Class for create and JSON template documentation. More...

#include <type_output.hh>

Inheritance diagram for Input::Type::OutputJSONTemplate:

Collaboration diagram for Input::Type::OutputJSONTemplate:

Public Member Functions
	OutputJSONTemplate (TypeBase *type, unsigned int depth=0)

ostream &	print (ostream &stream)

Public Member Functions inherited from Input::Type::OutputBase
void	set_filter (string regex_filter)
	Initializes and allocates regular expression filter `regex_filter`. More...

Protected Member Functions
void	print (ostream &stream, const TypeBase *type, unsigned int depth)

void	print_impl (ostream &stream, const Record *type, unsigned int depth)

void	print_impl (ostream &stream, const Array *type, unsigned int depth)

void	print_impl (ostream &stream, const AbstractRecord *type, unsigned int depth)

void	print_impl (ostream &stream, const AdHocAbstractRecord *type, unsigned int depth)

void	print_impl (ostream &stream, const Selection *type, unsigned int depth)

void	print_impl (ostream &stream, const Integer *type, unsigned int depth)

void	print_impl (ostream &stream, const Double *type, unsigned int depth)

void	print_impl (ostream &stream, const Bool *type, unsigned int depth)

void	print_impl (ostream &stream, const String *type, unsigned int depth)

void	print_impl (ostream &stream, const FileName *type, unsigned int depth)

Protected Member Functions inherited from Input::Type::OutputBase
	OutputBase (const TypeBase *type, unsigned int depth=0)

virtual	~OutputBase ()
	Destructor. More...

void	get_array_sizes (Array array, unsigned int &lower, unsigned int &upper)
	Gets range of array. More...

const string &	get_record_description (const Record *rec)
	Gets description of the given record type. More...

void	get_record_key (Record rec, unsigned int key_idx, Record::Key &key)
	Gets record key for given index. More...

void	get_integer_bounds (Integer integer, int &lower, int &upper)
	Gets range of integer. More...

void	get_double_bounds (Double dbl, double &lower, double &upper)
	Gets range of double. More...

void	get_parent_ptr (Record rec, boost::shared_ptr< AbstractRecord > &parent_ptr)
	Gets pointer of parent AbstractRecord for given Record. More...

void	get_array_type (Array array, boost::shared_ptr< const TypeBase > &arr_type)
	Gets pointer of inner type for given Array. More...

void	get_default (Record::KeyIter it, string &type, string &value)
	Gets values of default for given record key. More...

const string &	get_selection_description (const Selection *sel)
	Gets description of the given selection type. More...

const string &	get_adhoc_parent_name (const AdHocAbstractRecord *a_rec)
	Gets parent_name_ of the given AdHocAbstractRecord type. More...

AbstractRecord::ChildDataIter	get_adhoc_parent_data (const AdHocAbstractRecord *a_rec)
	Gets iterator to begin of parent_data_ of the given AdHocAbstractRecord type. More...

const void *	get_record_data (const Record *rec)
	Gets pointer of inner data for given Record. More...

const void *	get_abstract_record_data (const AbstractRecord *a_rec)
	Gets pointer of inner data for given AbstractRecord. More...

const void *	get_selection_data (const Selection *sel)
	Gets pointer of inner data for given Selection. More...

const void *	get_array_data (const Array *array)
	Gets pointer of inner data for given Array. More...

const void *	get_type_base_data (const TypeBase *type)
	Gets pointer of inner data for given TypeBase. More...

void	print (ostream &stream, const TypeBase *type, unsigned int depth)

void	write_description (std::ostream &stream, const string &str, unsigned int padding, unsigned int hash_count=1)

void	write_default_value (std::ostream &stream, Default dft)

Private Member Functions
void	print_default_value (ostream &stream, unsigned int depth, string empty_val, bool invalid_val, bool has_quote=false)

Private Attributes
string	key_name_
	temporary value of actually record type More...

string	reference_
	temporary value of actually reference More...

Default	value_
	temporary value of actually record value More...

Additional Inherited Members
Protected Types inherited from Input::Type::OutputBase
enum	DocumentationType { key_record, full_record }

Protected Attributes inherited from Input::Type::OutputBase
const TypeBase *	type_
	Object for which is created printout. More...

unsigned int	depth_
	Depth of printout (for value 0 is printed all input tree) More...

DocumentationType	doc_type_
	Type of documentation output. More...

unsigned int	size_setw_
	temporary value for printout of description (used in std::setw function) More...

std::string	format_head

std::string	format_tail

ProcessedTypes	doc_flags_
	Stores flags and references of processed type. More...

Static Protected Attributes inherited from Input::Type::OutputBase
static const unsigned int	padding_size = 4
	Padding of new level of printout, used where we use indentation. More...

Detailed Description

Class for create and JSON template documentation.

Every type is represented by JSON object. Type name, description and other data are displayed as comments. Among other data belongs range of numeric values, size limits of arrays, possible values of selections etc.

