.

Returns iterator to the last key.

Definition at line 299 of file type_selection.hh.

Here is the caller graph for this function:

FinishStatus Input::Type::Selection::finish ( FinishStatus finish_type = FinishStatus::regular_ )

overridevirtual

Finish declaration of the Selection type.

Reimplemented from Input::Type::TypeBase.

Definition at line 71 of file type_selection.cc.

Here is the caller graph for this function:

FinishStatus Input::Type::Selection::finish_status ( ) const

overridevirtual

Implements TypeBase::finish_status.

Reimplemented from Input::Type::TypeBase.

Definition at line 100 of file type_selection.cc.

void Input::Type::Selection::finished_check ( ) const

inlineprivate

Assertion for finished Selection (methods are called in correct order).

Definition at line 285 of file type_selection.hh.

Here is the caller graph for this function:

bool Input::Type::Selection::has_name ( const string & key ) const

inline

Just check if there is a particular name in the Selection.

Definition at line 261 of file type_selection.hh.

bool Input::Type::Selection::has_value ( const int & val ) const

inline

Check if there is a particular value in the Selection.

Definition at line 269 of file type_selection.hh.

string Input::Type::Selection::int_to_name ( const int & value ) const

Returns value name for the given value.

Throws exception if the value does not exist.

Definition at line 141 of file type_selection.cc.

bool Input::Type::Selection::is_closed ( ) const

overridevirtual

Implements TypeBase::is_closed.

Reimplemented from Input::Type::TypeBase.

Definition at line 110 of file type_selection.cc.

Here is the caller graph for this function:

bool Input::Type::Selection::is_finished ( ) const

overridevirtual

Implements TypeBase::is_finished.

Reimplemented from Input::Type::TypeBase.

Definition at line 105 of file type_selection.cc.

Here is the caller graph for this function:

Selection::keys_const_iterator Input::Type::Selection::key_iterator ( const string & key ) const

inline

Returns iterator to the key struct for given key string.

Definition at line 306 of file type_selection.hh.

string Input::Type::Selection::key_list ( ) const

private

Create string from values of keys.

Used in error messaged, where we can not use desc(), which can lead to infinite loop due to TYPE selection of Abstract.

Definition at line 165 of file type_selection.cc.

TypeBase::MakeInstanceReturnType Input::Type::Selection::make_instance ( std::vector< ParameterPair > vec = std::vector<ParameterPair>() )

override

Definition at line 174 of file type_selection.cc.

int Input::Type::Selection::name_to_int ( const string & key ) const

Converts given value name key to the value.

Throws exception if the value name does not exist.

Definition at line 130 of file type_selection.cc.

Here is the caller graph for this function:

bool Input::Type::Selection::operator== ( const TypeBase & other ) const

overridevirtual

Implements TypeBase::operator== compare also Selection names.

Reimplemented from Input::Type::TypeBase.

Definition at line 124 of file type_selection.cc.

unsigned int Input::Type::Selection::size ( ) const

inline

Returns number of values in the Selection.

Definition at line 276 of file type_selection.hh.

Here is the caller graph for this function:

string Input::Type::Selection::type_name ( ) const

overridevirtual

Implements Type::TypeBase::type_name.

Name corresponds to data->type_name_.

Reimplemented from Input::Type::TypeBase.

Definition at line 114 of file type_selection.cc.

Here is the caller graph for this function:

Input::Type::Selection::TYPEDEF_ERR_INFO	(	EI_Selection	,
		const Selection
	)

Input::Type::Selection::TYPEDEF_ERR_INFO	(	EI_Value	,
		const int
	)

Friends And Related Function Documentation

friend class OutputBase

friend

Definition at line 66 of file type_selection.hh.

Member Data Documentation

std::shared_ptr<SelectionData> Input::Type::Selection::data_

private

Handle to actual Selection data.

Definition at line 249 of file type_selection.hh.

The documentation for this class was generated from the following files:

/opt/flow123d/flow123d/src/input/type_selection.hh
/opt/flow123d/flow123d/src/input/type_selection.cc

Classes

Public Types

Public Member Functions

Private Member Functions

Private Attributes

Friends

Additional Inherited Members

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Friends And Related Function Documentation

Member Data Documentation