Definition at line 343 of file type_output.hh.

Constructor & Destructor Documentation

Input::Type::OutputJSONTemplate::OutputJSONTemplate	(	TypeBase *	type,
		unsigned int	depth = `0`
	)

inline

Constructor for output of the input type tree with root type. The input type tree is searched by DFS algorithm into depth.

Definition at line 349 of file type_output.hh.

Member Function Documentation

ostream & Input::Type::OutputJSONTemplate::print ( ostream & stream )

virtual

Perform output of the documentation into given stream.

Reimplemented from Input::Type::OutputBase.

Definition at line 563 of file type_output.cc.

Here is the caller graph for this function:

void Input::Type::OutputJSONTemplate::print	(	ostream &	stream,
		const TypeBase *	type,
		unsigned int	depth
	)

inlineprotected

Definition at line 358 of file type_output.hh.

void Input::Type::OutputJSONTemplate::print_default_value	(	ostream &	stream,
		unsigned int	depth,
		string	empty_val,
		bool	invalid_val,
		bool	has_quote = `false`
	)

private

Prints value according to DefaultType Respects obligatory, optional and read time flag

Parameters

stream	Output stream
depth	Depth of output
empty_val	Default empty value (zero for numeric types, empty string ...)
invalid_val	Flag if value is invalid for its type
has_quote	Flag if value is enclosed in quotes

Definition at line 886 of file type_output.cc.

void Input::Type::OutputJSONTemplate::print_impl	(	ostream &	stream,
		const Record *	type,
		unsigned int	depth
	)

protectedvirtual

Implements printout of Record type

Implements Input::Type::OutputBase.

Definition at line 569 of file type_output.cc.

void Input::Type::OutputJSONTemplate::print_impl	(	ostream &	stream,
		const Array *	type,
		unsigned int	depth
	)

protectedvirtual

Implements printout of Array type

Implements Input::Type::OutputBase.

Definition at line 634 of file type_output.cc.

void Input::Type::OutputJSONTemplate::print_impl	(	ostream &	stream,
		const AbstractRecord *	type,
		unsigned int	depth
	)

protectedvirtual

Implements printout of AbstractRecord type

Implements Input::Type::OutputBase.

Definition at line 698 of file type_output.cc.

void Input::Type::OutputJSONTemplate::print_impl	(	ostream &	stream,
		const AdHocAbstractRecord *	type,
		unsigned int	depth
	)

protectedvirtual

Implements printout of AdHocAbstractRecord type

Implements Input::Type::OutputBase.

Definition at line 738 of file type_output.cc.

void Input::Type::OutputJSONTemplate::print_impl	(	ostream &	stream,
		const Selection *	type,
		unsigned int	depth
	)

protectedvirtual

Implements printout of Selection type

Implements Input::Type::OutputBase.

Definition at line 752 of file type_output.cc.

void Input::Type::OutputJSONTemplate::print_impl	(	ostream &	stream,
		const Integer *	type,
		unsigned int	depth
	)

protectedvirtual

Implements printout of Integer type

Implements Input::Type::OutputBase.

Definition at line 790 of file type_output.cc.

void Input::Type::OutputJSONTemplate::print_impl	(	ostream &	stream,
		const Double *	type,
		unsigned int	depth
	)

protectedvirtual

Implements printout of Double type

Implements Input::Type::OutputBase.

Definition at line 810 of file type_output.cc.

void Input::Type::OutputJSONTemplate::print_impl	(	ostream &	stream,
		const Bool *	type,
		unsigned int	depth
	)

protectedvirtual

Implements printout of Bool type

Implements Input::Type::OutputBase.

Definition at line 831 of file type_output.cc.

void Input::Type::OutputJSONTemplate::print_impl	(	ostream &	stream,
		const String *	type,
		unsigned int	depth
	)

protectedvirtual

Implements printout of String type

Implements Input::Type::OutputBase.

Definition at line 847 of file type_output.cc.

void Input::Type::OutputJSONTemplate::print_impl	(	ostream &	stream,
		const FileName *	type,
		unsigned int	depth
	)

protectedvirtual

Implements printout of FileName type

Implements Input::Type::OutputBase.

Definition at line 860 of file type_output.cc.

Member Data Documentation

string Input::Type::OutputJSONTemplate::key_name_

private

temporary value of actually record type

Definition at line 388 of file type_output.hh.

string Input::Type::OutputJSONTemplate::reference_

private

temporary value of actually reference

Definition at line 390 of file type_output.hh.

Default Input::Type::OutputJSONTemplate::value_

private

temporary value of actually record value

Definition at line 392 of file type_output.hh.

The documentation for this class was generated from the following files:

/home/builder/jenkins/F123-linux-release/flow123d/src/input/type_output.hh
/home/builder/jenkins/F123-linux-release/flow123d/src/input/type_output.cc
